ACMD-200
Wireless carbon monoxide detector
EN
Firmware version 1.00
acmd-200_en 10/21
SATEL sp. z o.o. • ul. Budowlanych 66
80-298 Gdańsk • POLAND tel. +48 58 320 94 20
www.satel.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Abax 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Satel Abax 2

  • Page 1 ACMD-200 Wireless carbon monoxide detector Firmware version 1.00 acmd-200_en 10/21 SATEL sp. z o.o. • ul. Budowlanych 66 80-298 Gdańsk • POLAND tel. +48 58 320 94 20 www.satel.eu...
  • Page 2 13 August 2005). The device meets the technical regulations of the Eurasian Customs Union. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
  • Page 3: Table Of Contents

    CONTENTS Features ........................... 2 Description ........................2 Selecting a mounting location ................... 4 Installation ........................4 Battery replacement ......................5 Specifications ........................7...
  • Page 4: Features

    SATEL The ACMD-200 detector detects carbon monoxide. It is designed to work as a stand-alone device or within the ABAX 2 two-way wireless system. The detector is supported by:  ACU-220 / ACU-280 controller (firmware version 6.03 or newer),  ARU-200 repeater.
  • Page 5 You can set the operating mode using the jumper located on the electronics board (Fig. 2):  jumper off – stand-alone mode,  jumper on – working in the ABAX 2 system. The detector is operating similarly as in the stand-alone mode, but it additionally: –...
  • Page 6: Selecting A Mounting Location

    It may have a negative impact on the gas sensor operation.  If the detector is to work in the ABAX 2 system, installing the device in close vicinity of electrical systems is not recommended, since it can adversely affect the range of radio signal.
  • Page 7: Battery Replacement

    6. Put the detector at the place of its future installation. 7. Check the level of signal received from the detector by the ABAX 2 controller. If the signal level is lower than 40%, select another place for installation. Sometimes, it is sufficient to shift the device ten or twenty centimeters.
  • Page 8 ACMD-200 SATEL 4. Remove the discharged battery (Fig. 6). 5. Install a new CR123A 3 V lithium battery (Fig. 7). 6. Replace the cover (Fig. 8). 7. Turn the cover clockwise (Fig. 9). 8. Lock the cover using the screw (Fig. 10).
  • Page 9: Specifications

    ACU-220 ...................... up to 2000 m ACU-280 ...................... up to 1200 m Battery ........................CR123A 3 V Battery life expectancy ABAX 2 ....................up to 2 years stand-alone mode ................up to 5 years Standby current consumption ABAX 2 ......................62 µA stand-alone mode ....................
