Chapter 2 Local Management - Cabletron Systems WPIM-SY Management Manual

This Chapter explains how to configure the WPIM-SY through Local
Management. The WAN Physical Configuration screen and the WAN
Interface Configuration screen appear as Local Management menu
selections after you install the WPIM-SY into a WAN module such as the
BRIM-W6 and then install the BRIM into a MIM or standalone hub.
Refer to the MIM or standalone hub User's Guide for instructions about
how to setup and access Local Management.
Sections of this chapter include:
• The WAN Physical Configuration screen
• The WAN Interface Configuration screen
• PPP Configuration
• LEX Configuration
• Frame Relay Configuration
Read Sections 2.1 and 2.2 to gain an understanding of the WPIM-SY
Local Management screens. Sections 2.3 through 2.5 provide examples
for setting up the WPIM-SY in a PPP (LEX or BNCP) or Frame Relay
environment.
Navigate through the WPIM Local Management Screens by
using the following keyboard commands:
TIP
SPACEBAR to toggle between selections in a field.
ENTER (RETURN) to implement a selection.
Arrow keys to move up, down or sideways within the screen.
