Angelo Decor AD93640W Quick Start Manual

We hope you will find these instructions helpful in setting up your fountain.
If you have any issues with this item, please DO NOT return the unit to place of purchase.
Please visit our web site, www.angelodecor.com, for assistance and warranty information.
First unpack carton carefully, arranging parts safely in your working area.
Arrange all pieces in your Arrange all pieces in your
workspace. workspace.
Carefully lower the bowl on to Carefully lower the bowl on to
the pedestal. Align the the pedestal. Align the
grooves, then twist and lock it grooves, then twist and lock it
to the pedestal.
Set the pump housing /
riser in to place, align the
grooves then twist and lock
it to the bowl.
Align the top then lower and
secure it to the small bowl.
Now simply fill with clean water and plug into a grounded GFCI outlet.
We recommend keeping bowl 3/4 full of water to avoid pump burnout.
Product must be properly stored for winter.
Thank you for buying an Angelo Décor Fountain!
Pass the power cord down the Pass the power cord down the
cord pipe in the large bowl. cord pipe in the large bowl.
The pump is preset to full The pump is preset to full
strength. If splash is a strength. If splash is a
concern, adjust as needed. concern, adjust as needed.
Feed the tubing up the pump
housing / riser and pass it
through the middle of the
small bowl.
Carefully rest the bowl on its side. Carefully rest the bowl on its side.
Feed the pump cord down the Feed the pump cord down the
pedestal and out the base. pedestal and out the base.
Install the cord pipe cover Install the cord pipe cover
by aligning the cord then by aligning the cord then
fitting it in to the pipe. fitting it in to the pipe.
Align the grooves then
lower and twist and lock
the small bowl to the riser.
Check to ensure the
tubing is still properly
attached to the pump
and install the pump
access door. This
feature makes it
easier for you to
clean and adjust your
pump.
The final assembly
should look like this
Renaissance Fountain AD93640W
Align the pump cord with Align the pump cord with
the groove at the base of the groove at the base of
the pedestal. the pedestal.
The pump should sit flat The pump should sit flat
inside the bowl as shown inside the bowl as shown
above. Attach the included above. Attach the included
tubing to the pump.
Connect the tubing to the
top.
