Owner's Manual and Assembly Instructions
Model #: W458AC, W458AC-F
Read and understand the entire manual before assembly and operation. The vehicle must be
assembled by an adult who has read and understands the instructions.
Made in China.
Styles and colours may vary. Do not return to store. Call 1-888-982-9309 for assistance and
replacement parts.
IMPORTANT:
Save this manual with your sales receipt.
Scan here
to view the
assembly video
6V Audi R8 Spyder

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W458AC-F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rollplay W458AC-F

Summary of Contents for Rollplay W458AC-F

  • Page 1 6V Audi R8 Spyder Owner’s Manual and Assembly Instructions Model #: W458AC, W458AC-F Read and understand the entire manual before assembly and operation. The vehicle must be assembled by an adult who has read and understands the instructions. Made in China.
  • Page 2 Introduction Thank you for purchasing this vehicle from Rollplay. We hope the rider enjoys it for miles to come. Please read this instruction guide carefully before assembling and operating the vehicle. Please have your model number and serial number ready before calling. Please have proof of purchase.
  • Page 3 Call Customer Service if you need assistance or replacement parts. Please have your model number and serial number ready before calling. Please have proof of purchase. Keep your sales receipt or register your product at www.rollplay.net as we may require proof of purchase. 1-888-982-9309 Read this entire manual to ensure proper assembly and safe operation of the vehicle.
  • Page 4 This page is intentionally left blank.

  • Page 5: Table Of Contents

    Table of Contents Safety ............6 Parts ............8 Charging Instructions .......9 Assemble the Front Wheels ....10 Assemble the Rear Wheels .....11 Dashboard/Windshield Assembly ..12 Assemble the Steering Wheel ....13 Attach the Mirrors ........14 Attach the Seat ........15 Operation Instructions ......16 Battery Removal ........17 Maintenance ..........18 General Care ..........19 Troubleshooting Guide ......20...

  • Page 6: Safety

    Safety WARNING: SAFETY RIDING RULES The user must follow all safety rules and guidelines, or serious injury or death may occur to the user. • Always use common sense and safe practices when using the vehicle. The user must be at least 3 years old and weigh no more than 35 kg (77 lbs). •...
  • Page 7 Safety (Continued) WARNING: BATTERY SAFETY • Battery posts, terminals and related accessories contain lead and lead compound (asic) chemicals known to the state of California to cause cancer, reproductive harm, and are toxic and corrosive. DO NOT open the battery. •...

  • Page 8: Parts

    Parts 1. Car Body 2. Seat 3. Steering Wheel 4. Dashboard 5. Windshield 6. Left and Right Mirrors 7. Front Wheel (2) 8. Rear Wheel (2) 9. Hubcap (4) 10. Battery Charger (1) 11. Steering Wheel Screw (1) 12. Steering Wheel Nut (1) 13.

  • Page 9: Charging Instructions

    Charging Instructions YOU MUST CHARGE THE BATTERY FOR 24 HOURS BEFORE THE FIRST USE! ONLY AN ADULT SHOULD HANDLE THE BATTERY AND CHARGER. To Charge the Battery: 1. Ensure the vehicle is stopped and turned off. 2. Unlock and remove the seat. 3.

  • Page 10: Assemble The Front Wheels

    Assemble the Front Wheels Helpful Tip: Using pliers will make it easier to remove the snap pin from the wheel axle 1. Locate the snap pins (14) and large washers (15) from the blister box. Slide the large washer (15) onto the axle 2.

  • Page 11: Assemble The Rear Wheels

    Assemble the Rear Wheels Helpful Tip: If you encounter trouble fitting both wheels onto the rear axle, then your rear wheel axle may need to be realigned. Remove both wheels from the rear wheel axle. Using two hands, push down on the rear wheel axle and slide it gently toward the side of the vehicle that...

  • Page 12: Dashboard/Windshield Assembly

    Dashboard/Windshield Assembly 1. Position the two front tabs on the dashboard above the slots on the windshield. 2. Snap the windshield onto the dashboard. 3. Connect the wire from the dashboard to the wire from the car body. 1. Holding the dashboard/ windshield assembly together, insert the steering Steering Rod...

  • Page 13: Assemble The Steering Wheel

    Assemble the Steering Wheel 1. Use a Phillips head screwdriver to remove the screw on the battery compartment of the steering wheel. 2. Insert two AAA batteries into the battery compartment. 3. Replace cover and use the screwdriver to fasten. WARNING •...

  • Page 14: Attach The Mirrors

    Attach the Mirrors 1. Align the bottom of the mirror with the hole on the car body near the dashboard. 2. Gently press the mirror down into place. 3. Repeat for the other mirror.

  • Page 15: Attach The Seat

    Attach the Seat 1. Ensure the lock on the car seat (2) is in the unlock position. 2. Align the two hooks on the back of the car seat (2) with the holes on the back of the battery compartment. 3.

  • Page 16: Operation Instructions

    Operation Instructions Turn steering wheel left to steer left, right to steer right Mirrors Turn In and Out Press Pedal to Go, Release Push Buttons for Pedal to Stop Sounds Forward/Reverse Shifter Power Switch Seat Lock Unlocks and Locks Seat Press Button to Access the Trunk...

  • Page 17: Battery Removal

    Battery Removal Battery Strap 1. Unlock and remove the seat 2. Disconnect the red battery connector from the red engine connector 3. Loosen and remove the screw from the battery strap using a Phillips screwdriver 4. Slide the battery strap out from the battery strap slot 5.

  • Page 18: Maintenance

    Maintenance Important Battery and Charger Information • Only an adult who has read and understands the safety warnings may handle and operate the battery and battery charger. Keep away from children. • Charge the battery for 24 hours before using the vehicle for the first time.

  • Page 19: General Care

    General Care • Regularly inspect all vehicle parts to ensure they are in good working condition. • Regularly inspect the charger, cord, plug, and other related parts for damage. • Remove any damaged parts and immediately contact Customer Service for replacement parts. See Service and Repairs on Page 23 for more information.

  • Page 20: Troubleshooting Guide

    Troubleshooting Guide Completely read through the manual and troubleshooting guide before contacting Customer Service. Problem Potential Cause Solution Vehicle does not run Battery is low Recharge the battery Snap pins are loose Tighten snap pins Loose wires or loose Ensure the battery connectors connectors are securely attached.
  • Page 21 Problem Potential Cause Solution Vehicle needs a push to Loose wires or loose Ensure the battery connectors start connectors are securely attached. If wires are loose, contact Customer Service “Dead spot” on motor A “dead spot” means electricity is not being delivered to the terminal.

  • Page 22: Fcc Information

    FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 23: Service And Repairs

    Hours: 9 AM - 5 PM (CST), Monday - Friday 888-982-9309 Phone: 1- Email: customerservice@rollplay.net Web: www.rollplay.net For a list of available replacement parts, please visit www.rollplay.net WE WILL REQUIRE PROOF OF PURCHASE. Please save your sales receipt or register your product at www.rollplay.net.

  • Page 24: Warranty

    This warranty does not cover, and is not intended to exclude any liability on the part of Rollplay, whether under this warranty or implied by law for any indirect or consequential damages for breach of warranty. Some states may not allow the exclusion or limitation so this limitation may not apply to you.

  • Page 25: Product Registration

    City: State: Zip Code: Email: Phone: Date of Purchase: The following product information is on the cover of the owner’s manual. Product Name: Model Number: Serial Number: Retailer Place of Purchase: Questions or comments? Contact us at www.rollplay.net or 1-888-982-9309...
