Installing the MMAC-Plus modules

User Accessible Components

Figure 2-3 shows the various components that are accessible to the user. These
consist of an eight position dip switch (explained below), replaceable PROMs and
sockets for RAM. These will be used for future upgrades. Instructions for
installing the components will be supplied with the upgrade kit.
Boot PROM
Flash SIMM
Socket
An eight switch DIP switch is located on the module card as shown in Figure 2-3.
The function of the switches are listed in Table 2-1.
2-4
8
7
6
5
4
3
2
1
Figure 2-3. User Accessible Components
SMB-1
PROM
DIP Switch
Local DRAM
Socket
i960
Processor
