PSS20B2W/C
GENERATOR
INSTALLATION AND
OPERATORS MANUAL
COPY YOUR MODEL AND SERIAL NUMBER HERE
No other WINCO generator has the same serial number as yours.
If you should ever need to contact us on this unit, it will help us to
respond to your needs faster.
MODEL __________________________________________________
16200-009
SERIAL NUMBER _________________________________________
PURCHASE DATE _________________________________________
DEALER NAME ___________________________________________
DEALER PHONE # ________________________________________
Advertisement
Table of Contents
Related Manuals for Winco PSS20B2W/C
Summary of Contents for Winco PSS20B2W/C
- Page 1 OPERATORS MANUAL COPY YOUR MODEL AND SERIAL NUMBER HERE No other WINCO generator has the same serial number as yours. If you should ever need to contact us on this unit, it will help us to respond to your needs faster.
-
Page 2: Table Of Contents
FUEL PRESSURE TABLES NG/LP FUEL CONVERSION BATTERY INSTALLATION SERVICING BATTERIES BATTERY CHARGING CONNECTING BATTERY CHARGER GENERATOR CONNECTIONS WINCO UL ATS (ASCO 185) AC ELECTRICAL CONNECTIONS ASCO 185 UL SWITCH DC ELECTRICAL INTERCONNECTION 15 INITIAL START UP START UP PROCEDURE DSE 3110... -
Page 3: Save These Instructions
Should you experience a problem please follow the “Troubleshooting Tables” near the end of this manual. The warranty listed in the manual describes what you can expect from WINCO should you need service assistance in the future. 60706-229/F... -
Page 4: Safety
SAFETY IMPORTANT SAFETY INSTRUCTIONS WARNING: FIRE HAZARD This engine generator set has been designed and Gasoline and other fuels present a hazard of possible manufactured to allow safe, reliable performance. Poor explosion and/or fire. maintenance, improper or careless use can result in A. -
Page 5: Specifications
SPECIFICATIONS GENERATOR Fuel Watts* Volts Amps 17,000 120/240 70.8 3600 15,000 120/240 62.5 3600 *Continuous rating. Derate 3.5% per 1000 feet elevation above sea level. FUEL CONSUMPTION Natural Gas LP Vapor 1000 BTU/FT³ 2520 BTU/FT³ CF/HR* 130.5 BTU/HR* 328,000 329,000 GAL/HR* 3.61 *Based on full load operation. -
Page 6: Introduction
INTRODUCTION TESTING POLICY to run on LP or NG fuel. The engine operates at 3600 rpm and frequency regulation is maintained by the engine governor within 4 cycles variation (62.5 Hz - 58.5 Hz) from Before any generator is shipped from the factory, it is fully no load to rated load. -
Page 7: Preparing The Unit
1. As you receive your unit, it is critical to check it for any damage. If any damage is noted, it is always easiest to refuse the shipment and let WINCO take care of the freight claim. If you sign for the unit, the transfer of the ownership requires that you file the freight claim 2. -
Page 8: Installation
INSTALLATION WARNING: FIRE HAZARD WARNING All fuel runs should be installed by a licensed fuel supplier. Before proceeding with installation, be sure the operation selector switch is in the stop position. To connect the fuel line to the generator set you will connect your incoming fuel line to the 3/4 inch NPT fitting These engine generator sets are designed to be mounted located on the left side of the engine-generator set. -
Page 9: Natural Gas (Ng)
LP TANK SIZING Tank Temperature Tank Size 60° F (16° C) 150 Gallons 32° F (0° C) 250 Gallons 0° F (18° C) 500 Gallons -20° F (-29° C) 1000 Gallons NATURAL GAS (NG) The primary regulator (fuel meter) on the building should deliver the correct volume and pressure to the generator set. -
Page 10: Ng/Lp Fuel Conversion
Two regulator system (LP vapor only) Ref# Unit off Line PSI 10-15 lbs 7-11 in 7-11 in 4-6 oz 4-6 oz Starting Line PSI 10-15 lbs 7-11 in 7-11 in 4-6 oz 4-6 oz No load Line PSI 10-15 lbs 7-11 in 7-11 in 4-6 oz... -
Page 11: Battery Installation
BATTERY INSTALLATION CAUTION WARNING In the following battery installation procedure, check to be The electrolyte is a diluted sulfuric acid that is harmful to sure the selector switch remains in the ‘off’ position. This the skin and eyes. It is electrically conductive and corrosive, should be your last step before initial start-up. -
Page 12: Connecting Battery Charger
cable (ground) from the engine generator assembly. All NOTICE: connections must be clean and tight. Check the electrolyte The battery tender is not intended to recharge a battery (fluid) in the battery periodically to be sure it is above the which has become completely discharged. -
Page 13: Generator Connections
During all wiring installation, make sure the breaker is in the off position and the generator WINCO UL ATS (ASCO 185) operators switch is in the off position. See the ASCO installation manual for additional details on... - Page 14 the transfer switch can be wired in directly after the watt- hour meter and the service entrance, providing the service entrance ampere rating is within the transfer switch’s rated capability. If only specific circuits are to be powered under emergency power failure conditions, an additional distribution panel designated “emergency distribution panel”...
