User Manual
Lobby Camera Phone DRC 703LC/RF1
• Thank you for purchasing COMMAX products.
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRC-703LC/RF1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Commax DRC-703LC/RF1

Summary of Contents for Commax DRC-703LC/RF1

  • Page 1 User Manual Lobby Camera Phone DRC 703LC/RF1 • Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.

  • Page 2: Table Of Contents

    40. Specifications and Features ....................65 41. RF-ID Model (Optional) ......................65 Geetings * Thank you for purchasing a COMMAX product * This product is a high-end Main Entrance Interphone that supports Electronic Number Key (Password) and RF Card Keys features. Please read this manual thoroughly...

  • Page 3: Geetings

    1. Safety Warning & Caution Please follow the things described below in order to prevent any danger or property damage. Prohibition. Warning It may cause a serious damage or No disassembly injury if violated. No touch Must follow strictly. Caution Shows plugging out the power cord It may cause a minor damage or without an exception...
  • Page 4 Warning If an abnormal sound, burning Please don’t disassemble, Please don’t insert any Please use only the designated smell or smoke is coming out repair or rebuild this product metallic or burnable materials batteries for the products of of the product, please plug out arbitrarily (please contact the into the ventilation hole.

  • Page 5: Before Use

    2. Before Use * Wiring Lobby phone and Security Station Phone : 1) For 481 System (Coaxial Cable): Common 8 wires that are 3 channels + 1 channel with “Balance Type”. 2)For Gateview System (UTP Cable): Common 4 wires with 1 channel. * Wiring Lobby phone and Household unit monitor: 1) For 481 System (Coaxial Cable): Common 4 wires that include audio and video via coaxial cable.

  • Page 6: Part Names And Features

    3. Part names and Features 3-1. Part names Number Content Number Content Call Button Camera - calling households and also used for program setting Program Button 3.5” LCD Display - used for program mode settings Cancel Button RF-ID Card Receiver being progressed Microphone Speaker...
  • Page 7 3-2. Essentials ● Initial LCD Display (when power on) ● RF Receiver ③(Optional) For an access by RF Card, when RF Card is brought nearby the LCD display shows a message, “Open Lobby”, with an icon and the door is open. ●...
  • Page 8 ● Electronic Key Button ⑦ (K : Key) For an access to the entrance by password. (Only if the access by password is enabled) ● Security Paging Button ⑧ (G : Guard) To call a security station when an interphone is installed at the security center.
  • Page 9 1) keep pressing the button ,reset will be in progress. 2) Default setting is completed, you can see the message as below. Then, you can release the switch. ● Program Button ⑩ If you press the program button for 5 sec in standby, Program version & default of DRC-703LC will be presented.

  • Page 10: Various Password Types

    2-2. Password for any building: Reset the password by using Management password 2-3. Password for Management Press “Reset Button”. The password will be reset to factory default. 3) Deleting All RF Card Keys function in “8-5” shall ONLY be used when the product is initially installed.

  • Page 11: How To Input Password

    5. How to input Password 5-1. Press management Password • P – old Password – E – 0 – E – New Password – E • Password must be 4 digits. • “0000”, “1234”, “4321” can’t be used as Password ①...
  • Page 12 5-2. Press building Password • P - old Password - E - 1 - E - New Password - E • Password must be 4 digits. • "0000", "1234", "4321" can't be used as Password ① Press program button (P). ②...
  • Page 13 5-3. Press house (Unit) Password • K - 20 - E- house Number - E- old Password - E - New Password - E • Password must be 4 digits. • "0000", "1234", "4321" can't be used as Password • Unit Password no. may not be changed because of Interphone types. (Some model of Interphone can change Password in house.

  • Page 14: Check House Password

    6. Check house Password 6-1. Check house Password • P - management Password - E - 16 - E - Household Unit Number E ① Press program button (P). ② Press management Password. ③ Press call button (E). ④ Press "16" ⑤...

  • Page 15: Set Building Number And Id To Lobby Panel

    7. Set building Number and ID to Lobby panel • This setting is mandatory because building Number and ID automatically are set up when lobby panel call house and security guard. • Max. 99 lobby panel can be installed for one building. 7-1.
  • Page 16 7-2. Set ID no. in Lobby Panel • P - Management Password - E - 3 - E - ID - E ① Press program button (P). ② Press management Password. ③ Press call button (E). ④ Press "3" ⑤ Press call button (E). ⑥...

