Ender-3 3D Printer
Instructions for assembly
◆ This guide is for the Ender-3 3D printer.
◆ Select the correct input voltage to match
your local mains (220V or 110V).
◆ Because of software/hardware upgrades
and model differences, new revisions
may not be listed in this guide.
◆ Detailed instructions for use are
available on the SD card.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ender-3 and is the answer not in the manual?

Questions and answers

Related Manuals for Ender Ender-3

Summary of Contents for Ender Ender-3

  • Page 1 Ender-3 3D Printer Instructions for assembly ◆ This guide is for the Ender-3 3D printer. ◆ Select the correct input voltage to match your local mains (220V or 110V). ◆ Because of software/hardware upgrades and model differences, new revisions may not be listed in this guide.
  • Page 2 Step1. BOM a. Remove the parts from the box and remove any tape and padding from the parts. Inspect the parts to make sure they were not damaged in shipment. b. Check the items on List 1 and List 2. The wiring harness of component (Ba) and component (N) has already been connected.
  • Page 3 Step 2. Install aluminum extrusions (L) and (R) to base (Ba) Prepare the following parts: a. M5x45 socket head hex screws (4x) b. M5 washer (4x) c. Aluminum profiles (L) (1x) d. Aluminum profiles(R) (1x) e. Base (Ba) (1x) f. 4mm Allen key Step 1.
  • Page 4 Step 3. Power supply and operation screen installation Prepare the following parts: a. M5x8 hex drive rounded head screws (2x) b. Operation screen assembly(S) (1x) c. M4x20 socket head hex screws (2x) d. Switching power supply assembly（P）- (1x) e. 3mm Allen key *Select the correct input voltage to match your local mains (220V or 110V).
  • Page 5 Step 4. Z axis limit switch installation 1. Prepare limit switch assembly (ZI) and 3mm Allen key； 2. The direction of the base (Ba) stays at the front, and the switch assembly (ZI) is mounted on the left side of the base (Ba) (as shown in the diagram on the)；...
  • Page 6 Step 5. Z axis motor assembly installation Prepare the following parts: a. T8 Acme lead screw (1x) b. M4x18 hex drive flat head screws (2x) c. Z-axis motor assembly (Zm) (1x) d. 2.5mm Allen key Step 1. Rotate base (Ba) 180°until the back is facing towards you.
  • Page 7 Step 6. X-axis bearing installation preparation Prepare the following parts: a. Aluminum profiles(B1)-(1x) b.M4x16 Hex drive rounded head screws (4x) c. M4 Washer (4x) d. Extrusion assembly (E) (1x) e. Nozzle kit (N)-(1x). The wiring harness of component (N) and component (Ba) has already been connected.
  • Page 8 Step 7. X-axis assembly (part 1) Step 1. Assembly of aluminum profile (B1) and extrusion assembly (E). Aluminum profile (B1) is shown in the diagram on the left(1). Pay attention to the position and direction of the large hole. Align the hole of extrusion assembly (E) with the threaded hole of aluminum profile (B1), it should be noted that the hole has two plates, which aresecured with M4*16 screws, and fixed to the second profile plate and the...
  • Page 9 Step 8. X-axis assembly (Part 2) Step 1. Prepare belt tensioner assembly (K1) and 3mm Allen key. Step 2. Rotate the X-axis assembly 180°horizontally. Step 3. Pick up the belt tensioner assembly (K1). Loosen the T-nut by hand until it is at the end of the threads, but not so far it might fall off.
  • Page 10 Step 9. X, Z bearing assembly Step 1. Prepare 2mm and 2.5mm Allen key. Step 2. The direction of the base (Ba) keeps the end in front and rotates the X-axis assembly horizontally by 180°. Step 3. Align the pulleys on both ends of the X-axis assembly with the aluminum chute on the base (Ba).
  • Page 11 Step 10. Fix the gantry frame Prepare the following parts: a. M5x25 socket head hex screws (4x) b. M5 Washer (4x) c. Profile end caps(C)-(2x) d. Aluminum profiles (B2)-(1x) e. 4mm hexagon wrench Step 1. Take out the aluminum profile (B2), pay attention to the counterbore hole at the top (see the figure on the left), align the aluminum profile (B2) hole with...

  • Page 12: Step 11. Rack Installation

    M5 T-nut until it it is on the last few threads of the screew. Step 3. Align the T-nut with the top aluminum profile groove and tighten with an Allen key. Step 4. The Ender-3 mechanical part installation has been completed.
  • Page 13 Step 12. Tube and wire connection Step 1. Rotate the printer by 90º Step 2. Find the letters on the 1/2/4/7/8 wire harnesses, as shown on the left, and insert it according to the position indicated by the red arrow on the drawing. After the insertion, gently pull on it to insure it’s firmly seated.
  • Page 14 Shenzhen Creality3D Technology CO.,LTD. O f f i c i a l We b s i t e : www.creality3d.cn Company Address: 12F, Building No.3, Jinchengyuan Industrial Area, Huafan Road, Dalang, Longhua, Shenzhen, Guangdong Province...
