- Page 1 ASSEMBLY GUIDE Prato Chest of Drawers...
-
Page 2: What You Need
Components Before you get started, check you have all of the pieces below. If anything’s missing, please visit www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it out right away. Central Leg x 1 Body x 1 Leg x 4 Hardware A x 16... - Page 3 Align a leg to the underside of the body so that the screw Step 1 holes are overlapping. Fit a washer to a bolt and screw into a hole using a screwdriver. Repeat for the other legs and the central leg. Peel o the sticker paper and cover end of the legs with the trim caps (C).
- Page 4 Align the drawer slides to the corresponding holes Step 2 on the side walls. Secure into place using small screws (H). D x 6 Continue using the screws to secure the slides. Step 3 D x 4...
- Page 5 Align the end hole on the drawer with the hook on the Step 4 slide and insert the drawer halfway into the cabinet. Pull the side lock out. Step 5...
- Page 6 Alight the vertical knob on the slide with the hole on Step 6 the drawer and lift the drawer down. Pull back the side lock to x the drawer on the slide Step 7 and close the drawer.
- Page 7 Follow those steps to remove the drawer from the Step 8 storage. Open the drawer, open the lock to the side, pull the second lock up and take out the drawer (4). Repeat the steps in reverse order to put the drawer back in it’s place.
- Page 8 Rotate the knob on the side of the drawer to adjust Step 9 the correct angle. ±2mm...
- Page 9 Use both hands to open and close the drawers. Step 10 Enjoy your new storage! Step 11...
