- Page 1 ASSEMBLY GUIDE Haruki Entertainment Unit...
- Page 2 Components Upon unpacking your entertainment unit from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new entertainment unit. Hardware Top panel x 1 A x 4 Spec: Ø8 x 30mm Right side panel x 1 B x 4...
- Page 3 Step 1 Insert a dowel into the holes on both sides of the drawer box unit as shown below. Insert the cam screws into the side panels (4 & 5) along the bottom on either side and using the pozi screwdriver to tighten in place.
- Page 4 Step 2 Stand the drawer box unit in a vertical position and align side panels (4 & 5) one by one to their corresponding sides, making sure all the dowels and cam screws align to their correct holes and rmly press together. Insert the cam locks into the holes along the C x 4...
- Page 5 Step 3 Align the structure assembled in Step 2 to the underside of the top panel so all corresponding holes match. Insert a bolt into each hole and screw into place to secure the side panels (4 & 5) to the top panel (6). Use the allen key to tighten all bolts.
- Page 6 Step 4 e following steps are to intruct how to remove and insert the drawers. To remove the drawers, pull them out one by one and unlock by lifting up both locking pads located on either side of the drawers and then remove it. To insert the drawers, align it to the unit one by one and push back inside and once the drawer is in place the locking pads on both sides will automatically lock.
