Sanus Systems Vuepoint HTB7 Assembly Instructions

Assembly Instructions for model: HTB7 Speaker Stands
Thank you for choosing Vuepoint™ speaker stands. These stands are designed to support satellite speakers up to 4 lb. each.
If you have any questions regarding this or any other Sanus Systems product, please contact us at 800.359.5520 or visit
www.sanus.com. Check carefully to make sure you have all the parts listed below. Our customer service representatives
can quickly assist you with any issues regarding assembly or missing parts. Replacement parts for products purchased from
an authorized dealer will be shipped directly to you. Please call Sanus Systems before returning products to the point of
.
purchase

Supplied Parts:

(2) Base - a
(2) Flat Head Bolt - d
(2) L Bracket - g
(2) Double Bolt Bracket - j

Step 1: Remove the backing and add 3 Felt Pads

(m) to the bottom of each Base (a) as shown in
Diagram 1 below.
Diagram 1
Customer Service: 800.359.5520. See complimentary Sanus products at www.sanus.com
(2) Lower Pillar - b
(4) 1/4 - 20 Speaker
Attachment Bolt - k
m
Sanus Systems 2221 Hwy 36 W, Saint Paul, MN 55113 04.15.05
(2) Top Plate - e
(2) Knob - h
(2) M5 Speaker
Attachment Bolt - l
(2) Upper Pillar Assembly - c
(2) Double Stick Pad - f
(2) Keyhole Bolt - i
(6) Felt Pad - m
