JAI GO-2400M-PGE User Manual

2.35m digital progressive scan monochrome and color camera
Hide thumbs Also See for GO-2400M-PGE:
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for purchasing this product.
Be sure to read this manual before use.
This manual includes important safety precautions and instructions on
how to operate the unit. Be sure to read this manual to ensure proper
operation.
© 2016 JAI
User Manual
GO-2400M-PGE
GO-2400C-PGE
2.35M Digital Progressive Scan
Monochrome and Color Camera
Document Version: 2.1
GO-2400-PGE_Ver.2.1_Mar.2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GO-2400M-PGE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JAI GO-2400M-PGE

Summary of Contents for JAI GO-2400M-PGE

  • Page 1 Thank you for purchasing this product. Be sure to read this manual before use. This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read this manual to ensure proper operation. © 2016 JAI...

  • Page 2: Table Of Contents

    GO-2400M-PGE / GO-2400C-PGE Contents Notice ................3 Gamma Function ............35 To use the gamma function ........35 Warranty ...............3 Certifications ..............3 Line Status ..............36 Warning ................3 Shading Correction .............36 Flat Shading ............36 Usage Precautions ............6 Color Shading (GO-2400C-PGE only) ....37 Features ................7 To use the shading correction function ....37...

  • Page 3: Notice

    The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
  • Page 4 GO-2400M-PGE / GO-2400C-PGE Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.
  • Page 5 GO-2400M-PGE / GO-2400C-PGE Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

  • Page 6: Usage Precautions

    GO-2400M-PGE / GO-2400C-PGE Usage Precautions Notes on cable configurations The presence of lighting equipment and television receivers nearby may result in video and audio noise. In such cases, change the cable configurations or placement. Notes on LAN cable connection Secure the locking screws on the connector manually, and do not use a driver.

  • Page 7: Features

    High frame rate The GO-2400M-PGE and GO-2400C-PGE are both capable of frame rates of up to 48.8 fps (8-bit format) for full 2.35-megapixel output. Even faster frame rates can be achieved when binning is utilized (GO-2400M-PGE only) or when a smaller ROI (region of interest) is specified.

  • Page 8: Parts Identification

    GO-2400M-PGE / GO-2400C-PGE Connection example: Camera PoE-compatible switching hub AC adapter External trigger Computer Parts Identification ② ⑤ ④ ③ ⑧ ① ⑥ ⑦ ⑧ 1 Lens mount (C-mount) Mount a C-mount lens, microscope adapter, etc. here. Before mounting a lens, be sure to refer to “Step 2: Connecting Devices” (page 13) and confirm the ™...
  • Page 9 GO-2400M-PGE / GO-2400C-PGE 2 RJ-45 connector Connect a Gigabit Ethernet compatible LAN cable (Category 5e or higher, Category 6 recommended) here. Input/ Pin No. Description output In/Out MX1+ (DA+) In/Out MX1– (DA–) In/Out MX2+ (DB+) In/Out MX3+ (DC+) In/Out MX3– (DC–) In/Out MX2–...
  • Page 10 GO-2400M-PGE / GO-2400C-PGE 6 DC IN / trigger IN connector (6-pin round) Connect the cable for a power supply (optional) or for DC IN / trigger IN here. HR-10A-7R-6PB (73) (Hirose Electric or equivalent) Input/ Pin No. Signal Description output...
  • Page 11 GO-2400M-PGE / GO-2400C-PGE Recommended external output circuit diagram (reference example) Standard circuit diagram example JAI camera User side Userload User GO Series CAMERA (resistor/lamp/relay/etc) side side OUT f rom camera 330~ TLP109(TPR,E) HIROSE_6Pin_NO.3 or 4 2SC6033 180BS USER POWER2 220BS...

  • Page 12: Preparation

    Note When the JAI SDK is installed, a camera driver for the GigE interface is also part of the default installation. This GigE Vision Filter Driver is added to every NIC/port on the host computer. As the driver is also added to the NIC/ port for Internet connection, it may, on some systems, affect Internet access speed.

  • Page 13: Step 2: Connecting Devices

    GO-2400M-PGE / GO-2400C-PGE v Clear the [JAI GigE Vision Filter Driver] checkbox, and save. Step 2: Connecting Devices Connect the lens, LAN cable, AC adapter, and other devices. Attach the lens in a clean environment to prevent dust from adhering to the unit.
  • Page 14 GO-2400M-PGE / GO-2400C-PGE Caution • The maximum performance of the camera may not be realized depending on the lens. • Attaching a lens with a mount protrusion of 9.1 mm or longer may damage the lens or camera. Note The following formula can be used to estimate the focal length.

