USB 1.1 RV2850
2-Port USB 1.1 85m* CAT 5e/6/7
Extender System
Quick
Start
Guide
Product Contents:
▪ USB 1.1 RV2850 Local Extender
▪ USB 1.1 RV2850 Remote Extender
▪ USB Cable
▪ Quick Start Guide
Before you get started, ensure that all the drivers
required for your USB device(s) are installed.
1
Place units where desired and connect the
CAT 5e/6/7 (solid core) extension link cable
to the Link ports (RJ45) on the local extender
and remote extender units.
Local Extender
(CAT 5e/6/7 cable
*Maximum Cable Range:
Full-Speed and Low-Speed: up to 40m (131 ft)
Low-Speed HID Devices: up to 85m (279 ft)
2
Connect the local extender to your computer
using the included USB cable.
Computer
3
Attach USB device(s) to the remote extender.
Remote Extender
not included)
Advertisement
Related Manuals for Extreme USB RV2850
Summary of Contents for Extreme USB RV2850
- Page 1 Connect the local extender to your computer using the included USB cable. Product Contents: Computer ▪ USB 1.1 RV2850 Local Extender ▪ USB 1.1 RV2850 Remote Extender ▪ USB Cable ▪ Quick Start Guide Attach USB device(s) to the remote extender.
- Page 2 CE Statement We, Icron Technologies Corporation, an Analog Devices brand, declare under our sole responsibility that the Icron USB 1.1 RV2850, to which this declaration relates, is in conformity with European Standards EN 55024, EN 55032, EN 61000, and RoHS Directive 2011/65/EU + 2015/863/EU.
