- Page 1 Ender-7 创造现实，成就梦想 Create reality，achieve dreams Ender-7 3D Printer User Manual 3D打印机用户使用手册 V1.1...
- Page 3 Dear Consumers, Thank you for choosing our products.For the best experience,please read the instructions before operating the printer. Our teams will always be ready to render you the best services. Please contact us via the phone number or e-mail address provided at the end when you encounter any problem with the printer.
- Page 4 NOTES 使用须知 Do not use the printer any way other than described herein in order to avoid personal injury or property damage. Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment. Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.
- Page 5 Contents目录 Introduction 设备简介 01-01 Parameters 设备参数 02-02 Parts List 零部件清单 03-04 Assemble the 3D Printer 组装3D打印机 05-15 Use the 3D Printer 使用3D打印机 16-21 Start Printing 首次打印 22-24 25-25 Maintenance 维修 26-26 Equipment Maintenance 设备保养 27-27 Circuit Wiring 电路接线 28-29 Trouble-shooting 故障检修...
- Page 6 1. Introduction 设备简介 Storage card slot & Type-C interface 存储卡槽&Type-C接口 Upper Cover 上盖 Teflon tube 铁氟龙管 Y Axis Limit Switch Y轴限位开关 Bellows 波纹管 Sliding rails 滑轨 E Axis Motor E轴电机...
- Page 7 2. Equipment Parameters 设备参数 Basic Parameters 基本参数 Model | 型号 Ender-7 Printing Size | 成型尺寸 250*250*300mm Molding Tech | 成型技术 Nozzle Number | 喷头数量 Slice Thickness | 切片层厚 0.1mm-0.4mm Nozzle Diameter | 喷嘴直径 Standard 0.4mm | 标配0.4mm Precision | 打印精度...
- Page 8 3. Parts List 零件清单 Z-axis Component Z-axis Cover Z轴组件 Z轴盖板 Top component Filament Holder Z-axis profile 顶部组件 料架 Z轴型材...
- Page 9 3. Parts List 零件清单 ×12 M4*10 Hexagon flat round head screw x2 内六角平圆头螺丝M4*10 Power cord Cable connectors x 3 Serrated lock washers x 2 x 24 M5*18组合螺丝 排线压扣 外锯齿轮垫圈 Tips: the above accessories are for reference only, in kind prevail! 注意：...
- Page 10 4. Install Profile 安装型材 Z-axis component Z轴组件 M5*18组合螺丝 Serrated lock washers x 1 外锯齿轮垫圈...
- Page 11 4. Install Profile 安装型材 Z-axis profile Z轴型材 M5*18组合螺丝...
- Page 12 5. Install the Printing Platform 安装打印平台 ×8...
- Page 13 5. Install the Printing Platform 安装打印平台 ×4...
- Page 14 6. Install Top Component 安装顶部组件 Top component 顶部组件 M5*18组合螺丝 Serrated lock washers x 1 外锯齿轮垫圈...
- Page 15 6. Install Top Component 安装顶部组件 M5*18组合螺丝...
- Page 16 7. Install Filament Holder 安装料架 Filament Holder 料架 M4*10 Hexagon flat round head screw x2 内六角平圆头螺丝M4*10...
- Page 17 8. Install Z-axis Cover 安装Z轴盖板 Snap into place in the direction shown in the figure. 按图示方向卡入 Z-axis Cover Z轴盖板...
- Page 18 9. Cable Connection 设备接线 Securely insert the bellow into the mounting hole. 将波纹管用力插入安装孔 Put the cable plug into the socket 将排线插头装入插座中 Cable connectors x 3 排线压扣×3 Install the cable connectors 安装排线压扣...
- Page 19 9. Cable Connection 设备接线 Connect the heated bed cable. 连接热床线 Connect the Z-axis motor cable. 连接Z轴电机线 Note: Align the male plug with the female plug and insert. 注意： 公头凸起处对准母头凹起处插入...
- Page 20 10. Solution for V-wheel jamming of heated bed plate 热床板V轮卡顿解决方案 Gently dial the V-wheel manually to check whether it is idling. If idling happens, please use an open-ended wrench to adjust the off-center separation pillar according to the illustrated direction, so that the V wheel is not idling. 用手轻拨V轮，...
- Page 21 11. Bed Leveling 调平平台...
- Page 22 11. Bed Leveling 调平平台 使其与喷嘴处于刚好贴合状态，...
- Page 23 11. Bed Leveling 调平平台...
- Page 24 12. Preheating 预热...
- Page 25 13. Load Filament 装料...
- Page 26 13. Load Filament 装料 Method 1: Insert the new filament into filament runout detection module, the indicator light is on. Click the "Resume after filament runout" in the display, and set the nozzle temperature to 200℃. Take out the remaining filament in the filament runout detection module from the lower part of the extruder after the temperature rises.
- Page 27 14. Start Printing 开始打印...
- Page 28 14. Start Printing 开始打印 This machine can print at a fast speed, but it is recommended to print at normal speed!Notes: the temperature of the nozzle is set according to the printing speed. Take PLA as an example: 本机器支持高速打印， 但建议以正常速度打印！ 注意： 不同速率时， 喷嘴打印温度需相应调整设置， 创想配送PLA推荐设置参数： Cutting speed 60mm/s 125mm/s...
- Page 29 14. Start Printing 开始打印 storage Warning: Please don't insert or remove the storage card during printing. 警告：在打印过程中，禁止插拔存储卡。...
- Page 30 15.Maintenance- disassemble the upper cover 维修—拆上盖 First move the nozzle unit to where close to the origin . Diagram 1: Move the nozzle unit to where close to the origin first before assembly. 先将喷头组件移至原点附件。 图1： 安装时先将喷头组件移至原点附件。 Diagram 2: Then align the positioning pins of the upper cover with the holes of the Diagram 1: Remove the screws used for fixing of top cover, 图1：...
- Page 31 16.Equipment Maintenance 设备保养 Maintenance of sliding rails/ sliding blocks: Three sliding rails and sliding blocks in the X/Y line should be periodically maintained (generally per 3-6 months). When surfaces of sliding rails lack the lubricant or there is abnormal sound during the operation, it means that balls in sliding blocks lack the lubricant and lubricating grease or lubricating fluid should be applied on the sliding rails.
- Page 32 17. Circuit Wiring 电路接线 Motor wire 电线机 E轴电机接口 Storage Card 存储卡 Y signal cable interface Type-C Y信号线接口 X signal cable interface X信号线接口 Controllable fan 可控风扇 Fuse 保险丝 Display interface 显示屏接口 Normally open fan 常开风扇 Auto leveling interface 自动调平接口 DC24V power input DC24V电源输入...
- Page 33 18. Trouble-shooting Play by menory storage card Play by menory storage card motor motor Extrusion gear loose Extrusion gear loose motor motor...
- Page 34 18. 故障检修...
- Page 36 SHENZHEN CREALITY 3D TECHNOLOGY CO., LTD. Add:18F,JinXiuHongDu Building, Meilong Blvd., Longhua Dist., Shenzhen, China 518131 Official Website: www.creality.com Tel：+86 755-8523 4565 E-mail: info@creality.com cs@creality.com 深圳市创想三维科技有限公司 深圳市龙华区民治街道新牛社区梅龙大道锦绣鸿都大厦18F Scan To Learn More 公司网站：www.cxsw3d.com 扫 码 了 解 更 多 服务热线：400 6133 882 0755-8523 4565...