  • Page 15: Step 3: Verifying The Camera's Network Connection Status

    GO-2400M-PGE / GO-2400C-PGE Step 3: Verifying the Camera’s Network Connection Status When power is supplied to the camera while the necessary equipment is connected, the power / trigger LED and ACT LED at the rear of the camera light amber, and initialization of the camera starts.

  • Page 16: Configuring The Output Format

    Offset Y (vertical position) 0 (pixels) Pixel Format GO-2400M-PGE: 8 Bit Monochrome GO-2400C-PGE: 8 Bit Bayer RG ™ You can specify the image acquisition area. For details, see “ROI (Regional Scanning Function)” (page 38). Select the [Feature Properties] tab, and select the item you want to configure under [Image Format Control].

  • Page 17: Configuring Exposure And External Trigger Settings

    GigE NIC or switch. To correct the problem, you can either reduce the [Packet Size] setting to a value less than 1500 in the JAI Control Tool (under [Transport Layer Control] / [Stream Channel Selector], or set your NIC or switch to support “Jumbo...

  • Page 18: Control Via External Triggers

    GO-2400M-PGE / GO-2400C-PGE Configure the settings by expanding [Acquisition Control] and configuring the following items. Caution Settings can only be configured when image acquisition on the camera is stopped. If an item is grayed out and the setting cannot be changed, stop image acquisition beforehand.

  • Page 19: When Controlling The Exposure Time Using The Pulse Width Of The Trigger Input Signal

    GO-2400M-PGE / GO-2400C-PGE Set [Trigger Mode] to [On]. If necessary, change the [Trigger Source], [Trigger Activation], and [Exposure Auto] settings. When Controlling the Exposure Time using the Pulse Width of the Trigger Input Signal Configure the settings as follows. Item...

  • Page 20: Control Without External Triggers

    GO-2400M-PGE / GO-2400C-PGE Control Without External Triggers When Controlling the Exposure Time Using Specified Exposure Times Configure the settings as follows. Item Setting value / selectable range Trigger Selector (trigger operation) Frame Start Trigger Mode Exposure Mode Timed (control via exposure time) Exposure Time 38 to 7999892 (µs) (1 µs/step)*...

  • Page 21: Step 5: Adjusting The Image Quality

    Expand [Analog Control], and select the gain you want to configure in [Gain Selector]. • For the GO-2400M-PGE, only [Analog All] (master gain) can be configured. • For the GO-2400C-PGE, [Analog All] (master gain), [Digital Red] (digital R gain), and [Digital Blue] (digital B gain) can be configured individually.

  • Page 22: Automatic White Balance Adjustment

    Expand [Analog Control], and select the black level you want to configure in [Black Level Selector]. For the GO-2400M-PGE, only [Digital All] (master black) can be configured. For the GO-2400C-PGE, [Digital All] (master black), [Digital Red] (digital R), and [Digital Blue] (digital B) can be configured individually.

  • Page 23: To Save User Settings

    GO-2400M-PGE / GO-2400C-PGE ■ To save user settings Stop image acquisition. Expand [User Set Control], and select the save destination ([User Set1] to [User Set3]) in [User Set Selector]. Note The factory default setting values are stored in [Default] and cannot be overwritten.

  • Page 24: Basic Function Matrix

     2 × 1 × × ×       2 × 2 × × ×       *1 Operates only on the GO-2400M-PGE *2 Operates only on the GO-2400C-PGE — 24 —...

  • Page 25: Main Functions

    GO-2400M-PGE / GO-2400C-PGE Main Functions GPIO (Digital Input/Output Settings) The camera is equipped with GPIO (general-purpose input/output) functions for generating and using combinations of triggers and other necessary signals within the camera and of signals output from the camera to the system such as those used for lighting equipment control.

  • Page 26: Acquisition Control (Image Acquisition Controls)

    GO-2400M-PGE / GO-2400C-PGE Acquisition Control (Image Acquisition Controls) Perform operations and configure settings related to image acquisition in [Acquisition Control]. The following acquisition modes are available on the camera. Acquisition Mode Description Single Frame Acquire a single frame when the [Acquisition Start] command is executed.

  • Page 27: Maximum Frame Rate Period Formula

    GO-2400M-PGE / GO-2400C-PGE ■ Maximum frame rate period formula During continuous operation ([Frame Start] trigger is [Off] or [Exposure Mode] is [Off]) • Maximum frame rate of sensor output SensorFR = 1 / ((Height_s + 40) × Hperiod) • Maximum frame rate of GigE output bandwidth InterfaceFR = 920 ×...

