System Board - HP OMEN Maintenance And Service Manual

System board

Description
System board
All system boards use the following part numbers:
xxxxxx-001 Non-Windows operating systems
xxxxxx-601 Windows 10 operating systems
● NVIDIA N17P-G2 (GeForce GTX 1070), 8GB i7-1700HQ
NVIDIA N17E-G1 (GeForce GTX 1060), 6 GB i7-7700HQ
●
● NVIDIA N17P-G1 (GeForce GTX 1050Ti), 4 GB i7-7700HQ
● NVIDIA N17P-G0 (GeForce GTX 1050), 4 GB i7-7700HQ
● NVIDIA N17P-GR (GeForce GTX 1050), 4 GB i5-7300HQ
● NVIDIA N17P-G0 (GeForce GTX 1050), 2 GB i7-7700HQ
● NVIDIA N17 E-G0 (GeForce GTX 1060), 2 GB i5-7300HQ
NVIDIA N17E-G1 (GeForce GTX 1060), 2 GB i5-7300HQ
●
● AMD RX580 (R17M-E1-90), 8 GB i7-7700HQ
USB board cable
IMPORTANT:
and replacement.
Before removing the system board, follow these steps:
1. Shut down the computer.
2. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
3. Disconnect all external devices connected to the computer.
4. Remove the following components:
a. Base enclosure (see
b. Battery (see
c. Speakers (see
d. Optical drive (see
e. Remove the fans (see
f. Remove the heatsink (see
NOTE: When replacing the system board, be sure that the following components are removed from the
defective system board and installed on the replacement system board:
● WLAN module (see
Memory module (see
●
56 Chapter 6 Removal and replacement procedures for authorized service provider parts
Make special note of each screw and screw lock size and location during removal
Base enclosure on page
Battery on page
Speakers on page
Optical drive on page
Fans on page
Heat sink on page
WLAN module on page
Memory module on page
44)
37)
46).
47)
52)
53)
49)
42)
Spare part number
929515–xxx
929516-xxx
929517-xxx
929518-xxx
929519-xxx
929520-xxx
929521-xxx
9377406-001
929522-xxx
931560-001