-
Page 15: Asco 185 Ul Switch
DC ELECTRICAL INTERCONNECTION CAUTION Never run the AC and DC wiring on the same conduit. ASCO 185 UL SWITCH Your DC connection points in the ASCO 185 UL ATS are on the terminal block on the bottom of the controller in the lower left hand corner of the ATS panel. -
Page 16: Initial Start Up
INITIAL START UP WARNING STOP/RESET (red button) - This button places INITIAL START UP the switch, DO NOT jump start these engine generator sets. Starting the module into its Stop/Reset mode. This e switch cold these units on a low battery of jump starting them will will clear any alarm conditions for which the cause damage to the engine control module. - Page 17 TRANSFER SWITCH & ENGINE-GENERATOR CAUTION Before using the transfer test button, be sure that Automatic (remote) Operation conditions are safe for running the generator and for load This procedure checks the electrical operation of the tester. automatic transfer switch. If the actual operation does not follow procedure, consult the trouble-shooting section in the transfer switch manual.
- Page 18 Normally, WINCO generators exercise without a load transfer. This is because you may not with to have a momentary interruption of power. Turn the exerciser dip switch on. Then set the “with load” or “without load”. See the following table.
- Page 19 60706-229/F...
-
Page 20: Dse 3110
DSE 3110 DSE 3110 FAULT CODES FRONT PANEL CONFIGURATION Auxiliary inputs can be user configured and will display he message as written by the user. Fail to Start. The engine has not fired after the preset number of start attempts. Fail to Stop. -
Page 21: Dse 3110 Engine Control
DSE 3110 ENGINE CONTROL PROTECTIONS When an alarm is present, the Common alarm LED (if configured) will illuminate. The LCD display will show an icon to indicate the failure. WARNINGS Warnings are non-critical alarm conditions and do not affect the operation of the generator system; they serve to draw the operator’s attention to an undesirable condition. -
Page 22: Automatic Transfer Switch
PREVENTATIVE MAINTENANCE Reasonable care in preventative maintenance will ensure high reliability and a long life for the engine-generator set and Automatic Transfer Switch. WARNING When performing any type of maintenance on this equipment, make sure the selector switch on the engine- generator is in the off position. -
Page 23: Troubleshooting
TROUBLESHOOTING ATS PANEL WILL NOT TRANSFER TO EMERGENCY SUPPLY WARNING 1. No AC generator out put from generator. Never jump start these units. Jump starting these units 2. See Automatic Transfer Switch Manual. with low or bad batteries will cause permanent damage to the engine control module. -
Page 24: Outline Drawing
OUTLINE DRAWING 60706-229/F... -
Page 25: Pad Layout
PAD LAYOUT ENGINE GENERATOR SET PAD LAYOUT 60706-229/F... -
Page 26: Ac And Dc Generator Schematic
AC AND DC GENERATOR SCHEMATIC 60706-229/F... -
Page 27: Ac Wiring Schematic
AC WIRING SCHEMATIC PSS20-3/A PSS20-4/A PSS20-17/A PSS20-18/A 60706-229/F... -
Page 28: 24 Month Limited Warranty
24 MONTH LIMITED WARRANTY WINCO warrants to the original purchaser for 24 months, or 2,000 hours that goods manufactured or supplied by it will be free from defects in workmanship and material, provided such goods are installed, operated and maintained in accordance with WINCO written instructions and applicable codes.
