- Page 1 ASSEMBLY GUIDE Parc Media Unit...
- Page 2 Components Upon unpacking your media unit from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new media unit. Media unit x 1 Leg x 4 Hardware What you need A x 8 B x 8 C x 2...
- Page 3 Align a leg to the underside of the media unit Step 1 so that the screw holes are overlapping. Fit a washer to a bolt and screw into a hole and repeat for the other bolt to secure the leg in place. Repeat process for the remaining legs and use the allen to tighten all of the bolts (A).
- Page 4 e media unit is 100cm wide by 52cm high and 43cm Step 3 deep and can take up to 60kg maximum weight on top and 5kg inside each draw. Enjoy your new media unit! 60KG...
