MODEL: VTA-247B
BROOKLINE
6-IN-1 TURNTABLE
Instruction Manual
PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY
BEFORE USE AND KEEP IT FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BROOKLINE and is the answer not in the manual?

Questions and answers

Summary of Contents for Victrola BROOKLINE

  • Page 1 MODEL: VTA-247B BROOKLINE 6-IN-1 TURNTABLE Instruction Manual PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USE AND KEEP IT FOR FUTURE REFERENCE.
  • Page 2: Table Of Contents

    Important Safety Instructions ..................3 Product Overview ...................... 5 Setup / Basic Operation ..................... 8 Listening to the FM Radio ..................8 Listening to a CD/CD-RW ..................8 Listening to an External Audio Device (BT Mode) ..........10 Listening to an External Audio Device (AUX Mode) ..........10 Listening to a Vinyl Record..................
  • Page 3: Important Safety Instructions

    CAUTION: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. WARNING: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure. WARNING: Invisible laser radiation when open and interlock failed or defeated.
  • Page 4 -This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. -Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside.
  • Page 5: Product Overview

    Product Overview Top View POWER Press to turn the unit on or off. 3.5mm HEADPHONE JACK 3.5mm AUX-IN JACK: Connect your external source to the AUX-IN jack. OPEN/CLOSE ( ): In CD mode, use to open and close the disc tray. PAIR: Press to disconnect currently paired device.
  • Page 6 Front View 17. VOLUME KNOB: Turn to adjust volume. 18. FUNCTION KNOB (FM, CD, BT, AUX, PHONO, TAPE) Rotate to select your desire function. 19. RADIO TUNER KNOB: In FM mode, turn to tune in a station. 20. LED DISPLAY Left Side View 21.
  • Page 7 Rear View 23. FM Antenna 24. LINE OUT Jacks For amplifier device with RCA auxiliary input sockets, insert the white and red plugs on the RCA cable into the unit. Insert the opposite end into the amplifier device. Be sure to connect the white plug to the white jack and the red plug to the red jack.
  • Page 8: Setup / Basic Operation

    Setup / Basic Operation Setup 1. Remove white protective needle cover by gently pulling towards front of unit. 2. Remove any packaging materials from the unit. 3. Connect the AC power cord to a wall outlet. Note: -It is strongly recommended that this product should be operated only from the type of power source indicated on the marking label.
  • Page 9 7. To return to the previous or skip tracks, press the corresponding button ( 8. To Fast Forward / Rewind within a track, press and hold down the corresponding skip button ) until the desired position is reached. 9. To stop playback, press the STOP ( ) button.
  • Page 10: Listening To An External Audio Device (Bt Mode)

    To check the programmed order In stop mode, press ( ) repeatedly to show the track numbers that have been programmed. Listening to an External Audio Device (BT Mode) In BT (Bluetooth) mode, this unit can play music from external devices that have a built-in Bluetooth feature.
  • Page 11: Listening To A Vinyl Record

    Listening to a Vinyl Record 1. Rotate to select “PHONO” function. The LED Display will display “PHON”. 2. Gently open the top cover. Note: Be careful not to pinch your finger when opening/closing the top cover. 3. Place a vinyl record on the turntable. When playing a 45 RPM record, use the included adaptor. 4.
  • Page 12 Handling Vinyl Records Do not touch the record’s grooves. Only handle records by the edges or the label with clean hands. • Touching the record surface will cause your record’s quality to deteriorate. To clean a record, use a soft anti-static cloth to gently wipe the record surface. •...
  • Page 13: Specifications

    Specifications GENERAL Power Requirements AC 120 V~60 Hz Power Consumption x 7.6in x 14.76in Dimensions (W x H x D) 17.72in (approx.) x 193mm x 375mm 450mm (approx.) Weight 15.41 lbs (approx.) 6.99 (approx.) AMPLIFIER Output Power 5 W + 5 W Frequency Response 60 to 20,000 Hz SPEAKER SYSTEM...
  • Page 14: Troubleshooting Guide

    Troubleshooting Guide Symptom Possible Cause Solution Unit will not Unit is unplugged. Connect the unit to • • • power on. the AC power supply. No sound output The volume level is set too low. Adjust the volume. • • •...
  • Page 15 No sound output The unit is not on AUX mode. Ensure the unit is • • • with external audio switched to AUX device plugged mode. into AUX in jack. No sound. The unit is not switched to Bluetooth mode. Ensure the unit is •...
  • Page 16: Fcc Statement

    FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 17: Warranty

    To obtain service, the purchaser MUST present an original sales receipt / proof of purchase. Please contact us at www.victrola.com to request an RMA (Return Material Authorization) number to return products for service or replacement. Returns without an RMA number on the package will be refused and returned to sender.
