Summary of Contents for Speco O6MDP3
- Page 1 Quick Start Guide O6MDP3...
- Page 2 This owner's manual is designed to be a reference tool for your system. Please read this manual carefully before operating the unit and retain it for future reference. Should you require any technical assistance, contact Speco Technologies Tech Support at 1-800-645-5516 Important Safeguards and Warning 1.
- Page 3 Technologies reserves the right to modify these without notice and without incurring any obligation. Speco Technologies is not liable for any loss caused by improper operation. Note: Before installation, check the package and make sure that all components are included.
- Page 4 × 3 Tapping screws ×3 Junction box Plastic plug Overview 1 Ethernet Connector 2 MIC IN 3 HP Audio Output 4 Video Output 5 Alarm Input/Output 6 RS485 7 DC12V Power Supply 8 SD Card Slot 9 Reset ALM-COM ALM-OPEN ALM-INA ALM-GND DC12V...
- Page 5 * 1 It is recommended to install the security cap for outdoor installations. * 2 DC 12V power supply is not required if a PoE switch or injector is used to power the camera. ● Connecting Network Cable ① Loosen the nut from the main element. ②...
- Page 6 Fixed Ring ② Install the junction box onto the wall. ③ Route the cables through the cable hole (take side conduit cabling for example) and connect the cables. Then fix the camera onto the junction box with screws.
- Page 7 Rubber plug ④ Install the fixed ring back to finish the installation. Web Operation and Login IP Scanner can search for the device on the local network. ● Operation ① Make sure that the camera and the PC are connected to the same local network.
- Page 8 ② Install IP Scanner from the CD and run it after installation. 5C:F2:07:24:68:B9 O6MDP3 ③ In the device list, you can view the IP address, model number, and MAC address of each device. Select the applicable device and double click to open up the web viewer. You can also manually enter the IP address in the address bar of the web browser (Internet Explorer 8.0 and up).
