Surge Brake Trailer
Safety, Operation, Maintenance
& Parts Manual
TRB-S
1992 Model Sawmills
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
February 1999
Form #710

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRB-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wood-mizer TRB-S

Summary of Contents for Wood-mizer TRB-S

  • Page 1 Surge Brake Trailer Safety, Operation, Maintenance & Parts Manual TRB-S 1992 Model Sawmills Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. February 1999 Form #710...

  • Page 2: Table Of Contents

    Table of Contents Section-Page SECTION 1 SAFETY & GENERAL INFORMATION SECTION 2 SURGE BRAKE HITCH OPERATION SECTION 3 SURGE BRAKE HITCH MAINTENANCE SECTION 4 PARTS LISTS Trailer Hitch Assembly (LT25/LT30 Surge Brake)..........4-1 Trailer Hitch Assembly (LT40/30HD/40HD Surge Brake) ........4-3 Trailer Axle Assembly (Surge Brake)...............

  • Page 3: Safety & General Information

    The word regarding the ownership, operation and towing DANGER refers to hazards that can cause of your Wood-Mizer sawmill. All Wood-Mizer death or serious, irreversible personal injury. mill owners are encouraged to become thor- The word WARNING suggests a safety hazard oughly familiar with these applicable laws and that can cause personal injury.

  • Page 4: Surge Brake Hitch Operation

    Surge Brake Hitch Operation SECTION 2 SURGE BRAKE DANGER! Do not use eyebolts for safety chain hook-up. Safety chains should be hooked to HITCH OPERATION bumper of vehicle so that each chain would pull the trailer equally in the event the hitch became Pull the mill behind the towing vehicle and disengaged.

  • Page 5: Surge Brake Hitch Maintenance

    Surge Brake Hitch Maintenance SECTION 3 SURGE BRAKE HITCH MAINTENANCE Clean and repack the trailer axle wheel bearings with lithium grease every 12 months or 12,000 miles (19,308 km), whichever comes first. Make sure that the trailer tires are correctly inflated to the pressure shown on the tire.

  • Page 6: Parts Lists

    Parts Lists Trailer Hitch Assembly (LT25/LT30 Surge Brake) SECTION 4 PARTS LISTS Trailer Hitch Assembly (LT25/LT30 Surge Brake) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. HITCH ASSEMBLY,SURGE BRAKE TRAILER A10405 Hitch Mount (W/O Spacer Blocks), Surge Brake Trailer W09828 Hitch Mount (With Spacer Blocks), Surge Brake Trailer W10404...
  • Page 7 Parts Lists Trailer Hitch Assembly (LT25/LT30 Surge Brake) FIG. 4-1 Parts Lists SB92doc041614...

  • Page 8: Trailer Hitch Assembly (Lt40/30Hd/40Hd Surge Brake)

    Parts Lists Trailer Hitch Assembly (LT40/30HD/40HD Surge Brake) Trailer Hitch Assembly (LT40/30HD/40HD Surge Brake) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. HITCH KIT, SURGE BRAKE TRAILER K10403 Hitch Mount (W/O Spacer Blocks), Surge Brake Trailer W09827 Hitch Mount (With Spacer Blocks), Surge Brake Trailer W10401 Actuator, Dico Surge Brake Hitch...
  • Page 9 Parts Lists Trailer Hitch Assembly (LT40/30HD/40HD Surge Brake) FIG. 4-2 Parts Lists SB92doc041614...

  • Page 10: Trailer Axle Assembly (Surge Brake)

    Parts Lists Trailer Axle Assembly (Surge Brake) Trailer Axle Assembly (Surge Brake) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. AXLE ASSEMBLY, 3500# NON-BRAKE 014684  Frame, Trailer Axle W09751 Mount Bracket, Trailer Fender W09784 Axle, 3500 Lb With Springs And Surge Brakes P09772 Spring, 2000lb Dexter Leaf Idle Side Rpl P09612...
  • Page 11 Parts Lists Trailer Axle Assembly (Surge Brake) SM0083F FIG. 4-3 Parts Lists SB92doc070517...

  • Page 12: Outrigger Assembly (Long)

    Parts Lists Outrigger Assembly (Long) Outrigger Assembly (Long) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. OUTRIGGER ASSEMBLY, LONG A04287 Guide, Long Outrigger Guide W09011 Leg, Outrigger W07537 Cap, Outrigger Leg P09926 Spring, Outrigger Pin P04282 Washer, 9/16" SAE Flat F05011-8 Pin Kit, Outrigger Pull A12232...
  • Page 13 Parts Lists Outrigger Assembly (Long) FIG. 4-4 Parts Lists SB92doc041614...

