- Page 1 1347MA Model Revision 2.4 Updated Jun 8, 2016 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
- Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.
-
Page 4: Table Of Contents
1347576 Binder Assembly ........................29 1347462 Swing out Binder Assembly ...................... 31 213-005Y Button Assembly ........................32 1347468 Unfolder Assembly ........................33 1347554 Prefold Assembly ........................34 4000D-500 CONTROL BOX, 4000D ...................... 35 1347MA-PD Pneumatic Diagram ......................36 1347MA-WD Wiring Diagram ......................... 37... -
Page 5: Important Safety Instruction
Mandatory Information All persons operating and/or working on the 1347MA, should read and understand all parts of the Safety Instructions. This applies, in particular, for persons who only operate and/or work on the unit occasionally (e.g. for maintenance and repair). Persons who have difficulty reading must receive particularly thorough instruction. -
Page 6: Liability
Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet. -
Page 7: Safety Equipment On The Machines
Manual Técnico & Lista de Partes A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or... -
Page 8: Protective Eyewear
Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine. -
Page 9: Important Notices
Manual Técnico & Lista de Partes Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated. - Page 10 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.
-
Page 11: Maintenance
Manual Técnico & Lista de Partes Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine. -
Page 12: Repair
Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts. -
Page 13: A Word To The End User
Manual Técnico & Lista de Partes Starting Machine Movements Read the Instruction Manual carefully to establish which keys and functions start machine movements. A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines. - Page 14 Technical Manual & Parts Lists...
-
Page 15: Assembly Drawings & Parts Lists
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or... - Page 16 Technical Manual & Parts Lists...
-
Page 17: 11347Ma Auto Faux Hemmer, Single Hem
REWINDER W/MOUNTING ASSY Page Page 19 1347435 ROLL HOLDER,VERTICAL Page Page 21 1347464 WORK STATION,1347MA Page Page 33 1347468 UNFOLDER ASSY 1347MA Page 34 Page 1347554 PREFOLD ASSEMBLY Page Page 36 AR 1347MA-PD PNEUMATIC DRAWING Page Page 37 AR 1347MA-WD... - Page 18 Technical Manual & Parts Lists...
-
Page 19: 1330200 Rewinder W/ Mounting Assembly
Manual Técnico & Lista de Partes 1330200 Rewinder w/ Mounting Assembly AAC Drawing Number 1330200 Rev 4... - Page 20 Technical Manual & Parts Lists...
-
Page 21: 1347098 Rewind Assembly W/ Sleeve
Manual Técnico & Lista de Partes 1347098 Rewind Assembly w/ Sleeve AAC Drawing Number 1347098 Rev 1 NO. QTY PART# DESCRIPTION NO. QTY PART# DESCRIPTION 1961-319 PLATE,NUT,3/8-16@3.00 NNH1/2-13 NUT,HEX,1/2-13 1961-321 PLATE, ADAPTOR, AIR NNH3/8-16 NUT,HEX,3/8-16 1961-331 MOUNT, MOTOR NNK1/4-20 NUT,HEX,KEP,1/4-20 1961-332 COVER, MOTOR PP22LB075-1-1/8... - Page 22 Technical Manual & Parts Lists...
-
Page 23: 1347435 Vertical Roll Holder
Manual Técnico & Lista de Partes 1347435 Vertical Roll Holder AAC Drawing Number 1347435 Rev 2 NO QTY PART # DESCRIPTION 1347436 ROD, BENT, 90 DEG 1347437 ROD,SST,3/4 X 5,TAPPED 1961-251C HUB UNWIND SHAFT 1961-253 HUB, UNWIND STAND 1961-254 DISC 32 DIA. 1961-258 SUPPORT, DISC 1962-3201... - Page 24 Technical Manual & Parts Lists...
-
Page 25: 1347464 Work Station
CLAMP, SENSOR BRACKET 1000-6 TENSIO ASBLY, TABLETOP 26151 TOOL TRAY, 1X3.5X9 Page 23 1347364 SEWING HEAD DETAIL Page 25 Page 1347400 TABLE & STAND ASSY,1347MA Page 1347414 MODULAR HEMMER,SGL FOLD 1347431 BRACKET,PROX SENSOR Page 28 1347443 FLANGER ASSY Page 1347447... - Page 26 Technical Manual & Parts Lists...
-
Page 27: 1347364 Sewing Head
Manual Técnico & Lista de Partes 1347364 Sewing Head AAC Drawing Number 1347364 Rev 2 QTY PART # DESCRIPTION 11200A BUMPER 5/16-24 112013 BRKT,AIR LIFT CYLINDER 1862N14001 NEEDLE CHUCK,1N 1804 1888N12S01 FEED DOG 1N 1888N13S01 PLATE, NEEDLE, 1N AAC6S-1-H POSITION,SENSOR MT. 54242B9016 SPREADER,9NDL 1/4 GA AA198RR508... - Page 28 Technical Manual & Parts Lists...
