- Page 1 Rack Mount Display Military Grade Model No: R20L100-RKA2ML User Manual Version 1.1 Document Part Number: 915211121027...
- Page 2 Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
- Page 3 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
- Page 4 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
- Page 5 Safety Information CAUTION! POSSIBLE PROBLEM PREVENTION Sunlight shines directly will You should avoid placing the cause the panel damage. product under direct sunlight. Do not expose the display to direct sunlight. If the product is close to the You should avoid placing the wet ground such as product in wet grassplot, the moisture...
- Page 6 Safety Precautions For your safety carefully read all the safety instructions before using the device. All cautions and warnings on the equipment should be noted. Keep this user manual for future reference. CAUTION/ATTENTION Do not cover the openings! Ne pas couvrir les ouvertures! *Let service personnel to check the equipment in case any of the following problems appear: o The power cord or plug is damaged.
- Page 7 Important Information Countries/ Symbol This equipment complies with essential requirements of: Area European Electromagnetic Compatibility Directive(2014/30/EU) Union Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules.
- Page 8 European Union Thus equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010 EN 55022: 2010 Class B o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014...
-
Page 9: About This User Manual
Raven Hsu solutions About This User Manual This User Manual provides information about using the Winmate® Military Grade Rack Mount Display. The documentation set for the 20.1” Military Grade Rack Mount Display provides information for specific user needs, and includes: ... -
Page 10: Table Of Contents
Contents Preface ............................ii About This User Manual ......................ix 1 Introduction ..........................13 1.1 Product Features ........................ 13 1.2 Hardware Specifications ....................14 1.3 Packing List ......................... 15 1.4 Appearance ........................16 1.4.1 Display Appearance and Layout ................16 1.4.2 OSD Panel Layout .................... - Page 11 5 Maintenance ........................... 37 5.1 Cleaning the Display Screen ....................37 5.2 Cleaning the Casing ......................37 6 Technical Support ........................40 6.1 Troubleshooting ......................... 40 6.2 Problem Report Form ......................41 Appendix A MIL-STD-810F/G Compliance ................... 43 A1 MIL-STD-810F/G Compliance ..................... 43 Appendix B MIL-STD-461E/F Compliance ..................
- Page 12 Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the Display in the packing list. Military Grade Rack Mount Display...
-
Page 13: Introduction
Chapter 1 Introduction 1 Introduction Thank you for choosing the Winmate® Military Grade Rack Mount Display. Winmate® Military Grade Displays feature anti-corrosive coating with aluminum alloy housing withstands the harshest military environments. Armored power connector MIL-DTL- 38999 Type I initially developed for aerospace industry perfectly fit in our Military grade product line. -
Page 14: Hardware Specifications
User Manual Chapter 1 Introduction 1.2 Hardware Specifications Model Name R20L100-RKA2ML Viewable Size Image 20.1” Active Display Area 408.0(H) x 306.0(V) mm Pixel Pitch 0.255(H) x 0.255 (V) mm Number of Pixels 1600 x 1200 Contrast Ratio 800:1(typ.) 16.7M Display Color... -
Page 15: Packing List
User Manual Chapter 1 Introduction 1.3 Packing List Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Power Cord Display... -
Page 16: Appearance
User Manual Chapter 1 Introduction 1.4 Appearance This section includes appearance and input/ output connectors’ layout. 1.4.1 Display Appearance and Layout 1.4.2 OSD Panel Layout For more information on OSD control, refer to Ch.4 “On-Screen Display (OSD) Control” this User Manual. 1.4.3 LED Indicators Indicator Color... -
Page 17: Dimensions
User Manual Chapter 1 Introduction 1.5 Dimensions This section includes mechanical drawing and mechanical dimensions of the Display. Unit Dimensions (W x H x D): 482.6 x 399.4 x 85 mm CUT OUT 446 x 377 mm *Measurements shown in mm. **Tolerance of all dimensions is shown as follow 0~30 mm ±... - Page 18 Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. Military Grade Rack Mount Display...