  • Page 14: Outrigger Assembly (Short Front)

    Parts Lists Outrigger Assembly (Short Front) Outrigger Assembly (Short Front) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. OUTRIGGER ASSEMBLY, SHORT FRONT A04278 Guide, Short Front Outrigger Guide W09012 Leg, Outrigger W07537 Cap, Outrigger Leg P09926 Spring, Outrigger Pin P04282 Washer, 9/16"...
  • Page 15 Parts Lists Outrigger Assembly (Short Front) SM0087B FIG. 4-5 Parts Lists SB92doc041614 4-10...

  • Page 16: Outrigger Assembly (Lt25/Lt30/Lt40 Short Rear)

    Parts Lists Outrigger Assembly (LT25/LT30/LT40 Short Rear) Outrigger Assembly (LT25/LT30/LT40 Short Rear) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. OUTRIGGER ASSEMBLY, SHORT REAR A09475 Guide, Short Rear Outrigger Guide W09474 Leg, Outrigger W07537 Cap, Outrigger Leg P09926 Spring, Outrigger Pin P04282...
  • Page 17 Parts Lists Outrigger Assembly (LT25/LT30/LT40 Short Rear) SM0088B FIG. 4-6 Parts Lists SB92doc041614 4-12...

  • Page 18: Outrigger Assembly (Lt30Hd/Lt40Hd Short Rear)

    Parts Lists Outrigger Assembly (LT30HD/LT40HD Short Rear) Outrigger Assembly (LT30HD/LT40HD Short Rear) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. OUTRIGGER GUIDE ASSEMBLY, HD SHORT REAR A09276 Guide Weldment, Outrigger Leg w/Saw Head Rest Pin W09275  Spring, Outrigger Pin P04282 Washer, 9/16"...
  • Page 19 Parts Lists Outrigger Assembly (LT30HD/LT40HD Short Rear) HD0044-1 FIG. 4-7 Parts Lists SB92doc041614 4-14...

  • Page 20: Outrigger Assembly (Lt25L/Lt40 /Lt40Hd Rear)

    Parts Lists Outrigger Assembly (LT25L/LT40 /LT40HD Rear) Outrigger Assembly (LT25L/LT40 /LT40HD Rear) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. OUTRIGGER ASSEMBLY, LT40 REAR A12083 Guide, Short Rear Outrigger Guide W12082 Leg, Outrigger W07537 Cap, Outrigger Leg P09926 Spring, Outrigger Pin P04282...
  • Page 21 Parts Lists Outrigger Assembly (LT25L/LT40 /LT40HD Rear) 3H0132D FIG. 4-8 Parts Lists SB92doc041614 4-16...

  • Page 22: Trailer Lights (Clip-On Tail Light Lens)

    Parts Lists Trailer Lights (Clip-on Tail Light Lens) Trailer Lights (Clip-on Tail Light Lens) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. PLUG, TRAILER LIGHT MALE P04159 PLUG, TRAILER LIGHT FEMALE P04983 LIGHT ASSEMBLY, TRAILER TAIL P04294 Lens, Grote Tail Light #90012 P12509 Bulb, #1157 Trailer Light...
  • Page 23 Parts Lists Trailer Lights (Clip-on Tail Light Lens) FIG. 4-9 Parts Lists SB92doc041614 4-18...

  • Page 24: Log Loading Ramps (Lt25/Lt30/Lt40)

    Parts Lists Log Loading Ramps (LT25/LT30/LT40) 4.10 Log Loading Ramps (LT25/LT30/LT40) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. RAMP KIT, LOG LOADING WITH RETAINERS K09466 Ramp, Log Loading W09014 Retainer Kit, Log Ramp K09810 Retainer, Log Ramp W09413 ...

  • Page 25: Outrigger Pin Hardware (3/4" Dia.)

    Parts Lists Outrigger Pin Hardware (3/4” Dia.) 4.11 Outrigger Pin Hardware (3/4” Dia.) DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. SPRING, OUTRIGGER PIN 016145 WASHER, 3/4" SAE FLAT F05011-62 PIN KIT, 3/4” OUTRIGGER PULL 016148 Pin, 3/4” Outrigger Pull 016147 ...