  • Page 28: Exposure Mode

    GO-2400M-PGE / GO-2400C-PGE Pixel Binning User settings Height_s* Height_g* Width_g* H period Pack Maximum Format value frame rate Height Width (fps) 8-bit B.V&B.H 1 1216 1936 1216 1216 1936 12.4445 × 10 48.8 (Off) B.V 2 (On) 1936 1216 1936 B.H 2 (On)

  • Page 29: Trigger Control

    GO-2400M-PGE / GO-2400C-PGE Trigger Control The camera allows the following controls to be performed via external trigger signals. Trigger Selector Description Frame Start Start exposure in response to the external trigger signal input. Select this to perform exposure control using external triggers.

  • Page 30: When [Exposure Mode] Is [Timed]

    GO-2400M-PGE / GO-2400C-PGE ■ When [Exposure Mode] is [Timed] Example: When [Trigger Source] is set to [Line 5 - Optical In 1] and [OptIn Filter Selector] is set to [10 µs] • Trigger overlap: Off Next trigger disabled Next trigger...

  • Page 31: When [Exposure Mode] Is [Trigger Width]

    GO-2400M-PGE / GO-2400C-PGE ■ When [Exposure Mode] is [Trigger Width] Example: When [Trigger Source] is set to [Line 5 - Optical In 1] and [OptIn Filter Selector] is set to [10 µs] • Trigger overlap: Off Next trigger disabled Next trigger...

  • Page 32: Event Control

    GO-2400M-PGE / GO-2400C-PGE Event Control “Event control” is a function that uses GVCP (GigE Vision Control Protocol) to output points of change in the camera’s internal signal as event occurrence information or “event messages.” When this information is output, the camera’s internal timestamp counter value is added.

  • Page 33: To Use The Event Control Function

    GO-2400M-PGE / GO-2400C-PGE ■ To use the event control function Configure the settings as follows. Item Setting value / selectable range Description Event Selector Acquisition Trigger, Select the event for which to send notifications. Frame Start, Frame End, FVAL Start,...

  • Page 34: Lut (Lookup Table)

    LUT Selector* R, G, B Select the LUT channel to control. LUT Index GO-2400M-PGE: 0 to 255 Select the LUT index to configure. Indexes represent the GO-2400C-PGE: 0 to 255 possible pixel values captured on the sensor, from the lowest value (Index 0) to the highest (Index 255).

  • Page 35: Gamma Function

    GO-2400M-PGE / GO-2400C-PGE 4095 Values between points are determined using the linear interpolation values of data LUT Value [1] to the left and right. LUT Value [0] Index0 Index255 Index1 Gamma Function The gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display.

  • Page 36: Line Status

    GO-2400M-PGE / GO-2400C-PGE Line Status The line status function allows you to verify the status of external input/output signals. You can verify the status of the following signals. • Opt Out 1, Opt Out 2, Opt In 1 • Time Stamp Reset •...

  • Page 37: Color Shading (Go-2400C-Pge Only)

    GO-2400M-PGE / GO-2400C-PGE Within 30% of adjustment range ■ Color Shading (GO-2400C-PGE only) R-channel and B-channel properties are adjusted to using the G-channel shading properties as a reference. Pre-correction Post-correction Caution Proper correction is not possible under the following conditions.

  • Page 38: Roi (Regional Scanning Function)

    GO-2400M-PGE / GO-2400C-PGE ROI (Regional Scanning Function) The ROI (region of interest) function allows you to output images by specifying the areas to scan. ROI Settings Specify the area to scan by specifying width, height, and horizontal/vertical offset values under [Image Format Control].

  • Page 39: Sensor Multi Roi Function

    GO-2400M-PGE / GO-2400C-PGE Sensor Multi ROI Function Sensor Multi ROI is an ROI function that is configured and functions inside the sensor. You can configure up to 16 scanning regions (4 horizontal and 4 vertical). By skipping areas that are not specified as regions of interest when scanning a frame, the sensor's ROI function outputs the specified regions in a compressed state.
  • Page 40 GO-2400M-PGE / GO-2400C-PGE When you configure the [OffsetH], [Width], [OffsetV], and [Height] settings for an index and set [Horizontal Enable] or [Vertical Enable] to [True] for that index, the corresponding area is configured. When [False] is specified, the settings within the index are disabled.

