Installation Guide
For Model:
BRC30WW6L
E124404
net weight of fan: 9.04 lb (4.1 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 4
Warranty. pg. 8
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRC30WW6L and is the answer not in the manual?

Questions and answers

Related Manuals for Litex Industries BRC30WW6L

Summary of Contents for Litex Industries BRC30WW6L

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Model: BRC30WW6L Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Preparation for Wiring. pg. 4 Wiring.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches that the hanging location allows the blades a 7 feet (76cm) (2.13m) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. 8ft.

  • Page 5: Preparation For Wiring

    5. Preparation for Wiring. hook Remove single motor mounting screw from hook end of motor assembly. Remove hanging 2 motor mounting screws from hanging bracket bracket. Lift motor assembly to hanging bracket and slide hook end (with single screw hole) into square opening on hanging bracket (see diagram at right).

  • Page 6: Fan Assembly

    7. Fan Assembly. hanging bracket Carefully push wiring and wire connectors into outlet box. Leave hook end of motor assembly in square opening of hanging bracket and lift the other end of motor assembly toward hanging bracket. motor motor mounting Align motor assembly screw holes mounting screws...

  • Page 7: Blade Assembly

    9. Blade Assembly. Time Saver: Washers for blade screws can be set on each blade screw prior to installing motor housing blades. Locate 18 blade attachment screws and washers in one of the hardware packs. Hold blade attachment blade arm up to blade and align holes. Insert screws and washers 3 blade attachment screws (along with washers) with fingers first, and then tighten...

  • Page 8: Light Kit Assembly

    10. Light Kit Assembly. motor housing Install 1 medium base 6.5 watt LED bulb (included). Important: When replacing bulb, please allow bulb and glass shade to cool down switch housing before touching. thumbscrew thumbscrew Partially loosen the 3 thumbscrews in the light kit plate.

  • Page 9: Troubleshooting

    Service at 1-800-527-1292 to arrange for return of fan. 2. Verify that reverse switch is set completely in Return fan, shipping prepaid, to Litex Industries, Ltd. We will repair or ship you a replacement fan, and we will pay the either direction.
