Roverpet WB1866DSF Assembly Instructions

Roverpet
20 Kiji Dava Circle Prescott, Arizona 86301
Roverpet #WB1866DSF –18" high 6'x6' Whelping Box Assembly Instructions
Inventory list for The Roverpet #WB1866DSF Whelping Box:
(11) #118 18" high panels
(1) #66PR3 3" high puppy rail assembly(two leg bars, two cross-bars and four legs
(1) #66DPK Designer Puppy Keeper (6" high)
(24) #250 floor/divider clips

Assembly Procedure:

1.) Unpack contents of shipping carton and compare to parts list above.
2.) Layout the two #118 panels / #D18 door sub-assemblies as show below, with the assembly containing the
door positioned on the right side.
#200 panel clips- pre-attached
to end panels here by Rover
Co.
3.) Connect the ends of the sub-assemblies together with the #200 panel clips that are already attached to the
end panels; reposition panels into a square shape resembling the main photo at the top of this page.
4.) Install #180 straight stabilizers onto the top of in-line connected panels (left photo below) and install #90
corner stabilizers onto the top of corner connected panels (right photo below).
5.) Lay floor trays side-by-side into the bottom of the Roverpet whelping box with the frame pipes facing up to
allow connection to the side panels.
6.) Connect floors to side panels with supplied #250 floor clips in the following manner:
- One in the middle of each bottom bar of the #118 panels.
- Two at the extreme ends of the #D18 door frame bottom bar (do not place in the door opening).
- Three equally spaced across the mid-span of the floor frames.
(1) #D18 door
(8) #180 straight stabilizers
(24) #200 panel clips (pre-assembled onto frames by Roverpet.)
1-800-658-5925 rover@roverpet.com
(4) #F24 2'x4' floors 2'x2'
(1) #F22 floor
(2) #PRS66 Support Arms
(4) #90 corner stabilizers
Page 1 of 3
