- Page 1 PSS21/E PACKAGE PSS30/E STANDBY PSS40/I SYSTEMS DSE7310 INSTALLATION AND OPERATORS MANUAL...
-
Page 2: Table Of Contents
PREPARING THE UNIT USING THIS MANUAL Unpacking the unit ENGINE GENERATOR INSTALLATION Congratulations on your choice of a Winco generator set. Installation You have selected a high-quality, precision-engineered Fuel Line Installation generator set designed and tested to give you years of Fuel Pressure Tables satisfactory standby service. -
Page 3: Guide To Product Safety
IMPORTANT SAFETY FIRE HAZARD - Natural gas and L.P. present a hazard of possible explosion and/or fire. INSTRUCTIONS Do not smoke or use open flame near the generator set. SAVE THESE INSTRUCTION Keep a fire extinguisher nearby and know its proper use. Fire extinguishers rated ABC by NFPA are appropriate. -
Page 4: Basic Information
TESTING POLICY: Additional optional A.T.S. sizes are available to meet specific needs. Contact your local WINCO dealer or the WINCO Sales Department for a quote. Before any generator is shipped from the factory, it is fully checked for performance. The generator is loaded to its full... -
Page 5: Dse 7310 Engine Control
SPECIFICATIONS ENGINE CONTROL MODULE (DSE 7310 Series) The DSE 7310 Series control modules provide integrated engine MODEL WATTS VOLTS and generator set control, protection and metering in a single package. Microprocessor based technology allows for exact PSS1-3 1,000 10/40 89.0* 1800 measurement, set point adjustment, and timing functions. -
Page 6: Installation
INSTALLATION ENGINE SPECIFICATIONS: ** NOTICE ** **************** Regarding Engines - This manual covers the generator portion ***** WARNING ***** of these units. See the separate engine instruction manual **************** for engine-related problems, detailed engine information and PERSONAL INJURY - Before proceeding with the installation, engine warranty. -
Page 7: Fuel Line Installation
**************** FUEL INSTALLATION ***** WARNING ***** The fuel supply should be as close as possible to the engine. **************** This will reduce the installation cost of fuel runs. The information PERSONAL DANGER - Do not use galvanized pipe in fuel line in this manual is offered to assist you in providing the proper fuel runs. -
Page 8: Lp Liquid Withdrawal
UNIT OFF TANKPSI 7-11 in 7-11 in UNIT OFF LINE PSI 7-11 in 7-11 in 4-6 oz 4-6 oz 4-6 oz 4-6 oz STARTING TANK PSI 7-11 in 7-11 in STARTING LINE PSI 7-11 in 7-11 in 4-6 oz 4-6 oz 4-6 oz 4-6 oz NO LOAD... -
Page 9: Battery Installation
INSTALLING THE BATTERY WARNING – The electrolyte is a diluted sulfuric acid that is harmful to the skin and eyes. It is electrically conductive and **** CAUTION **** corrosive. The following precautions must always be taken. In the following battery installation procedure, check to be sure the selector switch remains in the “stop”... -
Page 10: Ac Electrical Connections
A.C. ELECTRICAL ** NOTICE ** The trickle charger is not intended to recharge a battery which CONNECTIONS has become completely discharged. It is designed to produce just enough current to maintain a fully charged battery. NOTICE - CLASS 1 WIRING METHODS ARE TO BE USED FOR ALL FIELD WIRING CONNECTIONS TO TERMINALS The battery tender receptacle is to be powered by a GFCI circuit OF A CLASS 2 CIRCUIT... -
Page 11: Dc Electrical Connections
GROUNDING Minimum Conductor Sizes between the Generator and the ATS. Based on wire type and temperature rating. Wire has been derated for 40 C ambient temperatures. A grounding lug has been provided on the engine generator set to grounded to earth ground if required. Check with your local Cu Conductor Al Conductor codes. - Page 12 in the OFF position. Connect the generator starting wires to the appropriate terminals on terminal block TB7 Be sure as shown on the wiring diagram. For wiring convenience mainta ASCO 185 UL SWITCH Note: Any relay closure can be used to start and stop this terminal block TB7 has a removable plug.
-
Page 13: Engine Control Panel Layout
ENGINE CONTROL PANEL L. FUEL SELECTOR SWITCH - This switch changes the engine operating fuel from NG (with the switch open ) to LP (with LAYOUT the switch closed) This selector switch tells the engine ECU what fuel you are supplying. The engine ECU then makes the appropriate changes in the engine electronics to handle the fuel of your choice. -
Page 14: Initial Start-Up
D. AUTO – This button places the module into its AUTOMATIC Engine oil. Fill as required with proper grade/qty. mode. This module will monitor the remote start input for a relay Engine coolant. Fill as required with proper closure. When the remote start signal is received it will time out mixture. -
Page 15: Exerciser Clock
TROUBLESHOOTING TABLES 4. During manual operation the load will not normally be applied to the generator. But caution must be used, if the line power should fail or be turned off to the transfer switch during manual UNIT WILL NOT CRANK WHEN THE POWER FAILS operation the load may be applied to the generator. -
Page 16: Changing The Fuel Type
Defective stator. GENERATOR SPECIFICATIONS PSS30-4/-17/18 PSS21-3 Stanford Newage Model# PI144D1J Stanford Newage Model# PI144H1L (Single phase 4 lead generator) (Three phase 12 lead reconnectable) Winco Part Number 350005-01 Winco Part Number 350005-007 Voltage Regulator AS480 Voltage Regulator AS480 Rotor Resistance 0.657 ohm... -
Page 17: Engine Specifications
Metal Oxide Varistor BC 073-08063 Diode Stud (fwd) 073-50032 Description Stanford Part # Diode Stud (rev) 073-50033 Automaic Voltage Regulator E000-14800 Winco Part # 350818- Complete Rectifier Assy 45-0427 Bearing 6306C3 051-01058 O’Ring 051-179 ENGINE SPECIFICATIONS GENERAL SPECIFICATIONS PSS21 - All voltages PSS40- All voltages Power Solutions, Inc. -
Page 18: Engine Maintenance Schedule
60706-50 4030-00... -
Page 19: Voltage Regulator Wiring
ENGINE MAINTENANCE NOTES: Coolant System: Check the coolant daily or after each use, and only when the engine is cool. Maintain the coolant level 3/4 to 1 1/2 inches below the filler neck seat when the coolant is cold. Engine oil: Use only engine oils displaying the API Certification Mark “... - Page 20 170-00 REV Page 14 60706-16 60706-50 4030-00...
- Page 21 170-00 REV 60706-16 Page 15 60706-50 4030-00...
- Page 22 60706-50 4030-00...
- Page 23 PSS21-E AND PSS30-E OUTLINE DRAWING PSS40-I OUTLINE DRAWING 60706-50 4030-00...
- Page 24 WINCO’s sole liability, and Purchaser’s sole remedy for a failure under this warranty, shall be limited to the repair of the product. At WINCO’s option, material found to be defective in material or workmanship under normal use and service will be repaired or replaced. For warranty service,...
