Speco O6MDP4 User Manual

6mp fisheye network camera
Hide thumbs Also See for O6MDP4:

Advertisement

Quick Links

Download this manual
User Manual
6MP Fisheye Network Camera
O6MDP4
Please read this instruction carefully before operating the unit and keep it for further reference

Advertisement

loading
Need help?

Need help?

Do you have a question about the O6MDP4 and is the answer not in the manual?

Questions and answers

Related Manuals for Speco O6MDP4

Summary of Contents for Speco O6MDP4

  • Page 1 User Manual 6MP Fisheye Network Camera O6MDP4 Please read this instruction carefully before operating the unit and keep it for further reference...
  • Page 2 Important Safeguards and Warnings 1. Electrical safety All installation and operation here should conform to local electrical safety codes. Use a certified/listed 12VDC Class2 power supply or adequate PoE switch. Improper handling and/or installation could run the risk of fire or electrical shock. 2.
  • Page 3 Statement This guide is for reference only. Product, manuals and specifications may be modified without prior notice. Speco Technologies reserves the right to modify these without notice and without incurring any obligation. Speco Technologies is not liable for any loss caused by improper operation.
  • Page 4 Table of Contents Introduction ..........................................2 Web Access and Login ......................................3 Live View..........................................5 Camera Configuration ......................................9 System Configuration ................................9 4.1.1 System Information ..............................9 4.1.2 Date and Time ................................9 4.1.3 Local Recording .................................10 4.1.4 Storage ..................................10 4.1.5 Configuring Fisheye Parameters ..........................12 Video Configuration ................................12...
  • Page 5 4.5.3 Block and Allow Lists ..............................41 4.5.4 Security Management...............................42 Maintenance Configuration ..............................43 4.6.1 Backup and Restore ..............................43 4.6.2 Reboot ..................................44 4.6.3 Upgrade ..................................44 4.6.4 Operation Log ................................44 4.6.5 Debug Mode ................................45 Search ............................................ 46 Image Search ..................................46 Video Search ..................................47 Appendix ............................................
  • Page 6 Thank you for purchasing this network camera! Please read this manual carefully before operating the unit and retain it for further reference. Should you require any technical assistance, please contact Speco Technologies Technical Support at 1-800-645-5516. Main Features  Built-in PoE (Power over Ethernet) ...
  • Page 7 IP address by the DHCP server. Make sure that the local network has a DHCP server. Routers typically have a DHCP server built in. ② Install Speco Blue Scanner and run it after installation. Speco Blue Scanner is the tool for discovering the IP cameras on the local network. It can be downloaded from www.specotech.com.
  • Page 9 3 Live View The window below will be shown after logging in. Before you view the live image, please set the stream mode and installation method as needed (see Configuring Fisheye Parameters for details). The following table describes the icons on the live view interface. Icon Description Icon...
  • Page 10 Fisheye+ 3PTZ view mode Panoramic + 3PTZ view mode 4PTZ view mode (you need to switch the stream mode in the fisheye parameter interface)
  • Page 11 4PTZ fusion view mode: you can view an entire picture formed by 4 small windows. Each small window cannot be controlled by PTZ panel. In panoramic + 3PTZ view mode or fisheye + 3PTZ view mode or 4PTZ view mode, select a PTZ window and view the image from every direction by controlling PTZ panel.
  • Page 12 2. Click to create a cruise. In the cruise creation window, enter the cruise name and then click “Add preset”. 3. In the preset adding window, select the preset name and time. Click “OK” to add this preset. After the presets are added to the cruise, click “OK”...
  • Page 13 4 Camera Configuration Press the “Setup” button to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 4.1 System Configuration 4.1.1 System Information In the “System Information” interface, the system information of the device is listed. 4.1.2 Date and Time To set the time and date, go to SystemDate and Time.
  • Page 14 4.1.3 Local Recording Go to SystemLocal Recording to set up the storage path of captured pictures and recorded videos on the local PC. There is also an option to enable or disable audio in the recorded files. Show Bitrate: enable or disable the bitrate display on the live video. Additionally, the snapshots triggered by smart events can be selected to save to the local PC.
  • Page 15 Weekly schedule Set the alarm time from Monday to Sunday for a single week. Each day is divided in one hour increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline. “Erase”: Delete the schedule.
  • Page 16 Timing Snapshot: Enable timing snapshot first and then set the snapshot interval and schedule. The setup steps of schedule are the same as the schedule recording (See Schedule Recording).  FTP Snapshot Settings If enabled, the system will upload snapshots to the FTP server according to the time interval. Server Address: select the set FTP server.
  • Page 17 Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Hue: Set the total color degree of the image. Saturation: Set the degree of color purity. The purer the color, the brighter the image is. Sharpness: Set the resolution level of the image plane and the sharpness level of the image edge.
