- Page 1 No.15, Wugong 5th Rd., Xinzhuang Dist., New Taipei City 24890, Taiwan (R.O.C.) RoBoard Module RM-G212 Manual V1.01 The Heart of Robotics Jan 2013 DMP Electronics Inc...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the DMP Electronics Inc. Copyright 2013 DMP Electronics Inc. Manual No. RM-G212-01 Ver.1.01...
-
Page 3: Table Of Contents
T a b l e C o n t e n t s C h a p t e r 1 ....................4 1.1 Packing List ................4 1.2 Product Description ..............5 1.3 Specifications ................6 1.4 I C Address ................6 1.5 Board Dimension ............... -
Page 4: Chapter 1
C h a p t e r Introduction 1.1 Packing List Product Name Package RM-G212 RoBoard Module RM-G212 Cable-RM-1 pin Cable RoBoard Module RM-G212 The Heart of Robotics www.RoBoard.com... -
Page 5: Product Description
1.2 Product Description The RM-G212 is a 16X4 array of thermopile sensors suitable to detect thermal radiation and measure temperatures without making contact with the object. The RM-G212 utilizes innovative non-contact temperature measurement technology to create a highly cost-effective thermography solution. Covering a -20°C to 300°C temperature range, this 16 x 4 element far infrared (FIR) thermopile sensor array produces a map of heat values for the target area in real time, avoiding the need to scan the area with a single point sensor... -
Page 6: Specifications
1.3 Specifications RM-G212 16x4 thermal array module 16x4 IR array Melexis MLX90620 Interface EEPROM : 0x50 Default Address RAM : 0x60 Connectors 1.25mm 6-pin wafer for I C x 2 Power Input DC-in 5V Dimension 20mm X 20mm Weight 2.5g 1.4 I C Address EEPROM : 0x50... -
Page 7: Board Dimension
1.5 Board Dimension RoBoard Module RM-G212 The Heart of Robotics www.RoBoard.com... -
Page 8: Chapter 2
C h a p t e r 2 Installation 2.1 Board Outline MLX90620 PWR LED 2.2 Connectors & Jumpers Summary Summary Table Description Type of Connections C connector (Top) Wafer, 2.54mm,6x1 6-pin C connector (Bottom) Wafer, 2.54mm,6x1 6-pin RoBoard Module RM-G212 The Heart of Robotics www.RoBoard.com... -
Page 9: Pin Assignments
2.3 Pin Assignments J1: I C connector (Top) Pin # Signal Name Vcc (Red) GND (Black) SCL (Blue) SDA (Green) X (White) X (Orange ) J2: I C connector (Bottom) Pin # Signal Name Vcc (Red) GND (Black) SCL (Blue) SDA (Green) X (White) X (Orange ) -
Page 10: Chapter 3
C h a p t e r Development Note Sample and development code The RM-G212 provides sample and development code. Please download from official website: http://www.roboard.com Warranty This product is warranted to be in good working order for a period of one year from the date of purchase.
