Operating instructions
RFID compact unit
UK
DTE801/DTE802/DTE804/DTE805
DTE901/DTE902/DTE904/DTE905

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTE801 and is the answer not in the manual?

Questions and answers

Summary of Contents for IFM DTE801

  • Page 1 Operating instructions RFID compact unit DTE801/DTE802/DTE804/DTE805 DTE901/DTE902/DTE904/DTE905...
  • Page 2: Table Of Contents

    2 Safety instructions �����������������������������������������������������������������������������������������������4 3 Functions and features ����������������������������������������������������������������������������������������5 3�1 Configuration via Ethernet interface ��������������������������������������������������������������6 4 Items supplied������������������������������������������������������������������������������������������������������6 5 Function ���������������������������������������������������������������������������������������������������������������6 5�1 Operating principle ���������������������������������������������������������������������������������������6 5�2 Overview DTE801������������������������������������������������������������������������������������������7 5�3 Overview DTE901������������������������������������������������������������������������������������������7 5�4 Overview DTE802������������������������������������������������������������������������������������������7 5�5 Overview DTE902������������������������������������������������������������������������������������������8 5�6 Overview DTE804������������������������������������������������������������������������������������������8 5�7 Overview DTE904������������������������������������������������������������������������������������������8 5�8 Overview DTE805������������������������������������������������������������������������������������������8...
  • Page 3 8�2�1 Power LEDs and signal bar ����������������������������������������������������������������17 8�2�2 LED signal bar ������������������������������������������������������������������������������������17 8�2�3 LED LINK/ACT ETH 1 / ETH 2 �����������������������������������������������������������18 8�2�4 Special device LED indicators ������������������������������������������������������������18 8�3 LED indicators DTE801/DTE901 �����������������������������������������������������������������19 8�3�1 LED SF �����������������������������������������������������������������������������������������������19 8�3�2 LED BF �����������������������������������������������������������������������������������������������19 8�4 LED indicators DTE802/DTE902 �����������������������������������������������������������������20 8�4�1 LED Mod (module status) �������������������������������������������������������������������20...
  • Page 4: Preliminary Note

    ► Measures to take� 1.3 Copyright and trademarks © All rights reserved by ifm electronic gmbh� No part of these instructions may be reproduced and used without the consent of ifm electronic gmbh� All product names, pictures, companies or other brands used on our pages are the property of the respective rights owners�...
  • Page 5: Functions And Features

    The DTE80x device is composed of an evaluation unit and an integrated RFID read/write head and provides the following functions • read and write ID tags which conform to the system without contact, • DTE801/DTE901: communication with the control level via PROFINET IO, • DTE802/DTE902: communication with the control level via EtherNet/IP, •...
  • Page 6: 3�1 Configuration Via Ethernet Interface

    4 Items supplied • DTE RFID compact unit • Operating instructions The device is supplied without installation and connection accessories� In the event of incomplete or damaged items supplied, please contact ifm electronic� 5 Function 5.1 Operating principle The ID tags are operated passively, i�e� without battery� The energy required for operation is supplied by the RFID compact unit�...
  • Page 7: 5�2 Overview Dte801

    The radiated power is specified in ERP (Effective Radiated Power) for the DTE80x units and in EIRP (Effective Isotropic Radiated Power) for the DTE90x units� The respective value can be converted using the following formula: P [dBm EIRP] = P [dBm ERP] + 2�15 [dB] 5.2 Overview DTE801 Art� no�: DTE801 Function:...
  • Page 8: 5�5 Overview Dte902

    5.5 Overview DTE902 Art� no�: DTE902 Function: RFID compact unit Type designation: DTRUHFA HLRWEIUS04 Operating frequency: 902-928 MHz Design: rectangular Typ� transm� power: 21�5 dBm EIRP (141 mW) 5.6 Overview DTE804 Art� no�: DTE804 Function: RFID compact unit Type designation: DTRUHFE HLRWENUS04 Operating frequency: 865-868 MHz...
  • Page 9: 5�9 Overview Dte905

    5.9 Overview DTE905 Art� no�: DTE905 Function: RFID compact unit Type designation: DTRUHFA HLRWITUS04 Operating frequency: 902-928 MHz Design: rectangular Typ� transm� power: 21�5 dBm EIRP (141 mW) 6 Installation NOTE! Radiated electromagnetic field strengths The device sends ultrahigh frequency electromagnetic waves (construed in accordance with DIN EN 50364, complies with the limit values for the general public and workers)�...
  • Page 10: 6�3 Avoiding Interference

    The orientation of the RFID compact unit axis must correspond with the axis of the ID tag� 6.3 Avoiding interference The unit generates a modulated electromagnetic field in the following frequency ranges: - DTE80x: 865-868 MHz - DTE90x: 902-928 MHz To avoid interference of the data communication no other RFID UHF devices generating interference emission in this frequency band must be operated in its vicinity�...
  • Page 11: 6�5�1 Installation With Angle Bracket E80335