  • Page 17: Rf Card Key Appliances

    8. RF card key appliances 8-1 RF card key test way • P- Management Password - E - 9 - E - Card Test - X(Cancel) • This function is only for the test of wireless card key ① Press down the (P) button ②...
  • Page 18 8-2. RF card key input way • P- Management Password - E - 10 - E - Place card close to the RF/ID receiver - X(cancel) <References> Up to 2048 cards can be registered(if not to connect with SecuMAX)
  • Page 19 8-3. RF card key separate deletion way • P - Management Password - E - 12 - E - Delete cards - X(Cancel) ① Press Program Button "P" ② Press Management Password ③ Press Call Button "E" ④ Press number "12" ⑤...
  • Page 20 8-4. RF card key separate deletion way • P- Management Password – E- 12 – E - Identification number - E – X(Cancel) ① Press Program Button "P" ② Press Management Password ③ Press Call Button "E" ④ Press number "12" ⑤...
  • Page 21 8-5. RF card key registration check way • P- Management password – E- 13 – E – Check the cards – X(Cancel) ① Press Program Button “P” ② Press Management Password ③ Press Call Button “E” ④ Press number “13” ⑤...
  • Page 22 8-6. RF card key all delete way • P- Management password – E – 11 – E – E • All deletion way is only useful when initially set up, unless all registered cards are to be deleted. ① Press down “P” button ②...
  • Page 23 ① Press down “P” button ② Press Management Password ③ Press down “E” button ④ Press number “19” ⑤ Press Call Button “E” ⑥ Select mode between numbers “0” and “1”. (0 : Up to 2048 RF Card Keys can be registered) (1 : Unlimited RF Card Keys can be registered along with SecuMAX) ⑦...
  • Page 24 8-8. RF card key data transmission • P – Management Passwords – E – 32 – E – Press Dest lobby phone number – E ① Press Program Button "P" ② Press Management password ③ Press Call Button "E" ④ Press number "32" ⑤...

  • Page 25: How To Set The Direct Call Number

    9. How to set the direct Call number • P – Management Password – E – 4 – E – Household number – E • This function is to set the direct call number ① Press Program Button “P”. ② Press Management Passwords. ③...

  • Page 26: Door Release By Internal Information Forwarding To Secumax Way

    10. Door release by internal information forwarding to SecuMAX way • P – Management password – E – 22 – E – 0 – E : Forwarding to SecuMAX disabled • P – Management password – E – 22 – E – 1 – E : Forwarding to SecuMAX enabled •...

  • Page 27: Door Opening Hours Setting

    11. Door opening hours setting • P - Management Passwords - E - 5 - E - Opening hours - E • This function is to control the common entrance door opening hours ① Press Program Button "P" ② Press Management Passwords ③...

  • Page 28: Line-By-Line Call Function Setting

    12. Line-by-line call function Setting • P - Management password - E - 21 - E - 0 - E : available for entire house call • P - Management password - E - 21 - E - Line number - E : call only specified line ex) In case 1 line ~ 2 line, input "0102"...

  • Page 29: Automatic Calling Function Of Guard Station Configuration

    13. Automatic calling function of guard station configuration • P – Management password – E – 27 – E – 0 – E : Automatic call mode • P – Management password – E – 27 – E – 1 – E : Emergency call mode •...

  • Page 30: Call Tones Selection

    14. Call Tones selection • P - Management password - E - 7 - E - 0 - E : Melody sound • P - Management password - E - 7 - E - 1 - E : Bell(Ringer sound) •...

  • Page 31: Setting The Number Of Call Ring Repetitions

    15. Setting the Number of Call Ring Repetitions • P - Management Password - E - 25 - E - 0 - E : Continuous call ring enabled. • P - Management Password - E - 25 - E - 1 - E : 1 time Call ring enabled. •...

  • Page 32: Setting The Number Of Call Ring Repetitions

    • P - Management Password - E - 26 - E – 0 – E : Voice message enabled. • P - Management Password - E - 26 - E – 1 – E : Voice message disabled. • This function enables/disables the Voice Message Function of DRC-703LC/RF1.

