Epygi Quadro Quadro FXO Specifications

QuadroFXO: The Gateway to PSTN, FXO Extension and/or Mini POP
Gateway to the PSTN
The QuadroFXO is a modular approach to adding
additional outside PSTN lines (POTS) to a corporate
phone network that utilizes an Epygi Quadro IP PBX.
Each QuadroFXO is a stand-alone SIP gateway de-
vice with 6 outside POTS lines. Multiple QuadroFXO
gateways can be added to a Quadro IP PBX depend-
ing on how many additional lines are required. Uses
include the addition of inbound lines, the balancing
of outbound call volumes from a combination of ana-
log and IP phones, fax lines, E911 emergency lines and
individual direct dial numbers for each salesperson.
FXO Extension for Quadro IP PBX
Connected via Ethernet to the LAN interface of a
Quadro IP PBX, QuadroFXO delivers six addional
POTS lines for PSTN calls. Minimal configura-
tion is needed, the Quadro IP PBX will au-
tomatically use the new POTS ports and
present them within its management sys-
tem as additional FXO lines. These lines may be
co-located with the IP PBX or located remotely as
an "extension cord" to another office in another city
or even another country.
Technical Data: QuadroFXO
The Analog Gateway
Mini Point of Presence (POP)
The QuadroFXO can be used as a low cost, mini Point
of Presence (POP). In this configuration you remove
the IP PBX altogether by assigning VoIP network DID
numbers from an ITSP directly to the QuadroFXO
lines. Think of it as a smaller scale alternative to the
QuadroE1/T1 gateway. It truly is the lowest cost for
creating a local presence anywhere on the globe.
N
L A
INTERNET
N
W A
W
A N
F X
O
O
F X
PSTN
PSTN
O
F X
PSTN
O
F X
N
L A