  • Page 18 Image Flip: Turn the current video image vertically. Note: For some items, if selected/enabled, the camera will reboot automatically. After that, clicking “Default” button will not take effect. Schedule Settings of Image Parameters: Click the “Profile Management” tab as shown below. Set full time schedule for common, auto mode and specified time schedule for day and night.
  • Page 19 IP Channel 2: Panoramic view channel, 3 streams can be set. Please set them according to the actual network condition. IP Channel 3/4/5: PTZ view channel, main stream can be set for each channel. Please set them according to the actual network condition.
  • Page 20 Set time stamp, device name, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position. Then click the “Save” button to save the settings. Picture Overlap Settings: Check “OSD Content1”, choose “Picture Overlay” and click to select the overlap picture.
  • Page 21 To clear the video mask: Click the “Clear” button to delete the current video mask area. 4.2.5 ROI Configuration Go to ImageRegion of Interest interface as shown below. An area in the image can be set as a region of interest. This area will have a higher bitrate than the rest of the image, resulting in better image quality for the identified area.
  • Page 22 1. Check “Enable” check box to activate motion based alarms. If unchecked, the camera will not send out any signals to trigger motion-based recording to the NVR or CMS, even if there is motion in the video. Alarm Out: If selected, this would trigger an external relay output that is connected to the camera on detecting a motion based alarm.
  • Page 23 2. Click “Enable” and set the alarm holding time. 3. Set alarm trigger options. The setup steps are the same as motion detection. Please refer to motion detection chapter for details.  SD Card Error When there are some errors in writing SD card, the corresponding alarms will be triggered. 1.
  • Page 24 2. Click “Enable alarm” and set the alarm holding time. 3. Trigger alarm out. When the IP address of the camera is in conflict with the IP address of other devices, the system will trigger the alarm out.  Cable Disconnection 1.
  • Page 25 1. Click “Enable” and set the alarm type, alarm holding time and sensor name. 2. Set alarm trigger options. The setup steps are the same as motion detection. Please refer to motion detection chapter for details. 3. Click “Save” button to save the settings. 4.
  • Page 26 Day/Night Switch Linkage: Having selected this mode, select the alarm type and choose to open or close alarm out when the camera switches to day mode or night mode. Timing: Select the alarm type. Then click “Add” and drag the mouse on the timeline to set the schedule of alarm out; click “Erase” and drag the mouse on the timeline to erase the set time schedule.
  • Page 27 At any time of day or night, please make sure the image of the camera is clear and with adequate and even light, avoiding  overexposure or too much darkness on both sides. Note: Events may vary by different installation methods and stream modes. Go to ConfigSystemFisheye Parameters to set the stream mode and installation method.
  • Page 28 Note: To save images to a local PC, please enable the local smart snapshot storage first (SystemLocal Recording). To save images to an SD card, please install an SD card first. Detection Target: Human: Select it and then alarms will be triggered if someone crosses the pre-defined alarm line. Motor Vehicle: Select it and then alarms will be triggered if a vehicle with four or more wheels (eg.
  • Page 29 5. The detected objects should not be less than 1% of the entire image and the largest sizes of the detected objects should not be more than 1/8 of the entire image. 6. Make sure cameras can view objects for at least 2 seconds in the detected area for accurate detection. 7.
  • Page 30 Non-motor Vehicle: Select it and then alarms will be triggered if a vehicle with two wheels (eg. a motorcycle or bicycle) intrudes into the pre-defined area. Note: When the installation method is set to “Ceiling”, only “Human” can be selected. All of the three types of objects can be selected simultaneously.
  • Page 31 3. Set the alarm area of the region entrance detection. 4. Set the schedule of the region entrance detection. The setup steps of the region entrance detection are the same as the region intrusion detection setup (See Region Intrusion for details).
  • Page 32 Push target trajectory with a persistent connection: Push target trajectory (moving coordinate) to API test tool with a persistent connection. If enabled, the system will push the target trajectory upon detecting a target. If disabled, the system will push the target trajectory only when triggering target counting by line.
  • Page 33 Enable the crowd density detection. Set “Refresh Frequency”, “Density Alarm Threshold” and “Alarm Holding Time”. Refresh Frequency: The refresh frequency of the detection result. Density Alarm Threshold: Alarms will be triggered once the percentage of the crowd density in a specified area exceeds the pre-defined threshold value.
  • Page 34 Note: The camera only can roughly calculate the crowd density through detecting the human faces. The head or back of the person detected is not counted. ※Configuration of camera and surrounding area 1. The camera lens should face to the people flow. 2.
  • Page 35 4.4 Network Configuration 4.4.1 TCP/IP Go to NetworkTCP/IP interface as shown below. There are two ways for network connection. Use IP address (take IPv4 for example)-obtain a local IP address automatically through DHCP. A typical router has a DHCP server built in, and therefore is able to assign an IP address to the camera.
