Summary of Contents for Erickson 07492
- Page 2 Item no : 07492 MANUFACTURING LTD. HITCH MOUNT BICYCLE CARRIER INSTRUCTION STEP 1 (5/8”) Hardware Needed: Qty 1: Pin (Part #16) Qty 1: “R” Pin (Part #17) (1/2” x 4”) See figure #1 below. Attach turn elbow plate (Part #22) onto hitch base (Part #23) using M16X90 bolt (5/8”...
- Page 3 Item no : 07492 Item no : 07492 MANUFACTURING LTD. STEP 3: Attach Top Support Plate (1/2”) Hardware Needed: Qty 1: Elbow Support Part (Part #24) Qty 1: Bolt M10 (3/8”) (Part #1) Qty 1: 10 spring washer (Part #2)
- Page 4 Limits of implied Warranty and Consequential Damage Erickson Manufacturing Ltd. disclaims any obligation to cover any loss time, use of this product, freight, or any incidental or consequential claim by anyone from using this product. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
