Vega VEGAPULS 61 Quick Setup Manual
Radar sensor for continuous level measurement of liquids
Hide thumbs
Also See for VEGAPULS 61:
- Operating instructions manual (100 pages) ,
- Quick setup manual (24 pages) ,
- Safety manual (16 pages)
Related Manuals for Vega VEGAPULS 61
Summary of Contents for Vega VEGAPULS 61
- Page 1 Quick setup guide Radar sensor for continuous level measurement of liquids VEGAPULS 61 HART and accumulator pack Document ID: 47099...
-
Page 2: Table Of Contents
Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available on our homepage. Operating instructions VEGAPULS 61 - HART and power pack: Document-ID 40792 Editing status of the quick setup guide: 2021-06-10 VEGAPULS 61 • HART and accumulator pack... -
Page 3: For Your Safety
During work on and with the device, the required personal protective equipment must always be worn. Appropriate use The VEGAPULS 61 is a sensor for continuous level measurement. Due to the integrated accumulator the instrument is particularly suitable as a portable measuring system or test sensor for special applications. -
Page 4: Eu Conformity
This device must accept any interference, including interference that may cause undesired operation of the device This device is approved for unrestricted use only inside closed, sta- tionary vessels made of metal, reinforced fiberglass or concrete. Changes or modifications not expressly approved by the manufac- turer could void the user’s authority to operate this equipment. VEGAPULS 61 • HART and accumulator pack... -
Page 5: Environmental Instructions
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter " Packaging, transport and storage" • Chapter " Disposal" VEGAPULS 61 • HART and accumulator pack... -
Page 6: Product Description
Test certificate (PDF) - optional Move to " www.vega.com" and enter in the search field the serial number of your instrument. Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the " Apple App Store" or the " Google Play Store" • Scan the DataMatrix code on the type label of the instrument or • Enter the serial number manually in the app... -
Page 7: Mounting
Required tools: Allen wrench size 4. There are two ways to screw the strap onto the sensor. Depending on the selected version, the sensors can be swivelled in the strap as follows: • Single chamber housing VEGAPULS 61 • HART and accumulator pack... -
Page 8: Mounting Instructions
1. Distance from the vessel wall > 200 mm, the antenna should protrude > 10 mm into the vessel > 200 mm (7.87") Fig. 5: Distance of the antenna to the vessel wall/vessel ceiling VEGAPULS 61 • HART and accumulator pack... - Page 9 3 Mounting 2. Note min. socket diameter depending on the socket length For further information see chapter " Mounting". VEGAPULS 61 • HART and accumulator pack...
-
Page 10: Connecting To Power Supply
LED lights = accumulator is full, battery charger should be unplugged (accumulator life time) After pressing the key or changing the mode the yellow LED shows the accumulator status for approximately 10 s as follows: • LED lights = accumulator is full • LED flashes = accumulator should be charged VEGAPULS 61 • HART and accumulator pack... - Page 11 4 Connecting to power supply • LED off = accumulator is empty VEGAPULS 61 • HART and accumulator pack...
-
Page 12: Set Up With The Display And Adjustment Module
The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. Fig. 7: Installing the display and adjustment module in the electronics compart- ment of the single chamber housing VEGAPULS 61 • HART and accumulator pack... -
Page 13: Parameter Adjustment
2. In the menu item " Medium"you select the medium of your ap- plication, for example " Aqueous solution". 3. Select in the menu item " Application" the vessel, the application and the vessel form, for example, storage tank. 4. Carry out the adjustment in the menu items " Min. adjustment" and " Max. adjustment". VEGAPULS 61 • HART and accumulator pack... - Page 14 In addition, the echo curve of setup can be dis- played in the echo curve window and compared with the current echo curve. Additional settings - False The following circumstances cause interfering reflections and can signal suppression influence the measurement: • High mounting nozzles • Vessel internals such as struts VEGAPULS 61 • HART and accumulator pack...
- Page 15 When selecting " Extend", the distance to the medium surface of the created false signal suppression is displayed. This value can now be changed and the false signal suppression can be extended to this range. VEGAPULS 61 • HART and accumulator pack...
-
Page 16: Menu Overview
Backlight Switched on Diagnostics Menu item Parameter Default setting Device status Peak value indi- Distance cator Electronics tem- Temperature perature Measurement re- liability Simulation Percent Curve display Echo curve False signal sup- pression VEGAPULS 61 • HART and accumulator pack... - Page 17 Linear Date/Time Actual date/Actual time Reset HART mode Address 0 Copy instrument settings - Info Menu item Parameter Device name VEGAPULS 6. Instrument version Hardware and software version Date of manufacture Date Instrument features Order-specific characteristics VEGAPULS 61 • HART and accumulator pack...
-
Page 18: Set Up With Smartphone/Tablet, Pc/Notebook Via Bluetooth
1. In the adjustment menu, go to " Additional adjustments", " PIN" Note: The menu item " PIN" is only displayed if in the menu " Setup", " Lock/ Unlock adjustment" the adjustment is released. 2. Change sensor PIN VEGAPULS 61 • HART and accumulator pack... -
Page 19: Connecting
Start the adjustment app and select the function "Setup". The smart- phone/tablet searches automatically for Bluetooth-capable instru- ments in the area. PC/Notebook Start PACTware and the VEGA project assistant. Select the device search via Bluetooth and start the search function. The device auto- matically searches for Bluetooth-capable devices in the vicinity. Connecting The message "... - Page 20 6 Set up with smartphone/tablet, PC/notebook via Bluetooth App view Fig. 11: Example of an app view - Setup sensor adjustment VEGAPULS 61 • HART and accumulator pack...
-
Page 21: Supplement
0 … +45° C (+32 … +167 °F) Ʋ Accumulator operation -20 … +60° C (-4 … +140 °F) Temperature derating accumulator capacity Ʋ +25° C (+77 °F) 100 % Ʋ -10° C (+14 °F) 50 % VEGAPULS 61 • HART and accumulator pack... - Page 22 Notes VEGAPULS 61 • HART and accumulator pack...
- Page 23 Notes VEGAPULS 61 • HART and accumulator pack...
- Page 24 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2021 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 77761 Schiltach E-mail: info.de@vega.com...
