Lectrosonics M2R Instruction Manual page 14

M2R
Vol. Taper
Compat. Mode
Compatibility mode is available to allow the receiver to
operate with IFB (FM). Icon on main screen is shown
when IFB (FM) Mode is active. The M2R is compatible
with Lectrosonics IFB transmitters in IFB mode
Locale
NA: 470.100-614.375 MHz
EU: 470.100-614.375 MHz
AU: 520.000-614.375 MHz
14
Choose between Log or
Linear taper volume control.
Lock/Unlock
The front panel controls can
be locked to prevent unwanted
changes. To lock/unlock, hold
UP + DOWN.
North America (NA) and
Australia (AU) have certain
frequency restrictions, and the
restricted frequencies are not
available in SmartTune. When
chosen, these locales include
the following available
frequency selections in
SmartTune:
About M2R
Default
Menu Item Setting
Flexlist Cleared
Vol/Bal Centered
Mixer Mode Stereo
Limiter Pregain 0
HF Boost 0
Meter Mode Post-Mix
Backlight Always On
Battery Type Lithium
Earphone Stereo
Type
Settings Unlock
Receiver M2R IEM Receiver
Name
Frequency Depends on Locale:
NA/EU 512.000 (TxA)
AU
Displays general informa-
tion about the M2R, includ-
ing serial number and the
versions for both FPGA and
main firmware running in
the receiver.
Returns all settings to the
factory defaults as shown in
the table below.
590.000 (TxB)
525.000 (TxA)
590.000 (TxB)
