2.2 THE WAN INTERFACE CONFIGURATION SCREEN

This section describes the features of the WAN Interface Configuration
screen. Access the screen by using the arrow keys to highlight the WAN
Int Config option at the bottom of the Physical Configuration screen, then
press ENTER. The WAN Interface Configuration screen shown in
Figure 2-2 appears.
Interface Number:
Data Compression: NO
Max Xmit Unit:
Line Coding:
Active Protocol:
RETURN
Figure 2-2. WAN Interface Configuration Screen
2.2.1 WAN Interface Configuration Screen Fields
The following sections describe WAN Interface Configuration screen
fields.
Interface Number
Displays active Interface Numbers. Use this field to configure the
Interface Numbers you assigned to the Timeslots on the WAN Physical
Configuration screen.