  • Page 41: Video Send Mode

    GO-2400M-PGE / GO-2400C-PGE Differences when Multi ROI Overlap is on or off Operations will be as follows in On Mode and Off Mode of Multi ROI Overlap. MultiROI Overlap OffMode Sensor ROI used Frame Sensor Memory Sensor ROI outputs will be output as is.

  • Page 42: Multi Roi Mode

    GO-2400M-PGE / GO-2400C-PGE ■ Multi ROI Mode In the multi ROI mode, you can specify up to five scanning areas (Index 1 to 5) for a single-frame image. On the GO-2400-PGE, the areas can overlap, and a separate frame will be output for each area.
  • Page 43 GO-2400M-PGE / GO-2400C-PGE Trigger Sequencer mode With this mode, the Sequencer Trigger “pattern” is predetermined by the user. The user defines up to 128 different “indexes.” Each index represents a combination of the following parameters: • ROI (width, height, offset X, and offset Y) •...
  • Page 44 GO-2400M-PGE / GO-2400C-PGE Index structure for Trigger Sequencer Index Selector Exposure Black Frame Next Gain1 Binning1 Index1 ROI1 Level1 Enable1 Count1 Index1 (M/Red/Blue) (H/V) (MUX) Exposure Black Frame Next Gain2 Binning2 Index2 ROI2 Level2 Enable2 Count2 Index2 (M/Red/Blue) (H/V) Current...

  • Page 45: Delayed Readout [Acquisition Transfer Start]

    GO-2400M-PGE / GO-2400C-PGE Command Sequencer Example User-defined Indexes (up to 128) Index1 Index2 Index3 Exposure Exposure Exposure Gain Gain Gain Binning Binning Binning Set to Set to Set to Set to Set to Set to Index1 Index1 Index3 Index1 Index2...

  • Page 46: Alc (Automatic Level Control) Function

    Set [Gain Auto] or [Exposure Auto] or both to [Continuous] mode. Configure the minimum value, maximum value, etc. for AGC and ASC under [JAI Custom Control ALC]. The target video levels for AGC and ASC are configured in [ALC Reference]. For example, when [ALC Reference] is set to 100%, video levels will be maintained at 100% for AGC and ASC.

  • Page 47: Detailed Settings For Gain Auto (Automatic Gain Level Control)

    GO-2400M-PGE / GO-2400C-PGE Detailed Settings for Gain Auto (Automatic Gain Level Control) When [Gain Auto] is set to [Continuous], you can configure the conditions for automatic adjustment in detail. Item Description ALC Reference Specify the target level for automatic gain control. (This setting is also used for automatic exposure control.)

  • Page 48: Counter And Timer Control Function (Counter Support Only)

    GO-2400M-PGE / GO-2400C-PGE Counter and Timer Control Function (counter support only) The counter function counts up change points in the camera’s internal signals using the camera’s internal counter, and reads that information from the host side. This function is useful for verifying error conditions via the count value using internal camera operations.

  • Page 49: To Use The Counter Function

    GO-2400M-PGE / GO-2400C-PGE ■ To use the counter function Configure the settings as follows. Three counters can be configured (Counter 0 to 2). Item Setting value / selectable range Description Counter 0 to 2 Counter 0 to 2 Select the counter.

  • Page 50: Chunk Data Function

    GO-2400M-PGE / GO-2400C-PGE Chunk Data Function The Chunk Data function adds camera configuration information to the image data that is output from the camera. Embedding camera configuration information in the image data allows you to use the serial number of the camera as a search key and find specific image data from among large volumes of image data.

  • Page 51: Configuring Chunk Data

    GO-2400M-PGE / GO-2400C-PGE ■ Configuring Chunk Data Set [Chunk Mode Active] to [True]. Select the itesms of information you want added to image data with [Chunk Selector], and set [Chunk Enable] from [False] to [True]. Note When [Chunk Mode Active] is set to [True], [Chunk Image] is automatically set to [True].

