- Page 1 INSTRUCTION MANUAL Installation and Operating Dimplex Saletto (LPPE) Models: LPP050E / LPP075E / LPP100E / LPP150E These instructions should be read carefully and retained for future use. Note also the information presented on the appliance. 08/80070/0 ISSUE: 2 Series: A...
-
Page 2: Important Safety Advice
IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/ OR DAMAGE AND MAY INVALIDATE YOUR GUARANTEE IMPORTANT SAFETY ADVICE When using electrical heaters, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons, including the following: IMPORTANT: The wall bracket supplied with the heater must be used. -
Page 3: Suitable Applications
CAUTION: Do not use if the heater’s mains power lead is damaged. If the supply cord is damaged it must be replaced by the installer or an approved Dimplex service partner. -
Page 4: Electrical Installation
ELECTRICAL INSTALLATION WARNING: The electrical installation of this heater must be carried out by a suitably qualified or trained electrician, and be in strict accordance with the current wiring Regulations BS 7671. The supply must be connected via a switched fused spur with a fuse rated suitably for the appliances flex. -
Page 5: Child Safety
CHILD SAFETY WARNING: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of appliance by a person responsible for their safety. -
Page 6: Technical Details
Energy Related Product Directive This product complies with Lot20 of the Energy Efficiency Directive (2015/1188). Type of heat output/ room temperature control With electronic room temperature control Electronic room temperature control plus week timer With open window detection With adaptive start control Technical Details Model Identifier(s): 050E... - Page 7 3.3V coin cell battery to backup real time clock. Battery life >5 years. 1.3 metres fitted, 3 core for fused spur installation, 1/N/PE ~230-240 V, Supply 50Hz Class I, with earth wire Approvals CE, BEAB Warranty 2 years Country of Origin United Kingdom Manufacturer Glen Dimplex Heating & Ventilation (GDC Group Ltd.)
-
Page 8: General Information
General Information Please read the instructions closely before first using the product, there is also a quick-start guide on page 8 if you need a reminder of how to use the basic functions in the future. The heater is designed for wall mounting using the wall bracket supplied. It should only be operated when in the upright position as shown - see Fig.3 and Fig.4. - Page 9 To mount the heater to the wall: 1. Remove wall mounting bracket from the back of the heater by depressing the spring latch at the side of each bracket - see Fig.2. 2. Fix the wall bracket securely to the wall through the four screw holes. Ensure only screw fittings suitable for the particular wall type are used.
- Page 10 Fig. 5 Timer Modes Timer Mode Description Your Dimplex LPPE Panel comes pre-programmed User timer Customise times in four periods with four timer modes. These 6 hours heating per day in two...
- Page 11 The User Timer mode will give you four periods of heating split throughout the day. If you are away for an extended period of time then you can use the Holiday mode. This allows you to reduce the heating during the period that you are away, reverting to the previously selected mode on the day you return.
- Page 12 Operation Manual WARNING: FAILURE TO FOLLOW THESE OPERATING INSTRUCTIONS MAY RESULT IN INJURY AND/OR DAMAGE. The controls are located on top of the heater. The heater is fitted with an adjustable electronic controller consisting of a display screen and six touch sensitive buttons. Display Screen ‘Menu’...
-
Page 13: Control Functions
Control Functions The heater controls can be easily adjusted by using the six buttons on the User Interface. The Display Screen shows the options available at each stage of adjustment. Menu - displays the main options list; - Date/Time - Set the date and time. - Mode - Set the mode of operation. -
Page 14: Main Screen
Main Screen After 30 seconds the heater will default back to the Main Screen. Here the current target temperature (setpoint) is displayed along with the mode of operation. Any use of the Advance function will be displayed here, and pressing Enter will show the functions which are enabled. -
Page 15: Modes Of Operation
Modes of Operation The heater comes pre-programmed with a set of heating profiles. The user can change if he / she want to. There are four options available - three pre-programmed and one user adjustable timer; User Timer - provides greatest flexibility to the user. Four time slots are available throughout the day and these can be customised for each day of the week. - Page 16 Choosing and Setting a Mode Timer Modes To choose a timer mode press Menu from the home screen, then navigate to button. Press Enter to select. ‘Timer Mode’ using the followed by Enter. Select a timer by pressing For Out All Day, Home All Day and User Timer, will show three choices available - Select, Preview and Modify.
- Page 17 In Holiday mode the number of days that the room will remain unoccupied for can be adjusted together with the required room temperature. Press to choose a holiday period between 1 and 255 days, then press the Enter button. Press to choose a temperature to be maintained during this period and press the Enter button.
- Page 18 Boost The Advance button is also used to enter the Boost mode which provides temporary heating for one, two, three or four hours. Press the Advance button twice to begin a one hour boost. Continue pressing the Advance button to set longer boost period. Boost 1hr Comfort On Options...
-
Page 19: Child Lock
Child Lock If you need to lock the controls so that the settings cannot be changed then activate the Child Lock. To lock the controls press Back and Enter for three seconds.Child Lock will appear at the bottom of the screen. To unlock the control repeat the action of pressing Back and Enter for three seconds. - Page 20 Runback Lock Mode Introduction 12:00 This appliance has a built in runback lock mode, when this Comfort mode is activated the user will have limited functionality with no access to the settings of the runback timer. It is possible to limit the maximum operating temperature and runback duration in the runback lock mode.
- Page 21 Accessing Runback Lock Mode In order to enter the Runback Lock menu; Back, Menu & Enter must be pressed simultaneously and held for 10 seconds. The user will then be prompted to enter the runback lock PIN. 12:00 Comfort NOTE The default PIN code is 0000, the password can be changed from within the runback lock mode menu.
- Page 22 Runback Duration During setup it is possible to select from a number of preset runback periods. This is achieved by selecting the maximum runback time. The maximum runback time is subdivided into four periods to deliver options to the user, the maximum time options and corresponding runback periods are shown in the table below.
-
Page 23: Battery Replacement
Battery Replacement IMPORTANT: Before replacing the battery ensure the heater is isolated from the electricity supply. NOTE - Battery should be disposed of in an appropriate manner This product is fitted with a replaceable battery in the controls. To replace the battery, follow the steps below, shown in Fig. 6: 1. -
Page 24: Energy Saving Tips
Energy Saving Tips The energy we use to heat, light and power our homes contributes over a quarter of the UK’s carbon emissions, the principle contributor to climate change. Around half the energy used in the home is for heating and hot water, so using your heating system efficiently will not only help the environment, but also save you money. - Page 25 The Dimplex Guarantee Period is two calendar years from the date of purchase of your Dimplex product, or the date of delivery of the product, if later. The Dimplex Guarantee is conditional upon you providing the original purchase receipt as proof of purchase.
- Page 26 • You must provide to Dimplex or its authorised agents on request the original receipt as proof of purchase and - if required by Dimplex - proof of delivery. If you are unable to provide this documentation, you will be required to pay for any repair work required.
- Page 28 Glen Dimplex Heating and Ventilation Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF © Glen Dimplex. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3.