-
Page 29: 1347400 Table Stand Assembly
NO. QTY PART# DESCRIPTION NO. QTY PART# DESCRIPTION 4000D-500 CONTROL BOX NNE10-32 NUT,ELASTIC LOCK 1278-6161 FOOT SWITCH NNH5/16-18 5/16-18 HEX NUT 1347MA-PD PNEUMATIC DIAGRAM NNM103 NUT,RECESSED,5/16 1347MA-WD WIRING DIAGRAM SSBC01048 SCREW,BUTTON CAP 1959-120 BRKT,MOUNTING,4000D SSFC80016 SCR,FLAT HD,CAP,6-32 1961-159 PLATE, MOUNT, FOOT... - Page 30 Technical Manual & Parts Lists...
-
Page 31: 1347414 Single Fold Modular Hemmer
Manual Técnico & Lista de Partes 1347414 Single Fold Modular Hemmer AAC Drawing Number 1347414 Rev 6 PART# DESCRIPTION 1278-6206 BLOCK BASE ASSEMBLY 1347416 EDGE GUIDE,END PLATE 1347420 GUIDE ASSY,FOLDER 1347422 FOLDER,FABRIC GUIDE 1347424 FOLDER TONGUE ASSY 1347430 ROD,S/S,1/2X22.0 1347433 ROD, BENT, 90 DEG 1347441 HEM GUIDE... -
Page 32: 1347443 Flanger Assembly
Technical Manual & Parts Lists 1347443 Flanger Assembly AAC Drawing Number 1347443 Rev 4 QTY PART # DESCRIPTION 1278-6206 BLOCK BASE ASSEMBLY 1335-320B ROD, ST, S/S, 11" L 1347457 FLANGER WELDMENT 1347466 ROD,BENT,SS,.5X9X5 1959-035 ROD, BENT, 90 DEG 23080A BLOCK,CLAMP,EYE 28201 BLOCK,CROSS,(LARGE) ROD CROSS BLOCK... -
Page 33: 1347576 Binder Assembly
Manual Técnico & Lista de Partes 1347576 Binder Assembly AAC Drawing Number 1347576 Rev 0 QTY PART # DESCRIPTION 1347116 RING,TAPE GUIDE Page 31 1347462 SWING OUT BINDER ASSY Page 1347577 ROLL HOLDER, ANGLED... - Page 34 Technical Manual & Parts Lists...
-
Page 35: 1347462 Swing Out Binder Assembly
Manual Técnico & Lista de Partes 1347462 Swing out Binder Assembly AAC Drawing Number 1347462 Rev 1 QTY PART # DESCRIPTION 1347022 GUIDE CLAMP 1347362 MOUNT, BLOCK BINDER 1347459 BINDER PREFOLD BAR 1347460 PREFOLD BINDER BRACKET IID016X160 DOWEL PIN,1/4 X 2-1/2 SSPS80016 #6-32 X 1/4 LG PAN HD SSPS98040... -
Page 36: 213-005Y Button Assembly
Technical Manual & Parts Lists 213-005Y Button Assembly AAC Drawing Number 290017A Rev 0 QTY PART # DESCRIPTION EE800FMLMP40E3 Push Button EE3X01 Switch, N.C. SPST EE3X10 Switch, N.O. SPST 350-12154 Bracket EEA3L Mounting Latch... -
Page 37: 1347468 Unfolder Assembly
Manual Técnico & Lista de Partes 1347468 Unfolder Assembly AAC Drawing Number 1347468 Rev 1 PART# DESCRIPTION 11-7080 ROD, STRAIGHT, CRS,1/2 28201 BLOCK,CROSS,(LARGE) 1347467 ROD,BENT,3/8,SS,12X18... -
Page 38: 1347554 Prefold Assembly
Technical Manual & Parts Lists 1347554 Prefold Assembly AAC Drawing Number 1347554 Rev 0 QTY PART # DESCRIPTION 1330217 SPACER, FOLDER 1330219 PLATE,NUT,10-32 X 2 1330221 PLATE,WASHER,#10 X 2 1347553 PREFOLD SCROLL 311-154 MACHINE MOUNT,1/2" HOLE NNK8-32 NUT,KEP,8-32 SST098032 SCREW,THUMB,10-32 X 1/2 TTH32425 HANDLE,THRDED,5/16-18X3/4... -
Page 39: 4000D-500 Control Box, 4000D
Manual Técnico & Lista de Partes 4000D-500 CONTROL BOX, 4000D AAC Drawing Number 9005195 Rev 1 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 4000D-01 BOX BOTTOM,PLAIN FF342838A FUSE HOLDER, PANEL MOUNT 4000D-02 PC BOARD, RELAY FF700-FEA3TU23 RELAY,TIMER,DIN,ON DELAY 4000D-WD4 WIRING DIAGRAM, W/TIMER FFGFTS-4... -
Page 40: 1347Ma-Pd Pneumatic Diagram
Technical Manual & Parts Lists 1347MA-PD Pneumatic Diagram 125296B... -
Page 41: 1347Ma-Wd Wiring Diagram
Manual Técnico & Lista de Partes 1347MA-WD Wiring Diagram 125297B... - Page 42 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
- Page 43 Declaración de Garantía Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de material y de mano de obra durante un período de ochocientos (800) horas de operación o cien (100) días, cual llegue primero.
- Page 44 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com Printed in the USA...
