IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electric shock
and injury to person, including the following:
1. Read all instructions before using this heater.
2. Heater and controls should be installed by a qualified
contractor. Wiring procedures and connections should
be in accordance with the National Electric Code (CEC &
NEC) and local codes.
3. A heater has hot and arcing or sparking parts inside. Do
not use it in areas where gasoline, paint or flammable
liquids are used or stored.
4. This heater is hot when in use. To avoid burns, do not let
bare skin touch hot surfaces. Keep combustible materials
such as: furniture, pillows, bedding, papers, clothes and
curtains away from heater.
5. To prevent a possible fire, do not block air intakes or
exhaust in any manner. Do not use on soft surfaces like a
bed where openings may become blocked.
6. Do not insert or allow foreign objects to enter any ventilation
or exhaust opening as this may cause an electric shock or
fire, or damage the heater.
7. Do not install these heaters against combustible, low
density cellulose fibre surfaces or vinyl wall paper.
8. Do not locate these heaters below any electrical
convenience receptacles.
9. Check nameplate ratings to be sure the heater voltage is
the same as the service supply. (The nameplate is located
below the right side of the heating element.)
10. HIGH TEMPERATURES: Keep electrical cords, furniture,
draperies or any other blocking material away from the
heater. See Installation Section for specific distances.
SAVE THESE INSTRUCTIONS
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Smart Baseboard
LPC Series
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
FCC CAUTION: Any changes or modifications not
expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference
that may cause undesired operation of the device.
Installation Instructions
Placement of the Smart Baseboard
Smart Baseboards are high performance heaters designed
to operate at higher outlet temperatures than conventional
baseboard heaters. They are to be mounted with the included
optimizer kit onto drywall, plaster, wood or concrete walls.
! NOTE: If the unit is being installed on a newly constructed
wall, ensure that all products that have been applied are
fully cured according to manufacturer's instructions, before
operating the unit.
!
NOTE: Failure to install optimizer kit will increase the wall
temperature and may discolor or deform some materials
(e.g. vinyl or plastic).
Recommendations for Locating Drapes and
Furniture near Heater (Figure 1)
!
NOTE: Any objects or materials that are located within the
distances outlined below should not discolor, nor distort
dimensionally (stretch or shrink) upon extended exposure (
up to 1000 hrs.) to temperatures of 200º F (93º C).
For most satisfactory operation of the heaters and minimum
effect on drapes, furniture and objects in close proximity, the
following recommendations should be observed:
1. Full Length Drapes: Hang drapes so there is at least
1.5"(3.8 cm) between the top of the drapes and the ceiling,
at least 1.5" (3.8 cm) between the bottom of the drapes and
the finished floor covering (such as carpet, if used) AND at
least 3" (7.6 cm) between the front vertical surface of the
heater and the nearest fold of the drapes (opened drape).
(Figure 1A)
2. Shorter Length Drapes: Hang drapes so there is at least
1.5" (3.8 cm) between the top of the drapes and the ceiling,
and at least 6" (15.2 cm), preferably more, between the
bottom of the drapes and the top horizontal surface of the
heater. (Figure 1B)
3. Furniture: Place furniture no closer than 3" (7.62 cm) from
the front of the Smart Baseboard. (Figure 1D)
4. Overhanging Solid Objects (Except Plastic): Position
Smart baseboard so there is at least 14" (35.6 cm) between
the top of the heater and any solid object that obstructs or
