- Page 1 ASSEMBLY GUIDE Parc Sideboard...
- Page 2 Components Upon unpacking your sideboard from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new sideboard. Sideboard x 1 Leg x 4 Hardware What you need A x 8 B x 8 C x 4 Spec: 5/16 x 60mm...
- Page 3 Align a leg to the underside of the sideboard Step 1 that the screw holes are overlapping. Fit a washer to a bolt and screw into a hole and repeat for the other bolt to secure the leg in place. Repeat process for the remaining legs and use the allen key tighten all of the bolts (A).
- Page 4 Align a strap to the back of the sideboard and secure Step 3 in place with a screw (F). Repeat for the other strap (H). F x 2 H x 2 At the location where the sideboard will be placed, Step 4 mark out two holes along the wall where you’ll secure the straps.
- Page 5 e sideboard is 120cm wide by 82cm high and 47cm Step 5 deep and can take up to 60kg maximum weight on top and 5kg inside each draw. Enjoy your new sideboard! 60KG...
