Zaxcom ZMT3-HH

SETUP MENU

LED Color

LED COLOR:
BLUE
This menu sets the color of the LED light ring. The light ring can be set to OFF, BLUE, GREEN, CYAN, RED,
MAGENTA, YELLOW, or WHITE.

LED Ring Mode

LED RING MODE:
OFF
This menu controls when the light ring illuminates.
OFF - The light ring will not illuminate.
•
ALWAYS ON - The light ring will always stay illuminated.
•
ON WHEN MUTED - The light ring will illuminate when the microphone is muted via the key.
•
ON WHEN PRESSED - The light ring will illuminate when the key is pressed regardless to what the key
•
function is set to.
MODULOMETER -The light ring will illuminate when audio is present in the microphone. The ring will
•
illuminate green then yellow and then red, just before the signal is about to clip. The ring will turn blue
when NeverClip activates.

Key Function

MUTE SWITCH:
OFF
This menu sets the function of the mute key.
OFF - The key has no function.
•
PUSH TO TALK - The key need to be pushed to transmit, record or output audio.
•
PUSH TO MUTE - Pushing the key will mute the audio.
•
TAP TO TOGGLE - Pushing the key toggles between mute mode and un-mute mode.
•

Test Tone

•
TEST TONE: ON
•
I I
•
•
The ZMT3-HH has an internal tone generator so the signal chain can be properly gain staged. From this menu
pressing the INC key will turn on the tone generator pressing the INC key will cycle trough the different tone
options (500Hz at -20, 1000Hz at -20 or 500Hz at full scale).
I
18
