Angelo Decor AD93378 Operating Instructions

Classic Solar Fountain
We hope you will find these instructions helpful in setting up your product.
If you have any issues with this item, DO NOT return the unit to place of purchase.
Please visit our web site www.angelodecor.com for assistance and warranty information.
Pass the power cord down the cord
Pass the power cord down the cord
pipe in the bowl. pipe in the bowl.
Carefully lower the bowl on to the Carefully lower the bowl on to the
pedestal. Align the grooves, then
pedestal. Align the grooves, then
twist and lock the bowl to the
pedestal.
Operating Instructions
For complete operating instructions, please see the included manual.
1. Install the included batteries.
2. Attach the included stake to the panel.
3. Fully charge the unit with the included charging cable or a minimum of
6 hours of direct sunlight.
4. Connect the pump to the corresponding socket on the panel.
5. Place the panel in a location where it will obtain consistent direct
sunlight.
6. Fill the fountain with clean water.
7. Turn the device on by pressing the power button.
8. Toggle the device to the desired method of operation: Direct solar or
Battery Power.
Direct Solar Power is the default method of operation. Battery Powered
operation will work for a period of up to 4 hours with a full charge.
The pump must be fully submersed at all times to avoid pump burnout.
Product must be properly stored for winter.
Carefully rest the bowl on its side. Feed the power cord down the Carefully rest the bowl on its side. Feed the power cord down the
pedestal and out the base. Align the power cord with the groove at
pedestal and out the base. Align the power cord with the groove at
the base of the pedestal. the base of the pedestal.
Connect the tubing from the top Connect the tubing from the top
to the pump.
to the pump.
The final assembly should
look like this
AD93378
Gently lower the top in place. Gently lower the top in place.
