MULTISPAN PID 4201-1C Product Manual page 2

Key Operation
1) Press key to go parameter setting.
SET
2) Press or key to change value or to select option.
3) Press key to save change in setting
SET
4) Press key for 6 sec to start/stop PID AUTO TUNING
5) Press + key for 3 sec to go to factory setting mode.
Basic Configuration
TO ENTER BASIC
CONFIGURATION
SETTING, ENTER "73"
Password Message
SET
(0.0 to 30.0)
(-20 to 20)
Press key to
ENT
save & exit
PID-4201-1C
Set Point Setting
Process Value
Set Point
Set Value
Press key for 4 sec to
SET
enter Password
Password Message
Page
-
2
C
°
PV
R
Current
PID
AUTO-TUNING
Press






key
for
6
sec
to
start/stop
PID
auto-tuning

Control Parameter
TO ENTER CONTROL
PARAMETER
SETTING, ENTER "37"
(If R1MD = PID)
Press key to
ENT
save & exit
Press + key
for 3 sec
yes : press key to apply factory set
ENT
values as shown in table.
nO : press ENT key to escape
from factory setting.
Factory Setting
FACTORY SETTING
SR. PARAMETER VALUES
1 PB 20.0
2 IT 300
3 DT 75
4 CT 15 SEC.
5 MR 0°C
6 OFFSET 0°C
7 HYSTERESIS
3°0
Press + key for
SET
4 sec for Heater on/off
Select on/off value & press key
ENT
to turn on/off heater
www.multispanindia.com