    6.5.1 Installation with angle bracket E80335 6.5.2 Installation with mounting device E80336 The mounting device is used to mount the device to a clamp� The following clamps can be used: • E21110 with a rod diameter of 12 mm • E20795 with a rod diameter of 14 mm •...
  • Page 12: 6�5�3 Installation With Fixing Bars E80337

    6.5.3 Installation with fixing bars E80337 ► Fix the unit with fixing screws to the designated location� 6.6 Mounting distances Operating mode Distance side (A) Distance front (B) Reading and writing at 100% transmitting >6�0 m >10�0 m power (simultaneous operation) Reading and writing at 100% transmitting >0�3 m >0�3 m...
  • Page 13: 6�7 Positioning Of The Id Tags

    6.7 Positioning of the ID tags ► Align the ID tag on the antenna central axis� > Distance D see data sheet ID tags can also be read behind the unit� Should such cases occur despite mounting precautions, the RSSI filter is recommended for suppression� 7 Electrical connection NOTE! The unit must be connected by a qualified electrician�...
  • Page 14: 7�1 Voltage Supply Pwr

    7.1 Voltage supply PWR ► Connect the device to the voltage supply using an M12 connection cable� Connection 24 V DC Digital input / output 2 Digital input / output 1 Not connected Pin connection voltage supply 7.2 Ethernet ► Connect the device to a PC using a suitable M12 Ethernet connection cable� The M12 Ethernet cable must be screened to ensure interference-free operation�...
  • Page 15: 7�2�1 Factory Setting Of The Ethernet Parameters

    7.2.1 Factory setting of the Ethernet parameters The following values are preset at the factory: Parameter Factory setting IP address 192�168�0�79 Gateway address 192�168�0�100 Subnet mask 255�255�255�0 Auto-negotiation DHCP The settings can be changed via the unit's web server or via the PC� 7.3 Functional earth connection To ensure interference-free operation, the unit must be connected to an earth potential free from external voltage�...
  • Page 16: Operating And Display Elements

    8 Operating and display elements ①: 1 power LED (green) 4 LEDs on signal bar (yellow) 2 fieldbus LEDs (green/red) ②: sensing face 8.1 Reset to factory settings The Ethernet parameters can be reset to factory setting� To do so, proceed as follows: ►...
  • Page 17: 8�2�1 Power Leds And Signal Bar

    8.2.1 Power LEDs and signal bar LED PWR LED signal bar State Note (1x green) (4x yellow) Voltage supply OK 18 V ≤ U ≤ 36 V Flashing Antenna (HF field) is deactivated 2 Hz ID tag read / written Flashes twice successfully ID tag read / written...
  • Page 18: 8�2�3 Led Link/Act Eth 1 / Eth 2

    8.2.3 LED LINK/ACT ETH 1 / ETH 2 LED green LED yellow State Note No connection to another Link status "no link" Ethernet counterpart Connection to Ethernet Link status "link", counterpart exists, no data "no traffic" exchange Connection to Ethernet Flashes counterpart exists, data Link status "link", "traffic"...
  • Page 19: 8�3 Led Indicators Dte801/Dte901

    8.3 LED indicators DTE801/DTE901 The following LED indicators only apply to DTE801/DTE901� 8.3.1 LED SF LED red LED green State Note No voltage supply Check the voltage supply "Node flash test", initiated by Flashes PROFINET IO controller Normal operation - Temperature...
  • Page 20: 8�4 Led Indicators Dte802/Dte902

    8.4 LED indicators DTE802/DTE902 The following LED indicators only apply to DTE802/DTE902� 8.4.1 LED Mod (module status) LED red LED green State Note No voltage supply Check the voltage supply Device is not configured� There is no exchange of data: ►...
  • Page 21: 8�4�2 Led Net (Network Status)

    8.4.2 LED Net (network status) LED red LED green State Note ► Check the voltage supply ► If DHCP is activated, No IP address or no voltage check presence of a supply DHCP server in the network� The device has received an IP address�...
  • Page 22: 8�5 Led Indicators Dte804/Dte805/Dte904/Dte905

    8.5 LED indicators DTE804/DTE805/DTE904/DTE905 The following LED indicators only apply to DTE804/DTE805/DTE904/DTE905� 8.5.1 LED SF LED red LED green State Note No voltage supply Check the voltage supply Normal operation - Temperature Flashes Error at channel level - Internal fault Error at device level Temperature Flashes...
  • Page 23: Maintenance, Repair And Disposal

    3� The distance between the read/write head and an ID tag must be > 20 cm� Changes or modifications made to this equipment not expressly approved by ifm may void the FCC authorisation to operate this equipment�...
  • Page 24: 10�1�4 Canada

    NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules� These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment�...
  • Page 25: 10�1�6 Australia

    Please find below the Taiwanese legal regulations in Chinese� 低功率電波輻射性電機管理辦法: • 第十二條 經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均不得擅自 變更頻率、加大功率或變更原設計之特性及功能。 • 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象 時,應立即停用,並改善至無干擾時方得繼續使用。 前項合法通信,指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 10.1.6 Australia Use in Australia: 10.1.7 Singapore Complies with IDA Standards DB 103032 The "Equipment Registration" is available on our website at: www�ifm�com 11 Scale drawing 12,4 M12x1...