  • Page 52: Settings List

    GO-2400M-PGE / GO-2400C-PGE Settings List Feature Properties : Settings that can only be configured when image acquisition on the camera is stopped. Item Setting range Default value Description Display/configure information related to a) Device Control the device. Device Vendor Name —...
  • Page 53 GO-2400M-PGE / GO-2400C-PGE Item Setting range Default value Description Configure image acquisition settings. c) Acquisition Control Acquisition Mode Single Frame, Multi Frame, Continuous Select the image acquisition mode. Continuous Acquisition Start — — Start image acquisition. Acquisition Stop — —...
  • Page 54 Description Gamma 0.45, 0.60, 1.0 0.45 Set the gamma value. JAI LUT Mode Off, Gamma, LUT Select the JAI LUT mode. f) LUT Control Configure LUT settings. LUT Selector R, G, B Select the LUT channel to control. (GO-2400C-PGE only)
  • Page 55 GO-2400M-PGE / GO-2400C-PGE Item Setting range Default value Description Configure settings for digital input/output. h) Digital IO Control Line Selector Line2 - Opt Out 1, Line2 - Opt Out 1 Select the input/output to configure. Line3 - Opt Out 2,...
  • Page 56 GO-2400M-PGE / GO-2400C-PGE Item Setting range Default value Description Pulse Generator Selector Pulse Generator 0 Pulse Generator 0 Select the pulse generator. Pulse Generator Length 1 to 1048575 30000 Set the count-up value (clock value) for the pulse generator. Pulse Generator Length 0.002222 to 2330.166666...
  • Page 57 GO-2400M-PGE / GO-2400C-PGE Item Setting range Default value Description Interface Selector — Set the interface. Mac Address — XX-XX-XX-XX- Display the MAC address. XX-XX Supported LLA — True Display whether LLA (link-local address) is supported. Supported DHCP — True Display whether DHCP is supported.
  • Page 58 GO-2400M-PGE / GO-2400C-PGE Item Setting range Default value Description Timestamp Tick Value — Display the timestamp value. Control Channel Privilege — ControlAccess Display the control channel privilege. Message Channel Port 0 to 65535 XXXXX Set the port number for the message channel.
  • Page 59 Shading Detect Result — — Display the shading detection results. When using the JAI Multi ROI function, set q) JAI Custom Control MultiROI the scanning area. Multi Roi Index Index 1 to 5 Index 1 Set the Multi ROI index table.
  • Page 60 Set the horizontal position. When binning Sensor Multi Roi Offset X 0 to 1920/16 steps ❖ maximum value is enabled on the GO-2400M-PGE, the = 1936 - width value maximum value will change. Sensor Multi Roi Offset Y 0 to 1214/2 step Set the vertical position.

  • Page 61: Miscellaneous

    GO-2400M-PGE / GO-2400C-PGE Miscellaneous Troubleshooting Check the following before requesting help. If the problem persists, contact your local JAI distributor. ■ Power supply and connections Problem Cause and solution The power / trigger LED remains lit amber and Camera initialization may not be complete due to lack of a does not turn green, even after power is network connection.

  • Page 62: Specifications

    GO-2400M-PGE / GO-2400C-PGE Specifications Item GO-2400M-PGE GO-2400C-PGE Scanning system Progressive scan, 1 tap Synchronization Internal Interface 1000BASE-T Ethernet (GigE Vision 1.1), IEEE 802.3af Image sensor 1/1.2-inch monochrome CMOS 1/1.2-inch Bayer color CMOS Image size (effective image) 11.3 (H) × 7.13 (V), 13.4 mm diagonal Pixel size 5.86 (H) ×...
  • Page 63 GO-2400M-PGE / GO-2400C-PGE Item GO-2400M-PGE GO-2400C-PGE Black level Default level 33LSB (during 10-bit output) adjustment Video level adjustment range R/B: 20 to 60 (during 10-bit output) Adjustment range –33LSB to +64LSB against reference level (during 10-bit output) Resolution adjustment 1 STEP = 0.25LSB...

  • Page 64: Frame Rate Reference

    GO-2400M-PGE / GO-2400C-PGE Frame Rate Reference (Theoretical value: decimal values are dropped, during Unpacked) Resolution Frame rate Pixel count ROI/Binning Pixel size(μm) Image size (screen size) 8 / 10 / 12 bit 2.35 MP 1936 × 1216 Full pixel 5.86 × 5.86 1/1.2"...

  • Page 65: Dimensions

    GO-2400M-PGE / GO-2400C-PGE GO-2400C-PGE Dimensions 41.5 C Mount 12.5 23.7 4-M2 Depth3 3-M3 Depth3 Dimensional tolerance: ±0.3 mm Unit: mm — 65 —...

  • Page 66: User's Record

    Serial No. …………….. Firmware version. …………….. For camera revision history, please contact your local JAI distributor. Trademarks • GigE Vision is a registered trademark of AIA (Automated Imaging Association). • Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries.

  • Page 67: Index

    GO-2400M-PGE / GO-2400C-PGE Index 6-pin round 10 JAI Camera Control Tool 12 white balance 21 JAI SDK 12 AC adapter 14 Acquisition Control 26 acquisition modes 26 LAN cable 14 ACT LED 9 LED 9 Adjusting the Black Level 22...