  • Page 33: Door Release By External Information Forwarding To Secumax Way

    17. Door release by external information forwarding to SecuMAX way • P – Management password – E – 18 – E – 0 – E : Forwarding to SecuMAX disabled • P – Management password – E – 18 – E – 1 – E : Forwarding to SecuMAX enabled •...

  • Page 34: Set To Be Forced Opening The Main Entrance Door By Secumax

    18. Set to be forced opening the Main Entrance door by SecuMAX • P – Management password – E – 29 – E – 0 – E : Forced opening by SecuMAX disabled • P – Management password – E – 29 – E – 1 – E : Forced opening by SecuMAX enabled •...

  • Page 35: Setting The Time To Trigger The Notice To Be Forced Door Forwarding To Secumax

    19. Setting the time to trigger the notice to be forced door forwarding to SecuMAX • P – Management password – E – 24 – E – 0 – E : This function is disabled • P – Management password – E – 24 – E – 1 – E : Set the time(second) •...

  • Page 36: Selecting The Wiring Method

    20. Selecting the Wiring Method • P – Management Password – E – 6 – E - 1 – E : Gateview method(UTP) • P – Management Password – E – 6 – E - 4 – E : common 4 wire method •...

  • Page 37: Video Out Impedance Adjustment Setting

    21. Video Out Impedance Adjustment Setting • P - Management Password - E - 8 - E - 0 - E : Short distance transmission. • P - Management Password - E - 8 - E - 1 - E : Long distance transmission. •...

  • Page 38: Registration Of Household Unit Number

    22. Registration of Household Unit Number • P - Management Password - E - 15 - E - Call Security from the monitor.- number of household - E - serial number - E • This method applies to the case that there is no security station installed. Calling security from the monitor will direct the call to the lobby phone.
  • Page 39 ① Press Program Button "P". ② Press Management password. ③ Press Call Button "E". ④ Press "15" ⑤ Press Call Button "E". ⑥ From a household unit, call security. The factory default household unit number appears on the LCD display of the lobby phone. Please Press the actual unit number. ⑦...

  • Page 40: Checking Videophone Status Of Household Units

    23. Checking Videophone Status of Household Units • P - Management password - E - 14 - Unit Number - E - serial number - E • This function is to check the status of videophones installed in each household unit.
  • Page 41 ① Press Program Button "P". ② Press Management Password. ③ Press Call Button "E". ④ Press "14" ⑤ Press Call Button "E". ⑥ Press the Unit Number and press Call Button "E". ⑦ Press "0" (number zero as Master lobby phone or Press a corresponding lobby phone number) and press Call Button "E".

  • Page 42: Setting The Keypad Led Option

    24. Setting the Keypad LED Option • P – Management Password – E – 35 – 0 – E : Keypad LED OFF • P – Management Password – E – 35 – 1 – E : Keypad LED ON •...

  • Page 43: Activation Of Electronic Key (Password) Function

    25. Activation of Electronic Key (Password) Function • P - Management Password - E - 31 - 1 - E : Electronic Key (Password) enabled. • P - Management Password - E - 31 - 0 - E : Electronic Key (Password) disabled. •...

  • Page 44: Setting The Volume Of Voice And Beep Sound

    26. Setting the Volume of Voice and Beep Sound • P - Management Password - E - 30 - E - Beep Volume (1~2) - Voice Volume (1~7) - E • This function enables the adjustment of Beep & Voice volume. ①...

  • Page 45: Setting The Voice Announcement Of Unit Number Function

    27. Setting the Voice announcement of unit number function • P – Management Password - E - 17 - E – 0 : Voice announcement of unit number enabled • P – Management Password - E - 17 - E – 1 : Voice announcement of unit number disabled •...

  • Page 46: The Setting Of Video Call Function

    28. The setting of Video call function • P – Management Password - E - 36 – E – 0 – E : video call disabled • P – Management Password - E - 36 – E – 1 – E : video call enabled •...
  • Page 47 ① Press a Program Button(P) ② Enter Management Password ③ Press the Call button (E) ④ Enter Program Number “36” ⑤ Press the call button (E) ⑥ Select the mode between 0 & 1 (0 : Video call is disabled) (1 : Video call is enabled) ⑦...

