Table A-1 Switch Specifications (continued)
Item
Redundant Power Supply Input Specifications (supports input from C2RPS-POE only)
Dc Input Voltages
Input Currents
Environmental
Operating Temperature
Storage Temperature
Operating Relative Humidity

Mini-GBIC Input/Output Specifications

The Mini‐Gigabit Ethernet Card (Mini‐GBIC) port interface slots can support 1‐Gbps
fiber‐optic and copper connections as described in Table
are hot swappable.
Table A-2 Mini-GBIC Input/Output Port Specifications
Item
MGBIC-LC01
MGBIC-LC03
MGBIC-LC09
MGBIC-MT01
MGBIC-08
MGBIC-02
Specification
-50 Vdc
+12 Vdc
7.5 A maximum at -50 Vdc
10.5 A maximum at +12 Vdc
5°C to 40°C (41°F to 104°F)
-40°C to 70°C (-40°F to 158°F)
5% to 90% (non-condensing)
Specification
Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC connector.
Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC connector.
Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-LX standard LC connector.
Provides one MT-RJ fiber-optic multi-mode port that is compliant with
the 1000BASE-SX standard MT-RJ connector.
Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-ELX standard LC connector.
Provides one RJ45 copper connection that is compliant with the
1000BASE-T standard RJ45 connector.
Mini-GBIC Input/Output Specifications
A‐2. The optional Mini‐GBICs
SecureStack C2 Installation Guide A-3
