LANVIEW LEDs
The functions of the two System Status LEDs, System Management Bus (SMB)
and the CPU, are listed in Table 4-1.
LED Color
Green
Yellow
Yellow (flashing)
Yellow/Green
Red
Red (Flashing)
Off
The functions of the INB receive LED are listed in Table 4-2.
The functions of the INB transmit LED are listed in Table 4-3.
4-2
Table 4-1. System Status (SMB and CPU) LEDs
State
Functional
Testing
Crippled
Booting
Reset
Failed
Power off
LED Color
Green (Flashing)
Green
Yellow (Flashing)
Red
Off
Table 4-3. INB Transmit LED
LED Color
Green (Flashing)
Yellow (Flashing)
Red (Flashing)
Red
Off
Description
Fully operational.
Power-up Testing
Not fully operational (i.e., one bad port).
Blinks yellow and green while booting.
Normal power-up reset.
Fatal error has occurred.
Module powered off.
Table 4-2. INB Receive LED
State
Link, Port Disabled
Link, Port Enabled, No activity
Link, Port Enabled, Activity
Fault
No Link
State
Data Activity
Port in Standby State
Collision
Fault
No activity, Port Disabled
