MULTIQUIP DAC7000SS Operation And Parts Manual page 123

KUBOTA Z 482-EB ENGINE—INJECTION PUMP COMPONENTS ASSY.
INJECTION PUMP COMPONENTS ASSY.
NO. PART NO.
010 1600151010
010 1754851010
020# 1685151050
020% 1754851050
030# 1584151030
040# 1584151230
050# 1584151240
060# 1685151220
070# 1584196760
080# 1584151560
090# 1584194570
100# 1584151200
110# 1586291430
120# 1585251470
130# 1584151070
140# 1584151250
150# 1584151430
160# 1584151280
170# 1584151270
180# 1584151290
190# 1584151490
200# 1584151060
210# 1584151540
220# 1584193110
230# 1584151380
240# 1584151320
250# 1584196650
260# 1584151350
270# 1584196660
DAC7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #0 (02/15/16) — PAGE 123
PART NAME
INJECTION PUMP ASSY., Z482-EB .................1................INCLUDES ITEMS W/#
INJECTION PUMP ASSY., Z482-E2B/E3B .......1................INCLUDES ITEMS W/%
PLUNGER, PUMP, Z482-EB
PLUNGER, PUMP, Z482-E2B/E3B
VALVE, DELIVERY
SPRING, DELIV. VALVE
GASKET, DELIV. VALVE
HOLDER, DELIV. VALVE
O-RING
FLANGE, SLEEVE
PIN, JOINT
O-RING
SCREW
WASHER
ASSY. TAPPET
PIN, TAPPET GUIDE
PIN, CLAMP
SPRING, PLUNGER
SEAT, SPRING UPPER
SEAT, SPRING LOWER
SHIM
SHIM
PLATE
SCREW, CSK-HD
SLEEVE, CONTROL
SCREW, FOLLOW
GASKET
SCREW
GASKET
QTY. REMARKS
2
2
2
2
2
2
2
2
2
4
4
4
2
2
1
2
2
2
1
1
1
4
2
1
2
1
1
