DS-1011
JAPAN
Прибор для измерения артериального
давления и частоты пульса цифровой DS
Руководство по эксплуатации
Вимірювач артеріального тиску та частоти серцевих
скорочень (Digital blood pressure monitor DS-1011)
Інструкція з експлуатації
Kүретамырдың қан қысымы мен тамырдың соғу
жиілігін өлшеуге арналған сандық DS аспабы
Пайдалану жөніндегі басшылық құжат
Digital Blood Pressure Monitor
Instruction Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Nissei DS-1011
Summary of Contents for Nissei DS-1011
- Page 1 Прибор для измерения артериального давления и частоты пульса цифровой DS Руководство по эксплуатации Вимірювач артеріального тиску та частоти серцевих скорочень (Digital blood pressure monitor DS-1011) Інструкція з експлуатації Kүретамырдың қан қысымы мен тамырдың соғу жиілігін өлшеуге арналған сандық DS аспабы...
- Page 2 This manual is intended to assist you in the safe and effi cient operation of BLOOD PRESSURE MONITOR DS-1011. The product must be used in accordance with the procedures contained in this manual and must not be used for purposes other than those described herein. It is important to read and understand the entire manual.
-
Page 3: General Information
The amplitude of each pressure waves is measured, converted to millimeters of mercury, and displayed on the LCD as a digital value. Used new NISSEI Technologies Measurement on Infl ation – is a technology that makes it possible to defi ne the pressure in the course of the cuff... -
Page 4: Tips On Taking Your Blood Pressure
7. Warranty card – 1 pcs. 8. Packing – 1 pcs. TIPS ON TAKING YOUR BLOOD PRESSURE 1. If treated with hemodialysis or anticoagulants, antiplatelets or steroids, refer to your doctor about the blood pressure measurement. 2. Malfunctions are possible when the device is used near working mobile phones, microwave ovens and other equipment generating electromagnetic radiation. - Page 5 5 In case of disorders such as deep vascular sclerosis, weak pulse wave and break in rhythm of heart contractions, the correct blood pressure measurement can be complicated. IN THIS CASE, A DOCTOR SHALL PROVIDE RECOMMENDATIONS IN RELATION TO USE OF THIS DEVICE. 6 KEEP QUIET DURING THE MEASUREMENT TO OBTAIN THE CORRECT BLOOD PRESSURE READING WHEN USING THE ELECTRONIC DEVICE.
-
Page 6: Battery Installation
BATTERY INSTALLATION Battery symbol will fl ash when battery power is low. Measurement can not be made while the symbol is displayed. Replace the batteries. All four batteries need to be replaced with new ones; do not mix new and old batteries or diff... -
Page 7: Correct Measuring Posture
Press “SET” KEY until “2011” starts fl ashing. Clock is set in the order of year, month, day, hour and minute. The fl ashing number increases with and decreases with . The number will be fast-forwarded if you keep your fi nger on the key. Pressing “SET” will fi x the number and the next article will fl ash. Pressing “START/STOP”... - Page 8 3 Press the surface of the cuff to make sure that the hook & loop fastens securely (fi g.9). If the cuff is wrapped tightly or loosely, inaccurate blood pressure readings may result. Fig.9 4 If the arm has taper form, it is recommended to put the cuff on “spiral way”, as shown in the fi...
- Page 9 Press “START/STOP” again to cancel measurement. The monitor will exhaust air from the cuff and turn off . 5. Pulse Symbol «» is displayed as pulse is detected (fi g.14). 6. Air is released from the cuff and measured values are displayed as measurement completes (fi...
- Page 10 WHO scale is the scale classifi cation derived values of blood pressure Display WHO Classifi cation Hypertension (severe) ≥180 ≥110 Hypertension (moderate) 160-179 100-109 Hypertension (mild) 140-159 90-99 High Normal 130-139 85-89 Normal 120-129 80-84 Optimal <120 <80 Pulse Pressure Display This product calculates and displays pulse pressure (fi...
-
Page 11: Memory Function
MEMORY FUNCTION The measured values are automatically saved for later review in either one of two memory banks. These two memory banks can be used to save readings of two persons separately or to save morning readings and evening readings separately. Each bank can save up to 60 readings. -
Page 12: Troubleshooting
TROUBLESHOOTING SYMPTOM PROBABLE CAUSE Remedies Blood pressure is The cuff is not adjusted to your heart. Adjust the cuff to the height of your heart. extremely high or low. The cuff is not wrapped appropriately. Reconfi rm how to put the cuff on your arm. Movement or speaking was detected. -
Page 13: Warranty
Nothing is displayed. Batteries are deleted. Replace all batteries with new ones. Batteries are inserted incorrectly. Reinsert the batteries correctly. Battery terminals are not clean. Clean the terminals with dry cloth. START/STOP was being pressed at Turn off the monitor once with “START/STOP” installation of batteries. -
Page 14: Specifications
Environment temperature, ˚C from -20 to 50 relative humidity, % Rh 85 or below Cuff Model Cuff DS-1011 Cuff Size adult (circumference of the upper arm 22-32 cm) Overall dimensions: Size (without cuff ), mm 115 x 115 х 65... -
Page 15: Care, Storage, Repair And Recycling
Classifi cation Class II / Internally powered equipment Key to symbols: IP20 IP protection class Important: Read the instructions Class II Sign of type approval of measuring instruments Mark of conformity of Ukraine UA.TR.001 Type BF Sign of type approval of measuring instruments of Ukraine Manufacturer When utilizing the waste, refer to current rules applicable in your region GOST conformity mark... -
Page 16: Certification And State Registration
AC Adaptor ADP-W5 meets international standard IEC60601-1 by JQA, class II. Produced by Nihon Seimitsu Sokki Co., Ltd. Address: 2508-13 Nakago Shibukawa Gunma 377-0293 Japan website: www.nissei.pl EC-Representative: MDSS GmbH Schiff graben 41, 30175 Hannover, Germany TECHNICAL DESCRIPTION FOR ELECTROMAGNETIC DISTURBANCES The device complies with the Electromagnetic Disturbances standard, IEC60601-1-2:2014. - Page 17 • Use of the device adjacent to or stacked with other equipment must be avoided because it could result in improper operation. • Use of accessories other than those specifi ed or provided by the manufacturer could result in increased electromagnetic emissions or decreased electromagnetic immunity of the device and result in improper operation.
- Page 18 NIHON SEIMITSU SOKKI CO., LTD. 2508-13 Nakago Shibukawa Gunma 377-0293 Japan web site: http://www.nissei-kk.co.jp/english/ MDSS GmbH Schiff graben 41, 30175 Hannover, Germany UA.TR.001 ® Зарегистрированный товарный знак. I467/1903/10 © Copyright 2019.