-
Page 19: Getting Started
User Manual Chapter 2 Getting Started 2 Getting Started This chapter provides information on how to connect the device to the source of power, connector pinouts and the guideline to turn on/off the Display. 2.1 Powering On 2.1.1 Power Considerations Follow the recommendations below when powering on the equipment. -
Page 20: Connecting The Power
User Manual Chapter 2 Getting Started 2.1.2 Connecting the Power 2.1.2.1 Connecting to AC Input Power Source (Default) AC Power Input Requirements: AC 100~240V, Universal, ±10% Connect one end of the Military Grade power connector MIL-DTL-38999/1 to the Display (CN2), and plug the other end of the power connector (CN1) in to a working AC outlet. Note: Power cords vary in appearance by region and country. - Page 21 User Manual Chapter 2 Getting Started 2.1.2.2 Connecting to DC Input Power Source (Optional) DC Power Input Requirements: 9~36V DC IN 1. Insert the exposed wires of the DC Power Cable to the appropriate connectors on the terminal block plug. 2.
-
Page 22: Connecting Other Devices
User Manual Chapter 2 Getting Started 2.2 Connecting Other Devices The location and pin assignment of the cables are as follows. WARNING!/ AVERTISSEMENT! Make sure the power is off when connecting and disconnecting the connectors. Assurez-vous que l'alimentation est coupée lors de la connexion et la déconnexion des connecteurs. -
Page 23: Vga To 5 Bncs Signal Shielding Cable
User Manual Chapter 2 Getting Started 2.2.2 VGA to 5 BNCs Signal Shielding Cable Plug one end of VGA signal cable to the rear side of the PC system and the other end of 5BNCs (R, G, B, H, V) signal connector to the Display. 2.2.3 DVI-I Connector Plug one end of the DVI signal cable to the video signal connector (DVI-I Dual Link) at the rear of the PC system and the other end to the Display. - Page 24 Mounting Solutions This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. Military Grade Rack Mount Display...
-
Page 25: Mounting Solutions
User Manual Chapter 3 Mounting Solutions 3 Mounting Solutions This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. -
Page 26: Safety Precautions
User Manual Chapter 3 Mounting Solutions 3.2 Safety Precautions Observe the following common safety precautions before installing any electronic device: •Use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must be crossed make sure the wires are perpendicular at the intersection point. -
Page 27: Vesa Mount
Make sure that the eight holes on gasket can fit in the mounting holes on the device. 3.3.2 VESA Mount Military Rack Mount Display supports VESA Mount installation. Notice that VESA Plate is not included in Winmate’s standard accessories package. VESA Plate 100 x 100 mm *with customer’s bracket Mounting Steps: 1. - Page 28 On-Screen Display Control This chapter provides information about On-Screen Display (OSD) Control interfaces. Military Grade Rack Mount Display...
-
Page 29: On-Screen Display Control
User Manual Chapter 4 OSD Control 4 On-Screen Display Control This chapter provides information about On-Screen Display (OSD) Control interfaces. 4.1 OSD Control Function Buttons On-Screen Display (OSD) is a user-friendly interface to remote the display function and to adjust the display’s image properties. It also supports special Hot Keys for easy control, such as auto-adjustment and brightness control for backlight. -
Page 30: Navigating The Osd Menu
User Manual Chapter 4 OSD Control 4.2 Navigating the OSD Menu This section describes how to navigate the OSD Menu. OPTION ACTION EFFECT Enter the main menu Display the main menu on the screen. Press the MENU button Select the menu you want Shift the item selections up to adjust or down until it is desired,... - Page 31 User Manual Chapter 4 OSD Control Description of items on the navigation menu: BRICONTRAST Press "+" to increase or "-" to decrease the brightness or contrast. BRIGHTNESS: Use to adjust the screen’s brightness CONTRAST: Use to adjust the screen’s contrast POSITION You can adjust the screen’s...
- Page 32 User Manual Chapter 4 OSD Control COLOR You can select the screen’s color level of the white color field from the default color temperature settings. Also, you can fine tune the color temperature by USER option if necessary. USER: Choose RED/GREEN/BLUE to set value of color temperature brightness to suit you own preference...
