The WAN Physical Configuration screen displays the following
information for each WPIM.
WPIM 1-4
Displays configuration information for as many as four WPIMs.
Each BRIM-W6 supports two WPIMs. Some of Cabletron's
products (e.g., the NBR-620 or the EMM-E6) will support two
NOTE
BRIM-W6 modules providing connectivity for as many as four
WPIMs. Only one WPIM per BRIM-W6 can be active.
TYPE
Displays the WPIM type.
BRIM #
Displays the BRIM slot in which the WPIM resides.
MODE
Displays the WPIM mode. Toggles between PRIMARY and
SECONDARY. In a device such as the BRIM-W6 where two WPIMs are
utilized but only one can be active at a given time, the second WPIM
installed or recognized defaults to Secondary.
ACTIVE
Displays the status of the WPIM, Yes (active) or No.
IFACES
Displays the interfaces available to each WPIM.
2.1.2 WPIM-SY Configuration Fields
The configuration fields displayed on the Physical Configuration screen
shown in Figure 2-1 vary depending on the type of WPIM. The examples
in this Guide cover the WPIM-SY. Each Cabletron WPIM has a Local
Management Guide that provides specific configuration guidelines.
WPIM-SY LOCAL MANAGEMENT GUIDE
THE WAN PHYSICAL CONFIGURATION SCREEN
2-3
