- Page 1 ASSEMBLY GUIDE Hans Narrow Bookcase...
-
Page 2: Table Of Contents
Components Upon unpacking your storage from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new storage. Leg x 4 Body x 1 Shelf x 3 Hardware A x 4 B x 4 C x 4 D x 4... -
Page 3: A X 4
Insert the cross dowel into the top hole of the leg Step 1 so that the side marker faces the bolt hole. Repeat for all four legs. A x 4 Screw the threaded bolt into the corner hole. Step 2 Repeat for all four legs. -
Page 4: C X 4
Place the storage body on on it’s back. Insert a Step 3 leg construction formed in previous steps into a corner opening. Fit a washer (C), a lock washer then a hex nut to the threaded bold and tighten with the spanner (F). Repeat for the remaining legs. With help of the assistant, carefully stand the unit uptight. - Page 5 Insert a pair of shelf supports into the holes of the Step 4 storage compartment. Make sure that all supports are on the same level. Insert the shelf into the opening. Lower the shelf until it rests securely on all four supports.
- Page 6 Turn the twist inside of the drawer to adjust it’s ver- Step 5 tical position, so that there are exqual gaps above and below the front wall. +2.5 -2.5...
- Page 7 To take the drawer out, open it, pull out the Lock Step 6 button inside of the drawer. Gently lift the front part of of the drawer.
- Page 8 To put the drawer back in, attach the connector in Step 7 the back of the drawer. Gently put down the front part of of the drawer so that the front connectors attach. Push back the Lock button inside of the drawer.
-
Page 9: Aa X 2
Fix a mounting plate (aa) to the back of the storage Step 8 using at head screws (cc). By using appropriate fastener based upon wall com- position, x another mounting plate (aa) to the wall. Connect two plates with the nylon srap (bb). Tighten the strap so that the table is xed in the place. - Page 10 Enjoy your new storage! Step 9...