-
Page 33: Osd Menu In Dvi Mode
User Manual Chapter 4 OSD Control OSD EXIT You can exit the OSD menu by selecting “YES”. Select “NO” to return the main menu. 4.4 OSD Menu in DVI Mode This section describes how to navigate the OSD Menu in DVI Mode. Navigation buttons in DVI Mode AUTO BRIGHTNESS CONTRAST... - Page 34 User Manual Chapter 4 OSD Control POSITION These functions are not available under DVI mode. IMAGE These functions are not available under DVI mode. COLOR You can fine tune the color temperature by USER option if necessary. USER: Choose RED/GREEN/BLUE to set value of color temperature brightness to suit you own preference...
- Page 35 User Manual Chapter 4 OSD Control AUDIO (optional) You can adjust the setting of speaker, including volume and mute. VOLUME ADJUST: Use to adjust the volume of speaker SPEAK ON/OFF: Use to make the speaker work or mute RECALL You can recall the factory default setting by selecting “YES”.
- Page 36 Maintenance This chapter provides information on regular cleaning and maintenance procedures. Follow all the recommendations included in this chapter in order to ensure long product lifecycle. Military Grade Rack Mount Display...
-
Page 37: Maintenance
User Manual Chapter 5 Maintenance 5 Maintenance This chapter includes regular cleaning and maintenance procedures. Follow all the recommendations in this chapter in order to ensure long product lifecycle. This equipment is extremely rugged and does not require a lot of maintenance. Remember that electrical equipment should be handled with care and used accordingly to its specifications. - Page 38 User Manual Chapter 5 Maintenance WARNING!/ AVERTISSEMENT! POTENTIAL ELECTROSTATIC CHARGE HAZARD – SEE INSTRUCTIONS POTENTIEL ÉLECTROSTATIQUE CHARGE DANGER - VOIR INSTRUCTIONS Military Grade Rack Mount Display...
- Page 39 Technical Support This chapter includes troubleshooting guide and problem report form. Military Grade Rack Mount Display...
-
Page 40: Technical Support
User Manual Chapter 6 Technical Support 6 Technical Support This chapter includes troubleshooting guide and problem report form. Free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. -
Page 41: Problem Report Form
User Manual Chapter 6 Technical Support 6.2 Problem Report Form Military Grade Rack Mount Display Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: _____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible. - Page 42 MIL-STD-810F/G Compliance This section includes information on testing methods and procedures in compliance with military standard MIL-STD-810 F/G. Appendix Military Grade Rack Mount Display...
-
Page 43: Appendix A Mil-Std-810F/G Compliance
User Manual Appendix A MIL-STD-810F/G Compliance Appendix A MIL-STD-810F/G Compliance This section includes information on testing methods and procedures in compliance with military standard MIL-STD-810 F/G. A1 MIL-STD-810F/G Compliance MIL-STD-810F/G Compliance Test Reference Condition * High Storage Method 501.5, Basic Hot 30 to 63°C ± 2°C Temperature Procedure I Operation... - Page 44 User Manual Appendix B MIL-STD-810E/F Compliance MIL-STD-461E/F Compliance This section includes information on testing methods and procedures in compliance with military standard MIL-STD-461E/F Appendix Military Grade Rack Mount Display...
-
Page 45: Appendix B Mil-Std-461E/F Compliance
User Manual Appendix B MIL-STD-810E/F Compliance Appendix B MIL-STD-461E/F Compliance This section includes information on testing methods and procedures in compliance with military standard MIL-STD-461 E/F. To comply with MIL-STD-461E Standard, the Display must have Built-in EMI -ITO Glass or Touch with EMI Mesh Film. B1 MIL-STD-461E/F Compliance MIL-STD-461E/F Compliance Test... - Page 46 Ordering Information This section includes information on available ordering options. Appendix Military Grade Rack Mount Display...
-
Page 47: Appendix C: Ordering Information
Appendix C: Ordering Information 20.1” Military Grade Rack Mount Display available in the following configurations: Part Number Description R20L100-RKA2ML/GS Anti-Reflective Glass (Default) R20L100-RKA2ML/ITO ITO EMI shielding Glass * R20L100-RKA2ML/ATR ELO 5 wired Resistive Touch Sensor (RS232 Interface) R20L100-RKA2ML/ATR-ITO ELO 5 wired Resistive Touch with EMI Mesh Filter *To comply with the MIL-STD-461E Standard, the display unit must have EMI-ITO Glass or Touch with EMI Mesh Filter. - Page 48 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, Taipei 241, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
