Ruijie RG-EG Series Routers Hardware Installation and Reference Guide
Voltage
Power Consumption
Working
Temperature
Working Humidity
Please avoid the vibration and collision in the process of moving and usage.
Products should be transported in original package.
RG-EG105G is a Class-A product which may cause radio interference in the living environment. In such a case, the
user may need to take feasible measures against such interference.
Appearance
Figure 1-3 Front Panel of RG-EG105G
Figure 1-4 Back Panel of RG-EG105G
Interface
Interface
WAN
LAN
LED Indicator
LED Indicator
Status
Link/ACT
100V to 240V~, 50/60Hz, 1.5A max.
Less than 6W
0° C to 40° C (32° F to 104° F)
10% to 90% RH (non-condensing)
Description
1 WAN port, used to connect to the DSL/Cable modem for Internet access.
4 LAN ports, used to connect the computer to the switch. The LAN3 port can be
used as a WAN port via the Web configuration.
Description
Blinking green (0.5Hz): The device has started up, but is not connected to the
Ruijie Cloud.
Solid green: The device has started up, and is connected to the Ruijie Cloud.
Blinking green (10Hz): The device is starting up/shutting down.
Solid green: the port is up.
Blinking green: data is being transceived on the port.
Product Overview
