EverFocus EZH5040 Specifications

EZH5040
720p High Definition Outdoor IR Bullet Camera
Features
• 1/3" Sony ExmorR Progressive Color CMOS
• 1280x720 resolution at 720p (30 FPS)
• HD-SDI (Serial Data Interface Type Video Output) BNC
• True mechanical Day/Night
• TV out (BNC) with NTSC/PAL selectable
• External megapixel lens controller for quick & easy lens zoom &
focus (3-9mm vari-focal)
• OSD menu setting with built-in joystick controller
• Supports second video output for easy camera configuration
• 45 high illuminating IR LED lights
• IR distance up to 45 meters / 150 feet
• Weather resistant IP66 rated
• 12VDC/24VAC dual voltage
Dimensions
196 mm / 7.7"
168.8 mm / 6.6"
98.6 mm / 3.9"
IR LEDs
Photo Cell
61
2011 EverFocus Product Catalog. Note: Product specifications are subject to change without notice. Visit www.everfocus.com for the most updated information.
HD CCTV - Bullet Camera
NEW!
327 mm / 12.9"
1.3
Megapixel

Specifications

Video Format
NTSC/PAL selectable (TV out)
Image Sensor
1/3" 1.3 Megapixel Sony ExmorR Progressive CMOS
Effective Pixels
1296x728 (30 FPS)
Unit Cell Size
3.75 um (H) x 3.75 um (V)
S/N Ratio
50 dB max.
Min. Illumination
0 Lux (IR LED on)
Day/Night
True mechcanical day/night
IR LED
45 IR LEDs
IR Wavelength
850 nm
IR Distance
Up to 45 meters / 150 feet
IR LED Operation
1 Lux (On), 3 Lux (Off)
Min. Exposure Time
110.86us (1/9020 sec)
Video Output Mode
SDI: 720P, 60 FPS (frame conversion)
Lens
Megpapixel vari-focal 3-9 mm lens (F1.6)
OSD Menu
Built-in with joystick controller
Flickerless
Off/50Hz/60Hz (selectable)
Backlight Comp.
On/Off
White Balance
Manual/Auto/Push (selectable)
Operating Temp.
-10°C ~ 50°C / 14°F ~ 122°F
Storage Temp.
-20°C ~ 70°C / -4°F ~ 158°F
Humidity
20~80% (operating), 20~95% (storage)
Power Source
12VDC/24VAC
Power Consumption
12VDC: 13.2W max. / 24VDC: 12W max.
Dimensions (L x W x H)
196 x 98.6 x 88.29 mm / 7.7" x 3.9" x 3.5"
(with sunshield, w/out bracket)
Weight
1.37 kg / 3.02 lbs
Weather Resistant
Yes, IP66 rated
Certification
CE, FCC

Ordering Information**

** Check with your EverFocus sales rep
for release date and availability
* Models vary in different countries. Visit www.everfocus.com and select your
country for accurate ordering information
HD-CCTV/
12VDC/
Weather
24VAC
Resistant
