Installing the SmartSwitch 9000 Module

The Reset Switch

The Reset switch is located under the top plastic tab as shown in Figure 2-3.
Use the reset switch to reset the module's processor, shutdown (power down) the
module, and/or restart the module.
• To reset the module's i960 processor, press the reset switch twice within three
seconds.
• To shutdown the module, press and hold the reset switch for three or more
seconds.
• To restart the module, press the reset switch momentarily.
SNMP management may be used to disable this switch to enhance module
security.
2-6
SMB CPU
Figure 2-3. The Reset Switch
Reset Switch
