- Page 1 ASSEMBLY GUIDE Haruki Extendable Table...
- Page 2 Components Upon unpacking your table from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new table. Corovin storage bag x 1 Table top x 1 Leaf x 1 Type - 1 x 1 Type - 2 x 1 Type - 3 x 1...
- Page 3 Step 1 Insert a steel dowel into each of the holes along the top of each leg (4, 5, 6 & 7) and secure into place by screwing the ttings. Make sure that the direction of the holes on the ttings are facing the correct way as shown in the diagram.
- Page 4 Step 2 Align the end apron to legs (6 & 7) so that the steel dowels t inside the holes of the end apron and rmly press together. Insert a grub screw in each of the four holes on the end apron and use the allen key to tighten.
- Page 5 Step 4 Align the structure assembled in Step 2 to the underside of the table top as shown so that the steel dowels t inside the corresponding holes. Insert a grub screw into the two holes on each side of the structure and use the allen key to tighten.
- Page 6 Step 5 Secure end apron to the table top using the round head screws as shown in the diagram. You will need a phillips head screw driver to x them into place. Align the structure assembled in Step 3 to the underside of the table top as shown so that the steel dowels...
- Page 7 Step 6 Ensure that you have already locked the slides in Step 4 before righting the table. Please note that when moving the table you must remove the leaf, close the table top and lock the slides before shifting. Enjoy your new table! Step 7 e following steps are instrustions on how to extend your table.
- Page 8 Step 8 Unlock the slides that were locked in Step 4. Extend the table by lifting the end apron, positioned behind the front rail, then slide the structure all the way out as shown. Step 9 Align the leaf over the side aprons so that the metal pins on the leaf are facing toward the front rail and carefully slide it to connect with the front rail.
- Page 9 Step 10 To close the table lift the end apron, positioned behind the front rail, then slide the structure all the way in, making sure that the holes on the leaf are aligned and to the pins on the table top. Step 11 Enusre that you have locked the slides after closing the table as shown.
- Page 10 Step 12 To remove the leaf unlock the slides that were locked Step 11 and extend the table by lifting the end apron, positioned behind the front rail, then slide the structure all the way out. Gently remove the leaf (3). Step 13 Fold both leaf aprons at and then place the leaf into...
- Page 11 Step 14 14.1 Carefully place the leaf (3) onto the wood support storage under the table top as shown. 14.2 Close the table by lifting the end apron, positioned behind the front rail, then slide the structure all the way in as shown, making sure the holes on the front rail are aligned to the pins on the table top.