  • Page 48: Setting The Door Release By Building Password

    29. Setting the door release by building password 29-1. Setting the Door Release by Building Password (Refer to 4-2) • P – Management Password – E – 28 – 1 – E : Door release by Building Password enabled. • P – Management Password – E – 28 – 0 – E : Door release by Building Password disabled.
  • Page 49 ① Press Program Button “P”. ② Enter Management Password. ③ Press Call Button “E”. ④ Enter “28” (number twenty-eight). ⑤ Press Call Button “E”. ⑥ Select mode between the numbers “0” and “1”. (1 : Door release by Building Password enabled) (0 : Door release by Building Password disabled) ⑦...

  • Page 50: How To Set Floor Distributor

    How to Set Floor Distributor (unit number, password, lobby number for monitoring or DTMF availability) • P – Management password- E - 34 – E – Floor distributor ID – E – Input data – P • You may set lobby number for monitoring if a floor distributor is installed and set. •...
  • Page 51 ① Press program button “P” ② Press Management password ③ Press Call Button “E” ④ Press number “36” ⑤ Press Call Button “E” ⑥ Input a new floor distributor ID to be changed (Download floor distributor information) ⑦ Select a new terminal number for the floor distributor to be changed - Move on to terminal number by electronic key buttons ⑧...

  • Page 52: When You Want To Call A Household

    31. When you want to call a household 1) called to a household 2) Call by Extension panel button...

  • Page 53: When You Want To Call A Guard Station

    32. When you want to call a Guard Station 33. Door Release by Unit Password 1) Door release to a household...
  • Page 54 2) Door release by Extension panel button...

  • Page 55: Door Release By Building Password Or Management Password

    34. Door Release by Building Password or Management Password...

  • Page 56: Supplement (Summary Of Various Programs)

    35. Supplement (summary of various programs) Setting Passwords 1. P–Previous Management Password–E–0–E– New Management Password–E: Management Password Registration. 2. P-Previous Building Password-E-1-E-New Building Password-E : Building Password Registration 3. K-20-E-Household Unit Number-E-Previous Unit Password-E-New Unit Password-E : Unit Password Registration 4.
  • Page 57 How to make a unit call and guard station call from a lobby phone 1. Press house number-E : to Household 2. Name search-Select Guard-E : to Guard Station Other settings 1. P-Management Password -E-4-E : Surveillance Monitor Setting (00: disabled, 01: enabled) 2.

  • Page 58: Wiring Information

    36. Wiring Information Guard interphone (1) GateView Guard Station (2) 481 Guard Station...
  • Page 59 (DRC-703LC/RF1) (1) Using Coax Cable...
  • Page 60 (2) Using UTP Cat 5e. Cable <Caution> 1) If installed outdoor, it requires extra molding for water-proof and rainshield. 2) Recommanded height is pertinent from 1450mm ~ 1500mm...
  • Page 61 System schematic (1) Using Coax Cable Reference ⓐ Guard Talk line(common 8 wires) ⓑ Lobby Talk line(common 4 wires) ⓒ External Talk line(common 18 wires) ⓓ External Talk extension line(common 16 wires) ← Optional...
  • Page 62 (2) Using UTP Cat 5e. Cable...
  • Page 63 Wiring Method for CCTV and Sensor Connection...

  • Page 64: Instalation

    37. Installation SCREW M4X50(4EA) SCREW SCREW M3X12(1EA) T3X8(1EA) or PIN FIX <Installation Precautions> 1) Assemble speaker grill at last stage of installing the product. - Assemble from left, then fasten screw on the right side to finish. 2) When installing the product outside the building, make sure the product's sides and edges are waterproof molded with silicon or other materials.

  • Page 65: Miscellaneous

    38. Miscellaneous ※ Please carefully read this User’s Guide before calling service man After checking the entire check list, please contact customer service center. We will do our best to make you satisfy with our services. 39. Part list (1) Using Coax Cable Item Description Q’ty...

  • Page 66: Specifications And Features

    40. Specifications and Features Installation Flush Mount Type installation Model DRC-703LC/RF1 Using Coax cable Using UTP Cat.5e cable Household Household(com 4wires) Wiring (8 wires-com 6w+VD 2w) Guard(com 8 wires) Guard(com 4wires) Power Source DC 12V, 1A Power Consumption Standby: 270mA, Maximum: 680mA...
  • Page 67 Memo...
  • Page 68 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM10703LCR10 Printed In Korea / 2016.03.104...