  • Page 36 Trigger Email: when the IP address of the device is changed, the new IP address will be sent to the email address that has been set Trigger FTP: when the IP address of the device is changed, the new IP address will be sent to FTP server that has been set up. 4.4.2 Port Go to NetworkAdvanced interface as shown below.
  • Page 37 3. Enter the above-mentioned server address, server port and device ID in the corresponding boxes. Click the “Save” button to save the settings. 4.4.4 Onvif The camera can be searched and connected to the third-party platform via ONVIF/RTSP protocol. Note: when adding the device to the third-party platform with ONVIF/RTSP protocol, please enter the username and password created in the above interface.
  • Page 38 4.4.6 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used. Before using SNMP, please install an SNMP management tool and set the parameters of the SNMP, such as SNMP port, trap address. 1.
  • Page 39 4.4.7 802.1x If it is enabled, the camera’s data can be protected. When the camera is connected to the network protected by the IEE802.1x, user authentication is needed. To use this function, the camera shall be connected to a switch supporting 802.1x protocol. The switch can be reckoned as an authentication system to identify the device in a local network.
  • Page 40 “rtsp://IP address: rtsp port/profile3?transportmode=mcast”. Audio: Having entered the main/sub stream in a media player(like VLC), the video and audio will play automatically. If “Allow anonymous login…” is checked, there is no need to enter the username and password to view the video. If “auto start”...
  • Page 41 Click “Edit and Test” to set the sender and the recipient. Sender Address: sender’s e-mail address. User name and password: sender’s user name and password. Server Address: The SMTP IP address or host name. Select the secure connection type at the “Secure Connection” pull-down list according to what’s required. SMTP Port: The SMTP port.
  • Page 42 Server Name: The name of the FTP server. Server Address: The IP address or domain name of the FTP. Upload Path: The directory where files will be uploaded to. Port: The port of the FTP server. Use Name and Password: The username and password that are used to login to the FTP server. 4.4.13 HTTP POST Go to ConfigNetwork HTTP POST interface.
  • Page 43 * If there is a signed certificate, click “Browse” to select it and then click “Install” to install it. * Click “Create a private certificate” to enter the following creation interface. Click the “Create” button to create a private certificate. Enter the country (only two letters available), domain (camera’s IP address/domain), validity date, password, province/state, region and so on.
  • Page 44 Alarm DSCP: The range is from 0 to 63. Manager DSCP: The range is from 0 to 63. Generally speaking, the larger the number is, the higher the priority is. 4.5 Security Configuration 4.5.1 User Admin Go to SecurityUser Admin interface as shown below. Add user: 1.
  • Page 45 3. Enter the old password of the user in the “Old Password” text box. 4. Enter the new password in the “New password” and “Confirm Password” text box. 5. Select the user permissions for advanced or normal user. 6. Click the “OK” button to save the settings. Delete user: 1.
  • Page 46 The setup steps are as follows: Check the “Enable address filtering” check box. Select “Block/Allow the following address”, IPv4/IPv6 and then enter IP address in the address box and click the “Add” button. 4.5.4 Security Management Go to SecuritySecurity Management as shown below. In order to prevent against malicious password unlocking, “locking once illegal login”...
  • Page 47 4.6 Maintenance Configuration 4.6.1 Backup and Restore Go to MaintenanceBackup & Restore. Import & Export Settings  Configuration settings of the camera can be exported form a camera into another camera. 1. Click “Browse” to select the save path for import or export information on the PC. 2.
  • Page 48 4.6.2 Reboot Go to ConfigMaintenanceReboot. Click the “Reboot” button and then enter the password to reboot the device. Timed Reboot Setting: If necessary, the camera can be set up to reboot on a time interval. Enable “Time Settings”, set the date and time, click the “Save” button and then enter the password to save the settings.
  • Page 49 2. Select the main type, sub type, start and end time. 3. Click “Search” to view the operation log. 4. Click “Export” to export the operation log. 4.6.5 Debug Mode Debug Mode is used to record and collect the required system data, so that the technician can quickly find out and analyze the problem, and help us to improve service.
  • Page 50 5 Search 5.1 Image Search In the Setup interface, click Search to go to the interface as shown below. Images that are saved on the PC or SD card can be found here.  SD Card Image Search 1. Choose “Picture”. 2.
  • Page 51 Icon Description Icon Description Zoom in: Click this button to Zoom out: Click this button to digitally digitally zoom in. zoom out. Slide show play: Click this button Stop: Click this button to stop the slide to start the slide show mode. show.
  • Page 52 Icon Description Icon Description Speed up Watermark display Click it to play the next record. Click it to play the previous record. Enable / disable audio; drag the slider to adjust the volume after enabling audio. Note: cannot be displayed in the above interface via the plug-in free browser. Additionally, for plug-in free playback, playback mode switch (balanced/real-time/fluent mode) and downloading functions are not supported too.
  • Page 53 Appendix Appendix 1 Troubleshooting IP Scanner does not show any device. Make sure that the PC that’s running IP Scanner is on the same local network as the devices. Internet Explorer cannot download ActiveX control. IE browser may be set up to block ActiveX. Follow the steps below. 1.
  • Page 54 Models: O6MDP4 Federal Communications Commission (FCC) Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
