An eight position DIP switch is located on the module card as shown in
Figure 2-1. The function of the switches are listed in Table 2-1.
See the Cautions at the end of this table.
Switch
8
7
6
5
4
3
2
1
1. Caution: Do not toggle Switch 8 unless you intend to reset the user
configured passwords to their factory default settings.
!
2. Caution: Do not toggle Switch 7 unless you intend to reset the user
CAUTION
parameters to the factory default settings.
Table 2-1. Function of DIP Switch
Function
When toggled, this switch clears user-entered
Clear passwords stored in NVRAM, and restores the
1
Password default passwords. Once reset you can use the
defaults or enter new passwords.
The module uses NVRAM to store user
entered parameters such as IP addresses,
device name, etc. To reset these parameters to
Clear the factory defaults, toggle this switch. Once
2
NVRAM reset you can use the defaults or enter new
parameters which are stored in NVRAM when
the module is powered down, and remain
there until the switch is toggled again.
Toggling this switch after pulling the board
out of the SmartSwitch 9000, clears download
information from NVRAM and forces image
Force BootP
files to be downloaded from the station
Download
connected to the EPIM on the Environmental
Module configured to act as that modules'
B P server.
OOT
Reserved
Reserved
Reserved
Reserved
Reserved
Installing the SmartSwitch 9000 Module
Description
For Factory Use Only
For Factory Use Only
For Factory Use Only
For Factory Use Only
For Factory Use Only
2-3
