- Page 1 ASSEMBLY GUIDE Hans Sideboard...
- Page 2 Components Upon unpacking your storage from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new storage. Leg x 4 Shelf x 3 Central Leg x 1 Body x 1 Hardware A x 4 B x 4...
- Page 3 Insert the cross dowel into the top hole of the leg Step 1 so that the side marker faces the bolt hole. Repeat for all four legs. A x 4 Screw the threaded bolt into the corner hole. Step 2 Repeat for all four legs.
- Page 4 Place the storage body on on it’s back. Insert a Step 3 leg construction formed in previous steps into a corner opening. Fit a washer (C), a lock washer then a hex nut to the threaded bold and tighten with the spanner (F). Repeat for the remaining legs. Screw central leg onto the metal plate.
- Page 5 Insert a pair of shelf supports into the holes on Step 4 the one side of the storage compartment. Make sure that both supports are on the same level. Tilt the shelf so it ts into the opening. Insert the shelf and rest on the supports.
- Page 6 Step 5 hinges if needed. Vertical adjustment via slots on mounting plate by slackening and retightening the screws on the mounting plate. Lateral adjustment by screw adjustent. Front-to-Back adjustment by slackening and retightening the hinge-arm mounting screw. Step 5.2 Step 5.1 Step 5.3...
- Page 7 Turn the twist inside of the drawer to adjust it’s ver- Step 6 tical position, so that there are exqual gaps above and below the front wall. +2.5 -2.5...
- Page 8 To take the drawer out, open it, pull out the Lock Step 7 button inside of the drawer. Gently lift the front part of of the drawer.
- Page 9 To put the drawer back in, attach the connector in Step 8 the back of the drawer. Gently put down the front part of of the drawer so that the front connectors attach. Push back the Lock button inside of the drawer.
- Page 10 Fix a mounting plate (aa) to the back of the storage Step 9 using at head screws (cc). By using appropriate fastener based upon wall com- position, x another mounting plate (aa) to the wall. Connect two plates with the nylon srap (bb). Tighten the strap so that the table is xed in the place.
- Page 11 Enjoy your new storage! Step 10...
